  • Page 1 Installation Instructions / Warranty Talis S 32020XX1...
  • Page 2: Technical Specification

    Talis S Lavatory Mixer 32020XX1 32020XX1 Technical Specification Flow Rate Max incoming water pressure Recommended incoming water pressure Max incoming hot water temperature Recommended incoming hot water temp. Maximum mounting surface thickness Hole size *Prevent accidental scalding - know and follow all applicable local plumbing codes when setting the temperature on the water heater! Installation Considerations This faucet requires supply stops with 3/8”...
  • Page 3 Installation If the mounting surface is less than 3/16” thick, care- fully trim the spacer ring so that it is even with the bottom of the faucet. If the mounting surface is greater than 3/16”, leave the spacer ring intact. Place the mounting plate over the stud.
  • Page 4: User Instructions

    stopper assembly height adjuster flange sealing gasket mack gasket plastic washer mounting nut pivot ball seal pivot ball nut tailpiece horizontal rod swivel connector User Instructions Pivot the handle up to turn the water on, down to turn it off. Pivot the handle to the right for cooler water, to the left for warmer water.
  • Page 5 Reset the high temperature limit stop: Turn the water off at the stops. Push the handle to the full up position (1). Loosen the handle screw 4 complete turns with a 4 mm allen wrench (2). Pull off the handle (3) and the nut cover. Turn the stem so that the handle screw faces forward.
  • Page 6: Replacement Parts

    Replacement Parts handle 32092000 screw cover 96338000 flange 96656000 96690000 cartridge 92730000 handle screw 96059000 aerator 13085000 pop-up rod 96657000 mounting set 96016000...
  • Page 7: Limited Lifetime Consumer Warranty

    Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty.
  • Page 8 THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR: Conditions, malfunctions or damage not resulting from defects in material or workmanship. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance, misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents or “no rinse” cleaning products, or the use of the product in any manner contrary to the product instructions.
