Page 1 EP2050 Thank you for choosing Minolta. This operator’s manual explains how to operate the copier and replenish its supplies. It also gives some troubleshooting tips as well as general precautions to be observed when operating the copier. To ensure the best performance and effective use of your copier, read this manual carefully until you familiarize yourself thoroughly with its operation and features.
Page 2: Table Of Contents
Contents Chapters 1 through 3 contain the basic information for making copies. Be sure to read these chapters before attempting to use your copier. Using This Manual Organization viii Page Organization ix Terms and Symbols for the Type of Originals and Copy Paper x Chapter 1 Safety Notes 1.
Page 3: About Ep
Contents Chapter 2 First Things to Know about EP2050 1. System overview 8 2. Copier parts and Accessories Outside Your Copier 10 Inside Your Copier 12 Paper Feed Cabinet 14 Duplex Cabinet and Duplex Unit 15 Duplexing Document Feeder 16...
Page 4 Contents Chapter 3 Making Copies 1. Basic Copying Overview 38 2. Basic Copying Procedure Original Placement 40 Using Automatic/Duplexing Document Feeder 42 Image Density 48 Zoom Ratio Types of Zoom Ratio 50 Auto Size Mode 56 Zoom Ratio Table (Orignal Size to Paper Size) 58 Paper Size Manual Mode 60 Auto Paper Mode 62...
Page 5 Contents Chapter 4 Special Functions 1. Meter Count Function 128 2. Auxiliary Toner Replenishing Mode (Increasing the Image Density) 130 3. Drum Dehumidify Function 131 4. User’s Choice 132 Chapter 5 When a Warning Message Appears 1. Quick Reference for Warning Messages and Indicator Lights 144 2.
Page 6 Contents Chapter 6 Troubleshooting 1. When This Type of Copy is Produced The Image is too Light 184 The Image is too Dark 184 The Image is too Blurry 184 The Copy has Lines 186 The Copy has dark specks or spots 186 The Edge of the Copy is dirty 186 The Image on the Copy is not aligned properly 186 2.
Page 7 2. Function Combination Matrix 212 Chapter 2 3. Description of Paper Size 216 First Things to 4. Zoom Ratio Table Know about EP2050 (Original Size to Paper Size) 217 Chapter 3 5. Index 218 Making Copies Chapter 4 Special Functions...
Page 8: Using This Manual
Chapters before using your copier. Chapter 1 Safety Notes About the operating environment, conditions and precautions for use. Chapter 2 First Things to Know About EP2050 A brief description of the system and preliminary information about the different parts of the system.
Page 9: Page Organization
Using This Manual Page Organization Each page of this manual is basically organized as follows. Index: To locate your Chapter quickly. Section title 1076O298 Table of contents of the Chapter: To quickly locate your page in the Chapter. p. XX (Cross-reference): Shows the page to refer to for more detailed information.
Page 10: Terms And Symbols For The Type Of Originals And Copy Paper
Using This Manual Terms and Symbols for the Type of Originals and Copy Paper A few special terms and symbols are used in this manual to designate types of originals and copy paper. These two pages explain about these terms and symbols.
Page 11 Using This Manual "Width" and "Length" When we talk about the size of the original or copy, we call side A "width" and side B "length." A: Width B: Length 1139O1610A Terms and Symbols Used <Lengthwise > When the original or copy has a "length"...
Page 13: Chapter 1 Safety Notes
Chapter 1 Safety Notes This Chapter explains about the operating environment, conditions, and precautions for use. 1. Installing the Copier Installation Site 2 Power Source 2 Grounding 2 Space Requirements 3 2. Precautions for Use Operating Environment 4 Using the Copier Properly 4 Care of Copier Supplies 4 Moving 5...
Page 14: Installing The Copier
1. Installing the Copier Installation Site To ensure utmost safety and prevent possible malfunctions of the copier, install it in a location which meets the following requirements. A place away from a curtain or the like that may catch fire and burn easily. An area where there is no possibility of being splashed with water or other types of liquid.
Page 15: Space Requirements
1. Installing the Copier Space Requirements To ensure easy copier operation, supply replacements and service maintenance, adhere to the recommended space requirements detailed below. NOTE Be sure to allow a clearance of 150 mm or more at the back of the copier as there is a ventilation duct.
