Installation

1.
Select a good location.
Place your fridge-freezer where it is easy to use.
2.
Avoid placing the unit near heat sources, direct
sunlight or moisture.
3.
To ensure proper air circulation around the
fridge-freezer, please maintain sufficient space
on both the sides as well as top and maintain at
least 2 inches (5 cm) from the rear wall.
4.
To avoid vibration, the unit must be leveled.
If required, adjust the leveling screws to
compensate for the uneven floor.
The front should be slightly higher than the rear
to aid in door closing.
Leveling screws can be turned easily by tipping
the cabinet slightly.
Turn the leveling screws counterclockwise (
to raise the unit, clockwise (
5.
Clean your fridge-freezer thoroughly and wipe
off all dust accumulated during shipping.
6.
Install accessories such as ice cube box, etc., in
their proper places. They are packed together to
prevent possible damage during shipment.
7.
Connect the power supply cord (or plug) to the
outlet. Don't double up with other appliances
on the same outlet.
Applicable to some models only:
8.
To provide necessary air circulation, you should
leave enough space on each side, top and
behind the refrigerator-freezer.
Set the limit stops in the upper corners of the
back plate of the device as shown in Fig. 1.
Stops (2) can be found in the drawer inside
refrigerator compartment.
Fig. 1. Push Stopper (2) onto part (1) until the end
)
) to lower it.
Fig. 2. Push the refrigerator to the wall.
17
1
Installation
2
