WARNING:
Follow
instructions exactly, if not, a fire or explosion may
result causing property damage, personal injury or
loss of life.
WARNING: Do not store or use gasoline or any
other flammable vapors and liquids near this or any
other gas appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch electrical switches; do not use the phone in your
building.
Immediately call your gas supplier from a phone outside the
structure. Follow your gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department
or 911.
A qualified installer, service agency, or gas supplier must perform
installation and service of this appliance. In the Commonwealth of
Massachusetts, all installation of gas lines and gas fittings must be
performed by a licensed gas fitter or licensed plumber.
MODENA GAS HEATER. SAVE THIS DOCUMENT FOR
the
information
in
these
(Model 8140)
Gas Fired Direct-Vent Heater
OWNER'S MANUAL
INSTALLATION AND

OPERATING INSTRUCTIONS

PLEASE READ THIS ENTIRE OWNER'S MANUAL
BEFORE YOU INSTALL AND USE YOUR NEW
FUTURE REFERENCE.
AVERTISSEMENT: Assurez-vous de bien suivre les
instructions donné dans cette notice pour réduire au
minimum le risque d'incendie ou pour éviter tout
dommage matéeriel, toute blessure ou la mort.
Ne pas entresposer ni utiliser d'essence ni d'autre vaperurs ou liquides
inflammables dans le voisinage de cet apprareil ou de tout autre
appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
Ne pas tenter d'allumer d'appareil.
Ne touchez à aucun interrupteur. Ne pas vous servir des téléphones
se trouvant dans le batiment où vous vous trouvez.
Appelez immédiatement votre fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
Si vous ne pouvez rejoindre le fournisseur de gaz, appelez le
service dos incendies.
L'installation et service doit être exécuté par un qualifié installer, agence
de service ou le fournisseur de gaz.
hase - Modena Model 8140
Manual # 6400-40458
Revised: 9/26/2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8140 and is the answer not in the manual?

Questions and answers

Summary of Contents for HearthStone 8140

  • Page 1: Operating Instructions

    In the Commonwealth of de service ou le fournisseur de gaz. Massachusetts, all installation of gas lines and gas fittings must be performed by a licensed gas fitter or licensed plumber. hase - Modena Model 8140 Manual # 6400-40458 Revised: 9/26/2008...
  • Page 2: Service Record

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 Information Sheet Use this page to record all relevant information concerning the purchase, installation, and maintenance of your Modena Gas-Fired Direct-Vent heater. This information will facilitate servicing, purchase of replacement parts, and warranty claims (if necessary). Keep your original receipt in a safe place as proof of purchase.
  • Page 3: Table Of Contents

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 ’ EAD THIS WNER ANUAL ABLE OF ONTENTS   Operate and maintain this gas heater according to the ............3 NTRODUCTION instructions in this manual. For your safety, and years of  ...
  • Page 4: Specifications

    Certified for US and Canada and flammable material. Approved for Mobile Home Installation " " Figure 1: Modena DV Model 8140 Dimensions FUEL TYPE: INPUT RATING (Btu/hr) 0-2000 ft 26,500 26,500 INPUT RATING (Btu/hr) 2000-4000 ft...
  • Page 5: Owner ' S Information

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 window glass. This condensation will evaporate within the ’ WNER NFORMATION first few minutes of operation. If you note continuous The installation must conform with local codes or, in the condensation on the window glass or dripping water from...
  • Page 6: Installer S Information

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 ’ NSTALLER NFORMATION Note: Vent kits and components are supplied separately. ODES Failure to use the venting components specified by Adhere to all local codes or, in their absence, the latest Hearthstone QHHP, Inc.
  • Page 7: Installing The Modena

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 independent laboratory ANSI INSTALLING THE ODENA standards, will prevent fire spontaneous combustion. We do not control the combustible EARTH EQUIREMENT LOOR ROTECTION materials exposed to heat by this product; When installing the Modena on carpet, vinyl, or any other...
  • Page 8 HearthStone Quality Home Heating Products, Inc. Modena Model #8140 Wall pass-through Minimum12" pipe section 90 degree elbow Termination Minimum 24" pipe section 1" rear clearance to combustible Figure 3: Minimum Vent Configuration and Clearances...
  • Page 9 HearthStone Quality Home Heating Products, Inc. Modena Model #8140 Acceptable Direct-Vent TERMINATION Cap locations. Figure 4: Termination Location & Clearances...
  • Page 10: Venting Information

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 ENTING NFORMATION ONNECTION 1. The Modena Direct Vent is approved for installation only with the vent connecting components listed; Simpson Dura-Vent Direct Vent GS, AmeriVent Direct, Selkirk Direct Temp™ or Secure Vent OPEN systems.
  • Page 11 HearthStone Quality Home Heating Products, Inc. Modena Model #8140 NOTE: These positions are based on lab results, and can have some variance. Figure 7: Venting Configurations & Restriction Settings...
  • Page 12 HearthStone Quality Home Heating Products, Inc. Modena Model #8140 Co-Linear Flex Connector & ENTING OMPONENTS Co-Axial to Co-Linear Appliance Connect (Masonry ONFIGURATION approved, not to exceed 16’ measured from the stove Do not vent the Modena jointly with any other solid fuel or top) gas appliance.
  • Page 13: Electrical Connections