Page 16: Precautions For Use
2. Precautions for Use Operating Environment The operating environmental requirements of the copier are as follows. Temperature : 10°C to 30°C (50°F to 86°F) with a fluctuation of 10°C (50°F) per hour Humidity : 15% to 85% with a fluctuation of 20% per hour Using the Copier Properly To ensure the optimum performance of the copier, follow the precautions listed below.
Page 17: Care Of Copier Supplies
1. Precautions for Use Care of Copier Supplies Use the following precautions when handling the copier supplies (toner, paper, etc.). Store paper, toner, and other supplies in a place free from direct sunlight and away from any heating apparatus. Keep them in a dry, clean environment. Store paper, which has been removed from its wrapper but not loaded into the Drawer, in a sealed plastic bag in a cool, dark place.
Page 19 Chapter 2 First Things to Know about EP2050 This Chapter gives you a brief description of the system and preliminary information about the different parts of the system. 1. System Overview 8 2. Copier Parts and Accessories Outside Your Copier 10...
Page 20: System Overview
1. System Overview The EP2050 system can be configured with the following components. Automatic Document Feeder AF-3 <Option> Permits automatic feeding of multiple originals. p. 42 1139O0010A Sorters <Option> 10-Bin Sorter S-104/20-Bin Sorter S-205 Permits sorting or grouping copies into up to 10 or 20 copy sets or stacks.
Page 21 20 1136O061AA EP2050 Equipped with two Paper Drawers to hold up to 500 sheets of copy paper (80 g/m ). The Multi Bypass Table allows you to make up to 50 copies on paper which is not loaded in any of the Drawers and which is fed into the copier automatically via this Table.
Page 22: Copier Parts And Accessories
2. Copier Parts and Accessories Outside Your Copier EP2050 1136O063AA Control Panel : Use to start a copy cycle or to make copying-job settings. p. 22 Original Cover : Holds the original placed on the Original Glass in <Option> position. To place an original, raise the Cover and place it in position on the Original Glass.
Page 23: Left Door
2. Copier Parts and Accessories 1136O064AA Copy Tray Extender : Slide this Extender out when making copies on large-size paper. 10 Exit Tray : Holds copies fed out of the copier. 11 Left Door : Open for clearing a paper misfeed. p.
Page 24: Inside Your Copier
2. Copier Parts and Accessories Inside Your Copier EP2050 1136O065AA Toner Bottle : Contains toner. Replace it with a new one when the Add Toner Indicator lights up. p. 146 Toner Bottle : Swing open to replace the Toner Bottle.
Page 25 2. Copier Parts and Accessories 1136O066AA Display Contrast : Use to adjust the brightness of the Message Control Knob Display. Dehumidifier : Turn ON to prevent condensation from forming on Switch the PC Drum when power is turned OFF. Corona Unit : Operate the Lever to clean the corresponding Cleaning Lever Corona Unit if unwanted lines are produced on the...
Page 26: Paper Feed Cabinet
2. Copier Parts and Accessories Paper Feed Cabinet PF-102 and PF-202 1136O168AA 1136O168AA 3rd Drawer (PF-202) : Holds up to 500 sheets of paper. p. 150 4th Drawer (PF-202) : Holds up to 500 sheets of paper. p. 150 3rd Drawer (PF-102) : Holds up to 2,500 sheets of paper. p.
Page 27 2. Copier Parts and Accessories Duplex Cabinet PF-2D and Duplex Unit AD-5 1139O1252A Middle Left Door : Open to clear a paper misfeed. pp. 167, 176 Misfeed Removal : Open to clear a paper misfeed. Guide Plate pp. 167, 176 Duplex Unit : Turns over 1-sided copies for making 2-sided copies.
Page 28: Duplexing Document Feeder
2. Copier Parts and Accessories Duplexing Document Feeder AFR-7 1139O1060A Document Exit : Receives originals that are automatically ejected Tray from the AFR-7. Document Feed : Load the originals face up on this tray. p. 43 Tray Document Guide : Slide the plates as necessary to the size of the Plates originals.
Page 29: Automatic Document Feeder
2. Copier Parts and Accessories Automatic Document Feeder AF-3 1139O1070A Document Exit : Receives originals that are automatically ejected Tray from the AF-3. Document Feed : Load the originals face up on this tray. p. 43 Tray Document Guide : Slide the plates as necessary to the size of the Plates originals.
