HearthStone Deva 100 Owner's Manual

Wood-fired cookstove
Hide thumbs Also See for Deva 100:
Table of Contents

Advertisement

Quick Links

JURISDICTION (BUILDING DEPARTMENT or FIRE
RESTRICTIONS AND INSTALLATION INSPECTION
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL AND USE
YOUR NEW Deva WOOD STOVE. To reduce the risk of fire, follow the installation instructions.
Failure to follow these instructions may result in property damage, bodily injury, or even death.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
CONTACT LOCAL AUTHORITIES HAVING
OFFICIALS) ABOUT PERMITS REQUIRED,
IN YOUR AREA.
Deva 100
Wood-fired cookstove
OWNER'S MANUAL
INSTALLATION AND OPERATING
INSTRUCTIONS
(8220)
Deva 100 Model# 8220
6400-40460
Revised 10-12-07

Advertisement

Table of Contents
loading

Related Manuals for HearthStone Deva 100

Summary of Contents for HearthStone Deva 100

  • Page 1 Failure to follow these instructions may result in property damage, bodily injury, or even death. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE! Deva 100 Wood-fired cookstove OWNER'S MANUAL INSTALLATION AND OPERATING INSTRUCTIONS IN YOUR AREA. (8220) Deva 100 Model# 8220 6400-40460 Revised 10-12-07...
  • Page 2 HearthStone Quality Home Heating Products Inc ® Model 8220...

  • Page 3: Table Of Contents

    INTRODUCING YOUR DEVA 100 COOKSTOVE ... 4 ... 5 ODES ... 5 AFETY NFORMATION Periodic Checklist ... 6 Emergency Procedures... 7 ... 8 PECIFICATIONS SETTING UP YOUR DEVA 100 COOKSTOVE... 9 ... 9 NPACKING NSTALLING TOVE EARTH EQUIREMENTS LEARANCES OMBUSTIBLES Components of a Venting System...

  • Page 4: Introducing Your Deva 100 Cookstove

    Congratulations! You have just invested in a most unique wood burning cook stove – the Deva 100 from HearthStone Quality Home Heating Products Inc®. The Deva 100 Model 8220 is a wood burning cook-stove. At 1.6 cubic feet firebox and 2.47 cubic feet oven capacity you can be proud to join the HearthStone family with our Premier Wood Burning Cookstove.

  • Page 5: Codes

    The performance of your stove depends on many variables. Since all installations are unique, the general information and operating procedures presented here can only serve as useful if you have any questions; do not hesitate contact your dealer information. Validate your warranty - return your warranty registration card to HearthStone within 30 days of purchase to validate your warranty.

  • Page 6: Periodic Checklist

    Never modify this cookstove in any way. Never burn kiln dried wood, painted or treated wood, solvents, trash, plywood, colored or glossy paper, artificial logs, cardboard, coal, garbage or driftwood. Especially, do not burn coal in this stove. Never Use gasoline type fuel, kerosene, charcoal lighter fluid, or other liquid fuels or solid fire starters to start or invigorate the fire.

  • Page 7: Emergency Procedures

    sealed properly.) To tighten the seal, change the door gasket. Every Season: Have a qualified service technician inspect your chimney and wood burning system. • Dismantle the chimney connector and clean it thoroughly. Replace any pieces that show signs of rust or deterioration. •...

  • Page 8: Specifications

    Specifications Oven Capacity: 2.47 cubic feet 1.6 cubic feet Firebox Capacity Maximum Heat Output: 46,000 BTUs per hour of cordwood (based on independent laboratory test results) Maximum Log Length: 17" (43 cm) fuel 40" 33-3/4 HearthStone Quality Home Heating Products Inc ® Height: 33-3/4"...

  • Page 9: Setting Up Your Deva 100 Cookstove

    If any parts are damaged or missing, please contact your dealer immediately. NSTALLING TOVE The Deva 100 is not approved for installation in a mobile home. The Deva 100 Cookstove does not require the use of additional outside air for combustion.

  • Page 10: Hearth Requirements And Floor Protection

    8 inches (20 cm) beyond each side of the cook stove. (See Figure 1) The hearth protection for your Deva 100 must have an R-value of at least 0.89 or be a UL Listed floor protection. An example of a non-combustible floor...
  • Page 11 MINIMUM CLEARANCES TO COMBUSTIBLES (from closest point of stove) Clearances Single wall connector Top Exit (in) (cm) 21.5 LCOVE Clearances Alcove requirements Maximum alcove depth is 48”/122cm Minimum alcove height is 96”/ 2439cm Minimum alcove width is 63”/ 160cm (with single wall connector) Minimum alcove width is 58”/ 147cm (with double wall connector) HearthStone Quality Home Heating Products Inc ®...

  • Page 12: Components Of A Venting System

    SINGLE WALL CONNECTOR ENTING OMPONENTS AND ONFIGURATION OMPONENTS OF A ENTING DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE The complete venting system consists of several components: chimney connector, wall thimble, wall pass-through, chimney, and liner. absolutely necessary that if you install all of these components, they must remain within the clearances to combustibles discussed earlier to...

  • Page 13: Installing A Venting System

    Simpson Dura Vent DVL, Metalbestos following acceptable close clearance connector pipe for the Deva 100; Security, GSW and Ameritec. o Chimney connector shall not pass through floor or ceiling, nor any attic or roof space, closet or similar concealed space.