    EMOTE ONTROL HERMOSTAT window. The Modena 8140 comes equipped with a programmable ON/OFF/Thermostat remote control. We recommend the Do not place the thermostat transmitter directly behind or use of the thermostatic remote for more comfortable too close to the unit, otherwise heat from the unit will performance, however you may still override the thermostat immediately satisfy the thermostat and turn the unit off.
  • Page 14: Gas Supply & Connections

    HearthStone Quality Home Heating Products, Inc. Modena Model #8140 Figure 9: Gas Control Valve pressures equal to or greater than ½ psig (3.5kPa). & C UPPLY ONNECTIONS Disconnect the Modena and its individual shut-off valve from the piping system when testing the valve and NOTICE: A qualified technician must connect the connections at pressures equal to, or greater than ½...
  • Page 15: Fire Stone Placement

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent TONE LACEMENT CAUTION: Fragile! Handle fire stone set with care. Always wear gloves and safety goggles while handling the stone set. Place only the Fire stone set supplied with the Modena in the firebox.
  • Page 16: Initial Adjustments

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent around the appliance area for gas. Be sure to smell next to CAUTION: Lighting the Modena for the first time the floor because some gases (LP) are heavier than air and and adjustments to the unit should be performed by will settle on the floor.
  • Page 17 HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent gases are heavier than air and will settle on the floor. lit regardless of the remote thermostat setting. The only way If you smell gas immediately follow the What To Do...
  • Page 18: Routine Maintenance And Care

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent forward to close the air shutter. Pull it towards you to open cooled, releasing the electromagnet (Approx. 60 sec.). The the air to the unit. When the flame pattern is correct, tighten gas control knob is designed to operate by hand.
  • Page 19 HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent The door is attached to the stove with two machine screws LEANING (see figure 13) one on the top above the door, and one below the lower left corner of the door. To access these WARNING: Do not clean the unit when hot.
  • Page 20 HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent LASS REPLACEMENT PROCEDURES 1. Follow the instructions included with the replacement glass kit. 2. Remove the door (see door removal procedure). 3. Remove the 12 screws from the glass-frame (use penetrating oil if necessary) –...
  • Page 21: Parts List

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent LASS LEANING As fuel gas may contain some impurities; it will be necessary to clean the inside of the glass occasionally. Do not use abrasive cleaners. Scratching the glass will weaken the integrity of the glass.
  • Page 22: Bolting Your Modena Gass

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent OLTING YOUR ODENA Leave the screws loose. Next, level, then slide the rear plate TOVE TO A ERMANENT up tight to the wall. Using the three screws provided, screw the steel plate to the wall. Once the screws are in place and...
  • Page 23: Troubleshooting

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent ROUBLESHOOTING Symptom Possible Cause Corrective Action 1. Pilot will not light. A. Insufficient gas pressure, air in A. Using the piezo sparker, try to light the pilot. If it will the pilot line, or dirty or kinked gas not light, check the inlet gas pressure.
  • Page 24 HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent Troubleshooting Symptom Possible Cause Corrective Action 3. Pilot burning, no gas A. Thermostat switch or wires A. Check thermostat/wiring for proper connections. to main burner, valve defective. Place jumper wire across terminals at thermostat. If knob in the "ON"...
  • Page 25 HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent Troubleshooting Symptom Possible Cause Corrective Action 8. Floating flames, lazy A. Potentially dangerous A. Check the appliance input rate and reduce if ill-defined, quiet flames, incomplete combustion due to necessary. The air intake/exhaust flow system may be...
  • Page 26: Rating Label

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent ATING ABEL 8140- MODE L # SER IAL # MODEL NAME: MODENA DIRECT VENT GA S FIRED HEATER LISTED : GAS FIR ED D IRECT VENT HEATE R CER TIFIED FOR A ND US CANADA HOMOLOG UE PO UR LE CANADA TES TED TO: A NSI Z21.88b-2005/CSA 2.33b-2005...
  • Page 27: Hearthstone Euro Collection Warranty

    HearthStone Quality Home Heating Products, Inc. MODENA 8140 Gas-Fired Direct-Vent EARTHSTONE OLLECTION IRED TOVE ARRANTY These warranties give you specific legal rights. You may also have other rights that vary from State to State. Hearthstone Quality Home Heating Products, Inc. (Hearthstone) warrants to the original purchaser only (the “Original Purchaser”) the new gas-fired stove/insert manufactured by Hearthstone and purchased by the Original Purchaser (referred to...
  • Page 28 or excessive venting, insufficient make-up air or negative air pressure whether or not caused by exhaust fans, clothes dryers etc. Additional exclusion of any liability is for the following: Grit leaking during transportation and installation of the Stove. Occurrence of odors during the first hours of operation resulting from the process-related "baking" of the stove paint and surrounding environment.
  • Page 29 OTES...
  • Page 30 OTES...
  • Page 31 OTES...
  • Page 32: Ccess

    – F UICK EFERENCE IREBOX CCESS & G LASS RAME EMOVAL ROCEDURE To access the firebox, remove the front door (recommended). The door is attached to the stove with two machine screws (see figure 16) one on the top above the door, and one below the lower left corner of the door.