Page 30 2. Copier Parts and Accessories Staple Sorter ST-206 and 20-Bin Sorter S-205 1136O077AA 1136O069AA Non-Sort Bin : Holds up to 100 copies. p. 88 Sort Bins (1st to : Hold sorted or grouped copies, each capable of 20th Bin) holding up to 50. p.
Page 31 2. Copier Parts and Accessories Staple Sorter ST-101 and 10-Bin Sorter S-104 1139O1080A Sort Bins : Hold sorted or grouped copies. The Top Bin is capable of holding up to 50 copies and each of the 2nd to 10th Bins up to 25 copies, a maximum of 275 copies.
Page 32: Data Controller
2. Copier Parts and Accessories Data Controller D-102 1074O203 LCD Display : Shows a variety of data according to the card being used. Card Insertion Slot Card : There are six different types of cards available. Use the right one according to your specific purpose. NEXT Key : Press to go to the next or previous screen.
Page 33 2. Copier Parts and Accessories...
Page 34: Control Panel Keys And Indicators Basic Panel
3. Control Panel Keys and Indicators Basic Panel Auto Count Mixed Manual Orng. Even Steple Detect # of Origs. 2in1 2in1 Sort Auto Sort Hole 2in1 Staple Punch Exposure Group 2in1 Lighter Darker Finishing Orig. Copy Clip Tray: Use this tray to put the paper clip used with the documents. System Panel: See the other pages in this manual.
Page 35 3. Control Panel Keys and Indicators Zoom Paper x0.5~x2.0 Reduce Full size Enlarge Auto Select 1136P250DA 21 20 19 18 1136P250DA Clear Key: Press to clear the number of copies and other settings. Panel Reset Key: Press to set the copier into the initial mode, clearing all settings made previously on the control panel.
Page 36: System Panel
3. Control Panel Keys and Indicators System Panel Auto Count Mixed Manual Orng. Even Steple Detect # of Origs. 2in1 2in1 Sort Auto Sort Hole 2in1 Staple Punch Exposure Zoom Paper Group 2in1 Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Finishing Orig.
Page 37 3. Control Panel Keys and Indicators...
Page 38: Supplementary Panel
3. Control Panel Keys and Indicators Supplementary Panel Zoom Auto Size Memory Memory Input Meter Count Cover Erase 1 Inter- (Front) leaving Auto Erase 2 Page Cover Insertion (Front Back) & Erase 3 Toner Book Margin 1 Exposure Zoom Lighter Darker x0.5~x2.0 Erase 4...
Page 39 3. Control Panel Keys and Indicators 10 Select Key : Press to select a function shown on the Message Display. 11 File Margin Mode : Press to set the copier into the File Margin Mode. p. 103 12 Book Mode Key : Press to set the copier into the Book Copy Mode.
Page 40: Display Panel
3. Control Panel Keys and Indicators Display Panel Auto 1136P253CA 12 11 10 9 Monitor Display Paper Source Indicator: Shows the Drawer which is currently selected for use. p. 61 It also lights up when a 1-sided copy is stored in the Duplex Unit.
Page 41 3. Control Panel Keys and Indicators Call-Technical- : Indicates that the copier has developed a Representative malfunction. Indicator When a malfunction occurs, the 1136P56OAA corresponding malfunction code is shown on the Message Display. p. 145 Maintenance Call : Indicates when a regularly scheduled Indicator: preventive maintenance call becomes necessary.
Page 42: Turning On And Off And Resetting The Copier
4. Turning ON and OFF and Resetting the Copier Turning ON and OFF Turning Copier ON ..Press the Power Switch to the " " position. 1136O070AA Turning Copier OFF ..Press the Power Switch to the " " position. 1136O071AA...
Page 43: When Copier Is Turned On
4. Turning ON and OFF and Resetting the Copier When Copier is Turned ON ... The Wait Indicator lights up on the Display Panel of the control panel indicating that the copier is now warming up. Auto Count Mixed Manual Orng.
Page 44: Auto Copy Start Function
4. Turning ON and OFF and Resetting the Copier Auto Copy Start Function The Auto Copy Start Function allows a copy process to be started as soon as the copier completes warming up. Using the Function Place the Original onto the Original Glass or in the Document Feeder.