  • Page 14: Connecting Your Wood -Fired Cookstove

    Remember, the NFPA has recommended, minimum clearances for chimney connectors to combustibles such as walls and ceilings. ONNECTING OOKSTOVE You can install your Deva 100 to a prefabricated metal chimney or a masonry chimney. ONNECTING TO A REFABRICATED ETAL HIMNEY...
  • Page 15 Extended Roof Support Bracket (Conduit not included) Attic Insulation Shield Twist-Lock Chimney Sections Two story house installation with attic. Chimney through outer wall with enclosed chase. Chimney is supported by Tee Support Bracket. Whenever possible, choose an interior chimney. An interior chimney heats up more quickly and retains its heat;...
  • Page 16 2) Locate and remove the four bolts that hold the block-off plate on the back of the stove. Remove the plate. 3) Place the flue collar on the back of the stove over the rear flue exit with the gasket side towards the stove. Rotate the collar so the 3 chimney connector screws are easiest to access when necessary to install later.
  • Page 17 Chimney height requirements: Illustration) At least 3 feet (0.9 m) higher than the highest part of the roof opening through which it passes. HearthStone Quality Home Heating Products Inc ® At least 2 feet (0.6 m) higher than any part of the roof within 10 feet (3 m) measured (See horizontally from the top of the chimney.
  • Page 18 HearthStone Quality Home Heating Products Inc ® Model 8220...

  • Page 19: Operating Your Deva 100 Wood Stove

    For your own safety, do not modify these features in any way. FLUE BYPASS SYSTEM: When starting a fire in a cold Deva 100 you will need to use the flue bypass system. This is the handle at the top HearthStone Quality Home Heating Products Inc ®...

  • Page 20: Choosing Firewood

    Remove ashes when the stove is cold. If the ash pan is warm, use protective fireplace gloves. Exercise extreme caution when handling, storing or disposing of ashes. HOOSING IREWOOD Your Deva 100 cookstove is designed to only burn firewood-also known as cordwood. ▌ CAUTION: CHEMICALS FLAMMABLE...

  • Page 21: Buildinga Fire

    UILDING IRST Once you understand the controls of your wood stove and have chosen the appropriate firewood, you are ready to start a fire. When you light your first fires, the wood stove will emit some smoke and fumes. normal “off-gassing” of the paints and oils used when manufacturing the wood stove.

  • Page 22: Burn Rate

    HIGH BURN: Fully load the firebox with wood on a bed of hot coals or on an actively flaming fire and fully open the primary air control. A high burn rate is recommended once or twice a day to fully heat the stovepipe and chimney, which will help...

  • Page 23: Maintenance

    Ashes should NEVER be placed in wooden or plastic containers, or in paper or plastic bags, no matter how long the fire has been out. Coals within a bed of ashes can remain hot for several days once removed from the firebox. MAINTENANCE REOSOTE ORMATION...

  • Page 24: Glass

    LASS Do not operate the stove with a broken door glass. Do not abuse the fuel loading door by striking or slamming it. When necessary, the glass can be cleaned with low alkaline content commercial stove glass cleaners, which are available from your local dealer.

  • Page 25: Cast Iron

    Exterior cast iron parts are porcelainized with an enamel finish. Use a damp sponge to wipe clean. Dry the cast iron thoroughly to prevent rusting. Enamel castings can be cleaned with a standard glass cleaner. With time and use, a very fine, subtle network of crazed lines may appear seemingly beneath the surface of the enamel.

  • Page 26: Troubleshooting Guide

    ROUBLESHOOTING UIDE PROBLEM POSSIBLE CAUSE STOVE SMOKES Operating Technique Cold Chimney Blocked Chimney Oversized Chimney Undersized Chimney Chimney Too Short Air Infiltration Into The Chimney More Than One Appliance Connected to the Flue BACK-PUFFING OR Operating Technique GAS EXPLOSIONS Extra Low Burn Rate Chimney Down-draft Excessive Ash Build-up UNCONTROLLED...

  • Page 27: Replacement Parts & Optional Accessories

    & O EPLACEMENT ARTS PTIONAL PART NUMBER: DESCRIPTION: GLASS 3030-050 FUEL LOADING DOOR GLASS 3030-051 OVEN DOOR GLASS 91-58710 TOP GLASS ASSEMBLY HANDLES 91-71710 OVEN DOOR HANDLE 91-71711 FIREBOX DOOR HANDLE 91-71712 ASH DOOR HANDLE HearthStone Quality Home Heating Products Inc ® CCESSORIES PART NUMBER: 91-59710...

  • Page 28: Safety Label

    AFETY ABEL CONTACT YO UR LOCAL BUILDING Services NA, inc. SERIAL # MODEL NAME: DEVA 8220 TESTED TO: UL 1482, ULC S627 TYPE OF FUEL: Solid Wood Only CAUTION: Special methods are required when passing chimney through a wall or ceiling, refer to local building codes.

  • Page 29: Hearthstone Woodstove Limited Warranties

    HEARTHSTONE WOODSTOVE LIMITED WARRANTIES These warranties give you specific legal rights. You may also have other rights, which vary from State to State. HearthStone Quality Home Heating Products, Inc. (HearthStone) warrants to the original purchaser only (the “Original Purchaser”) the new wood burning cookstove sold by HearthStone and purchased by the Original Purchaser (the “Cookstove”) against any of the occurrences listed in this document that result from defects in material or workmanship.
  • Page 30 6. Damage due to installation of the Cookstove in an atmosphere contaminated by damaging chemicals, including but not limited to chlorine, fluorine or salts. 7. Scratches on glass, enameled surfaces or stones due to mechanical abrasion. 8. Standard wear and tear of the Cookstove resulting from normal usage over time. 9.
  • Page 31 allow a Dealer to make a service call, HearthStone or a Dealer, as the case may be, will request that the Original Owner return the defective part, or the entire Cookstove (if needed), with shipping prepaid, to HearthStone or a Dealer.
