Access Card
Your system may have a built-in proximity card reader or an external
proximity card reader. When you present your access card to the proximity
reader as shown below, the system reads the user code in the same way as
when you enter the user code on the keypad. An access card may be used
for any system operation that requires you to enter a user code.
ARMED
1
2
3
4
READY
TRBL
STAY
POWER
INSTANT
STAY
I N STANT
BYPASS
CODE
1
2
3
4
A B C
D E F
G H I
J K L
5
6
7
8
OR
MN O
P Q
ST U
VW X
R
9
0
SPECIAL
COM MA ND
External
Y Z
743
Proximity
Keypad
Reader
Door Strike
Present your card to the reader. Once the system validates the user code,
the Door Strike relay activates. The relay activates for ten seconds during
which time you can open the door.
Arming and Disarming
Present your card to the reader. Once the system validates the user code,
all areas arm or disarm and the Door Strike relay activates.
Entry Delay
Once the protected door opens and the entry delay starts, present your
card to the reader. Once the system validates the user code, all areas are
disarmed and the Door Strike relay activates.
2-Button Panic Keys
If your system has a label showing a Badge under the Þ rst and second left
top row keys, the optional Burglary Panic key function is enabled.
If your system has a label showing a Flame under the third and fourth top
row keys, the optional Fire Panic key function is enabled.
By pressing and holding the two keys over the icon for at least two
seconds, the system sends either a Panic (Badge) or a Fire (Flame) report
to the supervising alarm panel. The keypad beeps to conÞ rm the Panic
entry.

System Setup

Important Information About Your System
Your system is monitored by a central station.
C/S Name: ______________________________________________________
Address: _________________________________________________
City/State: _______________________________________________
Emergency Phone:__________________________________________
Service Phone: ____________________________________________
Service Manager: __________________________________________
Relay Output
Below is the type of device controlled by the relay output on your system.
_________________________________________________
Zones
Below is a list of protection devices on each of the zones in your system.
01. ___________________________ 03. ______________________________
02. ___________________________ 04. ______________________________
User Codes
The table below lists the user codes used in your system.
User
User Name
01
02
03
04
05
06
07
08
Yes
No
Tomorrow's technology for today's security needs.
Welcome
Congratulations on your decision to purchase a Security Command®
system. The Security Command, from one of America's leading security
manufacturers, is quickly setting the standard for residential and
commercial burglary and Þ re protection. Look forward to years of superior
service and system ß exibility as your protection needs change.
Easy to Use
As powerful as your system is, it is also one of the easiest to use. Whether
you want to turn the system on or off, or set it to chime when a door is
Level
opened, all you have to do is press a few keys on the Security Command
keypad. Each keypad contains a keyboard with easy to read lettering that
Standard
lights up as you use it and ten indicator lights that tell you everything
from whether a window is open to which areas of the system are armed.
Standard
There is also an internal alert sounder that gently chimes to remind you to
Standard
turn the system off or that indicates when someone enters a door.
Please Take a Moment
Standard
To learn the full range of features of your new system, we encourage
Standard
you to read through this User's Guide thoroughly. On the back we have
included a System Setup section where the installer can Þ ll in the
Standard
programmed information about your system and where you, as your
Master
comfort with the system increases, can track additional changes you
should make.
Master
®
The SC Series Keypad
LT-0392 (1/04)