Page 45: Energy Saver Mode
4. Turning ON and OFF and Resetting the Copier Energy Saver Mode If the copier is shut down when it is not in use, it takes the copier a maximum of 2 minutes and 30 seconds to complete the warm-up cycle. Instead of turning the copier OFF, it is a good idea to use the Energy Saver Mode.
Page 46: Initial Mode And Panel Resetting
4. Turning ON and OFF and Resetting the Copier Initial Mode and Panel Resetting Initial Mode When the Power Switch is turned ON, the initial settings are indicated on the control panel. The initial settings serve as the reference for all control panel settings to be later made.
Page 47: Auto Reset Function
4. Turning ON and OFF and Resetting the Copier Panel Resetting The Panel Reset Key resets all control panel settings to initial mode including the number of copies to be made and zoom ratio. If Automatic/Duplexing Document Panel Reset Feeder AF-3/AFR-7 is used, the original present on the Original Glass will be ejected out of the unit.
Page 48: Entering The Access Number
4. Turning ON and OFF and Resetting the Copier Entering the Access Number. If "Copy Track" of the Administrator function of the User’s Choice has Enter Access #: been set to "YES," the access number assigned for your own department must be entered before you can make a copy.
Page 49: Chapter 3 Making Copies
Chapter 3 Making Copies This Chapter shows you how to make copies using the basic, system and supplementary functions. The Basic Copying Overview is on p. 38 The System Copying Overview is on p. 72 The Supplementary Copying Overview is on p. 96 These pages offer quick, at-a-glance instructions for making copies.
Page 50: Basic Copying Overview
1. Basic Copying Overview Placing the Original Setting the Image Selecting the Zoom Density Ratio Raise the Original Cover Select the Auto Exposure Select the Auto Size Mode. and place the original face Mode. p. 49 p. 56 down on the Original Auto Glass.
Page 51 1. Basic Copying Overview Setting the Number Starting the Copy Selecting the Copy of Copies Cycle Paper Size Using the Multi-Copy Press the Start Key to start Select the Auto Paper Keys, set the number of the copy cycle. Mode. p.
Page 52: Basic Copying Procedure
2. Basic Copying Procedure Placing Originals Place the original face down on the Original Glass. Different methods are used to load the originals depending on the type of originals and whether the copier is equipped with an Automatic/Duplexing Document Feeder AF-3/AFR-7 (option). Sheet Originals (Standard Size) Raise the Original Cover.
Page 53 2. Basic Copying Procedure Book Original *"Book original" refers to an open bound original. Position the higher-numbered page on the Original Width Scale end. If the book is thick, you can make copies with the Original Cover raised. NOTES Not positioning an open book properly will result in copies 1134O037AA with pages in incorrect order.
Page 54 2. Basic Copying Procedure Using the Automatic/Duplexing Document Feeder AF-3/AFR-7 The Automatic/Duplexing Document Feeder AF-3/AFR-7 automatically feeds sheet originals placed on the Document Feed Tray one by one. After the copy cycle has been completed, they automatically eject the original onto the Document Exit Tray.
Page 55 2. Basic Copying Procedure Loading the Standard Size Originals Swing the Document Exit Tray Sheet Original to the left as shown. Place a neat stack of originals face up on the Document Feed Tray, and then slide the Document Guide Plates to the size of the originals.
Page 56 2. Basic Copying Procedure Loading Originals of Assorted Sizes (Using the Mixed Original Detection Mode) You can load originals of different widths and lengths in the Auto Count Mixed Manual Orng. Even Steple Detect AF-3/AFR-7 and make copies # of Origs. automatically (Auto Paper, Auto Size) 2in1 Sort...
Page 57 2. Basic Copying Procedure Swing the Document Exit Tray back again and pull out the Document Exit Tray Extender. 1139O0100A Press the Mixed Original Auto Count Detection Mode Key. Mixed Manual Orig. Even Staple Detect This completes the setting procedure. Now, make your copies by following the steps given in "Basic Copying Overview"...
Page 58 2. Basic Copying Procedure For Originals Not Suitable for Reliable Operation on the AF-3/AFR-7 Raise the AF-3/AFR-7 and place Original Positioning Plate the original face down on the Original Glass. Align the rear left corner of the original with the marker on the Original Width Scale.
Page 59 2. Basic Copying Procedure...
Page 60: Image Density
2. Basic Copying Procedure Image Density Auto Exposure Zoom Paper Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select 1136P273DA The image density level of copies can be adjusted either in the Auto or Manual Exposure Mode. Select the appropriate mode according to your particular needs.
