Common Keys on All Keypads

Data Entry Digit keys
These keys allow you to enter your user code when arming or
disarming or enter other information into the system.
COMMAND (CMD) key
The COMMAND key allows you to advance through the keypad
displays, User Menu, or complete a data entry function.
Back Arrow (<— ) key
The Back Arrow (<—) key is used to go back through the keypad
displays while operating your system. You can press the Back Arrow
key to back up through the list of functions in the User Menu or to
erase the last character you entered.
Keypad User Options
The User Options menu allows you to make adjustments to your
keypad to best fit your environment and needs.
On Security Command™, Thinline™, Aqualite™, or Thinline™ Series
Icon keypads, press and hold the Back Arrow and COMMAND keys
for two seconds. The keypad display changes to SET BRIGHTNESS.
Press the COMMAND key to display the next option or the Back
Arrow key to exit.
On Clear Touch™ keypads, touch and hold the center of the logo
icon for two seconds. The display changes to SET BRIGHTNESS.
Touch the COMMAND (CMD) key to display the next option or touch
the Back Arrow (<—) to exit the User Options function.
6
Backlighting Brightness
At the SET BRIGHTNESS display, use the left Select key to lower
the keypad brightness. Use the right Select key to increase the
brightness. On Thinline™ Icon Series keypads, enter the desired
brightness from the range of off (0) to maximum (8).
Note: If the brightness level is lowered, it temporarily reverts back
to maximum intensity whenever a key is pressed.
On Security Command™, Thinline™, or Aqualite™ keypads this
sets the LCD display, AC LED, and keyboard backlighting brightness
level.
On Clear Touch™ keypads the user selected brightness may be set
to off which allows the backlighting to turn off (clear glass). Simply
touch the glass anywhere and the backlight illuminates for data
entry. When the speaker is sounding, the backlight illuminates at
one-half (1/2) brightness.
On Thinline™ Series Icon keypads this sets the LCD display,
keyboard, and logo backlighting brightness level.
Internal Speaker Tone
Set the tone of the keypad internal speaker. At the SET TONE
display, use the top left Select key to make the tone lower. Use the
right Select key to make the tone higher. On Thinline™ Icon Series
keypads, enter the desired speaker tone from the range of 1-8.
Volume level
Set the volume level of the keypad internal speaker for key presses.
During alarm, trouble, and prewarn conditions, the volume is always
at maximum level. At SET VOLUME LEVEL, use the left Select key
to lower the keypad volume. Use the right Select key to raise
the volume. On Thinline™ Icon Series keypads, enter the desired
speaker volume level from the range of off (0) to maximum (8).
