Shelburne
(Model 8370)
Woodstove
OWNER'S MANUAL
INSTALLATION & OPERATING
INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE
YOUR NEW Shelburne WOOD STOVE. To reduce the risk of fire, follow the installation
instructions. Failure to follow these instructions may result in property damage,
bodily injury, or even death.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
CONTACT LOCAL AUTHORITIES HAVING JURISDICTION (BUILDING DEPARTMENT or
FIRE OFFICIALS) ABOUT PERMITS REQUIRED, RESTRICTIONS, AND INSTALLATION
INSPECTION IN YOUR AREA.
Shelburne Model 8370
Manual: 6400-4041
R: 2 - 8/19/10
Advertisement
Table of Contents
Troubleshooting
Subscribe to Our Youtube Channel
Related Manuals for HearthStone Shelburne 8370
Summary of Contents for HearthStone Shelburne 8370
- Page 1 Shelburne (Model 8370) Woodstove OWNER'S MANUAL INSTALLATION & OPERATING INSTRUCTIONS PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL AND USE YOUR NEW Shelburne WOOD STOVE. To reduce the risk of fire, follow the installation instructions. Failure to follow these instructions may result in property damage, bodily injury, or even death.
- Page 2 Failure to do so may result in a cracked or broken glass. If you have a crack or break in your glass, please contact your dealer immediately for replacement. HearthStone Quality Home Heating Products Inc ® Model 8370...
-
Page 3: Table Of Contents
Creosote Formation And Need For Removal ................23 Gaskets............................24 Glass.............................. 24 Cast Iron............................25 TROUBLESHOOTING........................25 ........................27 ROUBLESHOOTING UIDE & O ................28 EPLACEMENT ARTS PTIONAL CCESSORIES ............................29 AFETY ABEL Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 4: Introducing Your Shelburne Wood Stove
2 grams per hour particulate you can be wall coverings as specified by this manual, the proud to join the HearthStone family with our NFPA 211 codes, and your local authorities Premier Wood Burning Stove. The generous having jurisdiction. -
Page 5: Codes
According to the manufacturer's recommendations. Validate your warranty - return your warranty registration card to HearthStone within 30 days In accordance with all applicable codes. of purchase. Once returning your warranty card has validated your warranty, contact your dealer With the proper sized chimney. -
Page 6: Periodic Checklist
11) Thoroughly clean out the inside of the stove. Install a smoke detector. Inspect all door gasket material and replace if worn, frayed, cracked or extremely hard. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 7: Emergency Procedures
BODILY HARM. HearthStone’s Thermo-Ceramic Baffle System To enhance the combustion efficiency and reduce the emissions of the fire in your stove HearthStone QHHP, Inc. has developed an advanced THERMO-CERAMIC baffle system. This system uses a lightweight, durable ceramic material above the burner tubes to maintain the high temperatures in the secondary combustion area and maintain the low emission –... -
Page 8: Specifications
Outside Air Kit, Optional Equipment Blower, Rear Heat Shield Ø6.00" SHELBURNE SHELBURNE SHELBURNE SHELBURNE FRONT VIEW SIDE VIEW TOP VIEW SIDE VIEW (REAR EXIT) (TOP EXIT) Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 9: Setting Up Your Shelburne Wood Stove
ATTACH TO 3" FLEX PIPE OUTSIDE AIR INTAKE FROM OUTSIDE AIR SOURCE (PT# 5950-027) stove. UTSIDE ONNECTIONS If you use a close clearance connector pipe, it must be tested to UL standards and listed. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 10: Hearth Requirements And Floor Protection
R-value of the specified floor protector, possibility of obstruction by snow, leaves or then your setup is acceptable. other material and should be screened against animals and insects. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 11: Clearances T O Combustibles
2-in. 50-mm Double wall connector Connector type Unprotected Surfaces (horiz.) Protected Surfaces (NFPA 211) (horiz.) 18-in. 460-mm 9-in. 230-mm Single wall connector pipe 6-in. 150-mm 3-in. 75-mm Double wall connector pipe Hearthstone Quality Home Heating Products, Inc ® Model 8370... - Page 12 CHECK THE SPECIFICATIONS FROM MANUFACTURER YOUR When used in a mobile home, a spark arrester CONNECTOR. is required. (See page 16) CHIMNEY CONNECTOR CLEARANCE TO COMBUSTIBLES SINGLE WALL CONNECTOR DOUBLE WALL CONNECTOR Hearthstone Quality Home Heating Products, Inc ® Model 8370...