Page 61 2. Basic Copying Procedure Selecting the Exposure Mode Auto Exposure Mode Press the Auto Exposure Mode Auto Key A as necessary to light up the Auto Exposure Indicator Exposure Auto . Lighter Darker Each time the Auto Exposure Mode Key A is pressed, the Manual and Auto Exposure Mode are selected alternately.
Page 62: Types Of Zoom Ratio
2. Basic Copying Procedure Zoom Ratio Auto Exposure Zoom Paper Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select 1136P273DA The zoom ratio will be set automatically by the copier when in the Auto Size Mode or can be set manually by the operator when in the Manual Mode. Select the appropriate mode according to your needs.
Page 63: Auto Size Mode
2. Basic Copying Procedure Zoom Memory You may want to store frequently used zoom ratios in memory and call Select Zoom#: >1:<X1.000> one up from memory as necessary for 2:<X0.930> use in your copying job. Zoom Up to two different zoom ratios can Memory Memory Input...
Page 64 2. Basic Copying Procedure Selecting the Fixed Zoom Ratios Press the Reduction, Full Size, or Reduce Full size Enlarge Enlargement Key to select a fixed zoom ratio of your choice. 1136P285CA 1136P285CA <Reduction> B4-A4 A3-A4 Each time the Reduction Key is Auto Auto B5-A5...
Page 65 2. Basic Copying Procedure Setting a Zoom Ratio Hold down the Zoom Down Key until the desired zoom AUTO ratio is reached. X1.500 Zoom Down Key makes the Zoom Paper ratio smaller x0.5~x2.0 Zoom Up Key makes the ratio greater 1136P445CA 1136P445CA Zoom range: 0.500 to 2.000...
Page 66 2. Basic Copying Procedure Storing a Zoom Ratio Press the Memory Input Key. Both the Job Memory Select Key LED and Zoom Memory Input Select Key LED start blinking. 1136P290CA 1136P290CA Press the Zoom Memory Select Key. Zoom Then, the Zoom Memory Select Memory Key LED lights up, while the Job Memory Select Key LED...
Page 67 2. Basic Copying Procedure Using the Multi-Copy Keys, enter the desired zoom ratio. Zoom ratio setting range: From 0.500 to 2.000 Press the Enter Key. The initial screen reappears on the Message Display. 1136P429AA At this time, the set zoom ratio 1136P429AA has been stored in the specified memory location.
Page 68 2. Basic Copying Procedure Auto Size Mode In the Auto Size Mode, the copier automatically selects the correct zoom ratio according to the original size and copy paper size. Selecting the Auto Size Mode Flip open the System Panel. 1136O088AA Press the Auto Size Mode Key.
Page 69 2. Basic Copying Procedure Select the copy paper size. p. 60 M FEED Auto Select 1136P298CA 1136P298CA Useful Tip This mode is very helpful for neat filing when you need to make copies from originals of assorted sizes. NOTES The message shown on the left appears under any of the following conditions: The original has been placed on...
Page 70: Paper Size
2. Basic Copying Procedure Zoom Ratio Table (Original Size to Copy Paper Size) Metric Size Inch Size Copy Copy Original Size Zoom Ratio Original Size Zoom Ratio Paper Size Paper Size 0.707 11" 17" 11" 14" 0.823 0.500 Legal 0.772 420 mm 279.4 431.8 mm...
Page 71 2. Basic Copying Procedure...
Page 72: Manual Mode
2. Basic Copying Procedure Copy Paper Size Auto Count Mixed Manual Orng. Even Steple Detect # of Origs. 2in1 2in1 Sort Auto Sort Hole 2in1 Staple Punch Exposure Zoom Paper Group 2in1 Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select Finishing Orig.
Page 73 2. Basic Copying Procedure Paper Source Indicator and Copy Paper Size Indicators Example: The copier is loaded with paper as follows: 1st Drawer ... A4L 2nd Drawer ... B4L 3rd Drawer (Option) ... A3L 4th Drawer (Option) ... FLS.L Multi Bypass Table ... A3L 1136P541CA 1136P541CA Each time the Paper Select Key is pressed, the lights on the Paper Size Indicator...
