Security Command SC Series User Manual

Access Card
Your system may have a built-in proximity card reader or an external
proximity card reader. When your access card is presented to the proximity
reader as shown below, your user code is read by the system just like you
would enter it on the keypad. For any system operation that requires
entering a user code, the access card may be used.
743 READY ARMED 1 2 3 4
TRBL STAY
POWER INSTANT
OR
I N STANT
STAY BYPASS CODE
1 2 3 4
A B C D E F G H I J K L
5 6 7 8
MN O P Q ST U VW X
R
9 0
SPECIAL COM MA ND
Y Z
DOOR STRIKE
Present your card to the reader. Once the user code is validated by the
system, the Door Strike relay activates. The relay activates for 10 seconds
during which time you can open the door.
ARMING AND DISARMING
Present your card to the reader. Once the user code is validated by the
system, all areas arm or disarm automatically and the Door Strike relay
activates.
ENTRY DELAY
Once the protected door is opened and the entry delay starts, present your
card to the reader. Once the user code is validated, the system disarms all
areas and activates the Door Strike relay.
2-Button Panic Keys
If your system has a label showing a Badge under the first and second left
top row keys, the optional Burglary Panic key function has been enabled.
If your system has a label showing a Flame under the third and fourth top
row keys, the optional Fire Panic key function has been enabled.
By pressing the two keys over the icon, and holding them down for at least 2
seconds, the system will send either a Panic (Badge) or a Fire (Flame)
report to the supervising alarm panel. The keypad beeps to confirm the
Panic entry.
Important Information About Your System
Your system is monitored by a central station.
C/S Name: __________________________________________________
Address: ___________________________________________________
City/State: __________________________________________________
external
Emergency Phone: ___________________________________________
proximity
reader Service Phone: ______________________________________________
Service Manager: ____________________________________________
Relay Output
Below is the type of device controlled by the relay output on your system.
Zones
Below is a list of protection devices on each of the zones in your system.
01. _________________________ 03. ____________________________
02. _________________________ 04. ____________________________
User Codes
Your system provides up to 8 user codes. Each code is made up of 3 parts:
The User Number is how the system identifies a user.
The User Code is the 4-digit number a user enters into the keypad to arm
and disarm the system or to perform other system operations.
User Level - There are 3 user levels; 1 Standard level and 2 Master levels.
A Standard level user can perform all user functions except adding,
deleting, or changing other user codes. In addition, a Standard level user is
allowed to change their own code. User 07 is a Master level that can
perform all user functions including adding, deleting and changing user
codes 01 through 07. User 08 Master level can perform all user functions
including adding, deleting and changing all user codes (01-08). Users 01
through 06 are always Standard level. Users 07 and 08 are always Master
level.
User
01
02
03
04
05
06
07
08

System Setup

Yes No
User Name Level
Standard
Standard
Standard
Standard
Standard
Standard
Master (01-07)
Master (01-08)
Tomorrow's technology for today's security needs.
The SC Series Keypad
Welcome
Congratulations on your decision to purchase a Security Command
system. The new Security Command, from one of America's leading
security manufacturers, is quickly setting the standard for residential
and commercial burglary/fire protection. You can look forward to years
of superior service and system flexibility as your protection needs
change.
Easy to Use
As powerful as your system is, it's also one of the easiest to use.
Whether you want to turn the system on or off, or set it to chime when
a door is opened, all you have to do is press a few keys on the Security
Command keypad. Each keypad contains a keyboard with easy to
read lettering that also lights up as you use it and 10 indicator lights
that tell you everything from whether a window is open to which areas
of the system are armed. There's also an internal alert sounder that
gently chimes to remind you to turn the system off or that indicates
someone just entered a door.
Please Take a Moment
To learn the full range of features of your new system, we encourage
you to read through this User's Guide thoroughly. On the back we've
included a System Setup section where the installer can fill in the
programmed information about your system and where you, as your
comfort with the system increases, can track any additional changes
you should make.
®
TM
LT-0392 7/98