-
Page 13: Venting Components And Configuration
(without moving the stove) when you chimney or an approved high temperature periodically inspection the stovepipe connection type building prefabricated residential and chimney. heating appliance chimney. Do not connect this stove to a chimney serving another Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 14: Connecting Your Wood Stove
When connecting Shelburne prefabricated metal chimney, you must follow, precisely, manufacturer's installation instructions. Use only Type HT (2100 deg. F), prefabricated metal chimneys listed per UL 103 or ULC S629 standards. Hearthstone Quality Home Heating Products, Inc ® Model 8370... - Page 15 An exterior discourages the formation of creosote. chimney’s draft is not as strong and may exterior chimney does not benefit from the experience increased creosote accumulation. Hearthstone Quality Home Heating Products, Inc ® Model 8370...
-
Page 16: Connection To A Masonry Chimney
This stove requires a minimum chimney height of 13 feet (4 m). The maximum allowable Chimney wall construction: chimney height is 30 feet (9m). Brick or modular block at least 4" (102 mm) thick. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 17: Installing I N A Mobile Home
▌ WARNING: DO NOT INSTALL IN A SLEEPING ROOM ▌ CAUTION: MAINTAIN THE STRUCTURAL INTEGRITY OF THE MOBILE HOME WALLS, FLOOR, CEILING, AND ROOF WHILE YOUR STOVE IS INSTALLED AND IN USE Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 18: Operating Your Shelburne Wood Stove
Generally speaking, the more air allowed into the firebox, the faster and hotter the rate of burn; conversely, Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 19: Choosing Firewood
Cherry, Soft Maple, Tamarack LOW: White Pine, White Cedar, Balsam Fir, Spruce, Aspen, Basswood, Butternut, Hemlock Moisture content also plays a key role in the performance of your stove. Wood freshly cut Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 20: Buildinga Fire
1. Open the door and place five or six double sheets tightly twisted newspaper in the center of the firebox. Arrange kindling in a crisscross pattern Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 21: Normal Operation
Once the fire is burning well, use the primary air control to regulate the desired rate of burn. Pulling the lever toward the front of the stove opens the Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 22: Over-Fire Caution
EMOVAL ISPOSAL SHES Ashes should be removed when the stove is cold. Use protective fireplace gloves when the pan is warm. Exercise extreme caution when handling, storing or disposing of ashes. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 23: Maintenance
The stovepipe connector and chimney should be inspected at least monthly during the heating Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 24: Gaskets
(take care to save hinge pins and washers for reuse). Lay the door face down on a workbench Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 25: Cast Iron
Enamel castings can be cleaned with a standard smoke to pour into the room. glass cleaner. With time and use, a very fine, Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 26: Operating The Stove
WIND VELOCITY: Generally, the stronger frequently with small fuel until the chimney is and steadier a wind, the stronger (better) the draft well established. draft. However, "gusty" wind conditions may cause erratic downdrafts. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 27: Troubleshooting Guide
Do not over-fire the stove. Monitor stove temperatures. Use ENAMEL CASTING seasoned wood only. Excessive Draft Check the DRAFT. (See page 10) A damper may be required. Operate the stove at a LOW BURN range. Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 28: Replacement Parts & Optional Accessories
5370-065 SUPPORT, REAR FIREBRICK 5370-066 SUPPORT, SIDE FIREBRICK 5370-068 CLIP, GLASS 5370-070 FRONT DOOR STRIKER PLATE 5370-112 THROAT BAFFLE, SS CRANK: HANDLE, 45, 5010-080 MAN/HER/STA/PHX 5570-030 CABLE: LABEL, 1/16” X 12” Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 29: Safety Label
AFETY ABEL Hearthstone Quality Home Heating Products, Inc ® Model 8370... -
Page 30: Hearthstone Woodstove Limited Warranties
“Original Purchaser”) the new woodstove manufactured by HearthStone and purchased by the Original Purchaser (the “Woodstove”) against any of the occurrences listed in this document that result from defects in material or workmanship. All obligations of HearthStone under this document commence on the date the Original Purchaser purchases the Woodstove (the “Purchase Date”). - Page 31 12. A defect in any part of the Woodstove if the Original Purchaser fails to comply with HearthStone’s or a Dealer’s request to ship the part or the Woodstove to HearthStone or a Dealer, as the case may be.
- Page 32 Woodstove is located. In the event the Original Purchaser refuses to allow a Dealer to make a service call, HearthStone or a Dealer, as the case may be, will request that the Original Owner return the defective part, or the entire Woodstove (if needed), with shipping prepaid, to HearthStone or a Dealer.