Page 74: Auto Paper Mode
2. Basic Copying Procedure Auto Paper Mode In the Auto Paper Mode, the copier automatically selects the correct copy paper size according to the original size and zoom ratio selected for use. Selecting the Auto Paper Mode Press the Auto Paper Mode Key. Then "Auto"...
Page 75 2. Basic Copying Procedure NOTES If the paper of the right size has run out in the Auto Paper Mode, the message shown on the left appears. Load paper: If this happens, add the right size paper, or cancel the Auto Paper X1.000 Mode and use the Manual Mode to 1136P305CA...
Page 76: Special Paper Mode
2. Basic Copying Procedure Special Paper Mode If S1, S2, or S3 appears after the paper size on the Message Display when the Paper Select Key is pressed, M FEED it means that the Drawer loaded with Auto Select that paper has been set for special paper loading.
Page 77 2. Basic Copying Procedure...
Page 78: Number Of Copies
2. Basic Copying Procedure Number of Copies Setting the Number of Copies Using the Multi-Copy Keys, enter the number of copies to be made. The maximum number that can be set is 99. 1139O2640A Example: To make 18 copies, press Key , in that order.
Page 79: Copy Cycle Start
2. Basic Copying Procedure Starting the Copy Cycle Auto Exposure Zoom Paper Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select 1136P273DA Starting the Copy Cycle Check the control panel to make sure that you have set up your copy job correctly. Press the Start Key, if it is green.
Page 80: Interrupt Mode
2. Basic Copying Procedure Interrupt Mode Auto Exposure Zoom Paper Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select 1136P273DA The Interrupt Mode allows you to interrupt a current job and run a different one. The copier ensures that the previous job will be resumed as soon as the Interrupt Mode is canceled.
Page 81 2. Basic Copying Procedure Ending the Interrupt Mode Press the Interrupt Key again. Interrupt The Interrupt Key light goes out and the copier is restored to the previous settings. 1139O2612A 1139O2612A NOTES The Interrupt Mode cannot be canceled by the Panel Reset Key or Clear Key. If the current job involves the Sort, Group, or Sort-and-Staple Mode, only Non-Sort mode can be selected in the Interrupt Mode.
Page 82: Multi Bypass Copying
2. Basic Copying Procedure Multi Bypass Copying Use the Multi Bypass to make copies on paper not loaded in any of the Drawers or to copy onto transparencies, translucent paper, or any other special paper. You can also use the Cover Mode when the Multi Bypass Table is used with the Automatic/Duplexing Document Feeder AF-3/AFR-7 (option).
Page 83 2. Basic Copying Procedure Place a neat stack of copy paper on the Table and insert it into the copier until it stops. NOTES Before inserting, fan the paper stack well if you are using transparencies or 1139O0140A translucent paper. Correct any curl if you are using heavyweight paper.
Page 84: System Copying Overview
3. System Copying Overview Making the Selecting the Original Copy Type Basic Settings Place the original. Select the Orig. Copy Type I. p. 80 p. 40 2in1 Set the image density. p. 49 2in1 Set the zoom ratio. p. 50 2in1 Select the copy 2in1...
Page 85: Copy Cycle
3. System Copying Overview Selecting the Finishing Mode Starting the Copy Cycle Select the Sorter mode. p. 90 Press the Start Key to start the copy cycle. p. 67 Sort Sort Hole Staple Punch Group Finishing 1136P311CA Select the Hole Punch mode. p.
Page 86: Original Copy Type
4. System Job Setting Original Copy Type Eight specific types are grouped into Auto Count two categories as follows: Mixed Manual Orng. Even Steple Detect Type I # of Origs. 1-sided 1-sided 1-sided 2-sided 2in1 2-sided 1-sided 2-sided 2-sided 2in1 Sort Type II Sort...
Page 87 4. System Job Setting 1-sided 2-sided Originals Copy Select 1 2 to make 2-sided copies from 1-sided originals. NOTE The copier has to know whether it needs to make the odd-page 1136P426AA 1136P205AA correction depending on the number of originals you have, either even or odd.
Page 88 4. System Job Setting Type II 2-in-1 copy: 2-in-1 functions The copier copies, through reduction, the 1-sided originals 2-in-1 copy texts/images of two different originals onto one side of a single sheet of paper. This saves paper. 1136P208AA 2-in-1 separation copy: 2-in-1 original 1-sided copy The copier copies, through enlargement,...
Page 89 4. System Job Setting 1-sided 2-sided [2-in-1] Originals Copy <2-sided 2-in-1 copy> Select 1 2[2in1] to make a 2-sided 2-in-1 copy. The copier copies, through reduction, the texts/images of four different originals onto both sides of 1136P210AA 1136P210AA a single sheet of paper, each side containing the texts/images of two different originals.
Page 90 4. System Job Setting 1-sided [2-in-1] 1-sided Copies Original <2-in-1 separation copy> Select 1[2in1] 1 to make 1-sided page-by-page copies of a 1-sided original which is the result of 2-in-1 copying. 1136P211AA 1136P211AA The copier copies, through enlargement, the texts/images of a 1-sided original which is the result of a 2-in-1 copy onto one side of two separate sheets of paper, each copy...
Page 91 4. System Job Setting...
Page 92 4. System Job Setting Selecting the Original Copy Type Type I Press the Orig. Copy Type I 2in1 Select Key to select your choice. 2in1 Each time the Orig. Copy Type I Select Key is pressed, 2in1 the newly selected type 2in1 indicator lights as shown.
Page 93: Type Ii
4. System Job Setting Type II Press the Orig. Copy Type II 2in1 Select Key to select your choice. 2in1 Each time the Orig. Copy Type II Select Key is pressed, 2in1 the newly selected type 2in1 indicator lights as shown below. Orig.
Page 94: Original Count Mode
4. System Job Setting Original Count Mode If you have an odd number of originals in 1 2, 1 1[2in1], or 1 2[2in1], some inconvenient situations result in page organization of your output copies. The copier provides the Original Count Mode in which it counts the number of originals loaded in the AFR-7 to determine whether it needs to make the odd-page correction.
Page 95 4. System Job Setting Using the Original Count Mode Select the Orig. Copy type. p. 80 2in1 Press the Original Count Mode 2in1 Key to select the appropriate function according to the number of originals you have. Orig. Copy If you do not know how many 1136P320CA 1136P320CA originals you have, select "Auto...
Page 96 4. System Job Setting Procedure for Loading Originals Use the following procedure for loading Originals to make 1-sided copies from 2-sided originals. Load the originals crosswise. If the originals are loaded lengthwise, the directions of the copy images will be mixed up. Correct: 2-Sided Originals 1-Sided Copies...
Page 97 4. System Job Setting Panel Display in 2-Sided Copying The copier starts a 2-sided copying cycle when you select a mode to make 2-sided copies (i.e., 1 2 or 2 2) and press the Start Key. On completing the first copy cycle, the copier stores the 1-sided copy in the Duplex Unit, getting ready to run the second copy cycle.
Page 98: Finishing Modes
4. System Job Setting Finishing Modes There are six different finishing Auto Count Mixed modes: Manual Orng. Even Steple Detect Non-Sort, Sort, Sort-and-Staple, # of Origs. Group, Hole Punch, and Manual 2in1 Staple. 2in1 Sort Select the appropriate mode Sort Hole 2in1 Staple...
Page 99 4. System Job Setting In the Group Mode, the copies made Group Copies from each single original are Originals separated into groups. Each group 1st Bin Copies contains multiple copies of the same originals. 2nd Bin Copies 3rd Bin 1076O147 This mode allows you to have holes Hole Punch Copies...
Page 100: Auto Dual Function
4. System Job Setting Auto Dual Function Each of the Sorter Bins holds up to 50 ( 25) sheets of paper. However, the Auto Dual Function allows sorting of copies of up to 100 ( 50) originals under certain conditions. NOTE The descriptions on this and the following pages is that for the S-205 and ST-206.
Page 101 4. System Job Setting Auto Dual Function in Sort-and-Staple Mode When 10 ( 5) or less copies are made from an original set consisting of more than 50 ( 25) originals in the Sort-and-Staple Mode, and the Auto Dual Function is activated, the Sort-and-Staple Mode is automatically switched to the Sort Mode (no stapling takes place).
Page 102: Selecting The Finishing Mode
4. System Job Setting Selecting the Finishing Mode Selecting the Sort, Sort-and-Staple, Group, or Hole Punch Mode Press the Finishing Mode Select Key or Hole Punch Mode Key to select the Sort desired mode. Sort Hole Staple Punch Each time the Key is pressed, the Group newly selected indicator lights.
Page 103 4. System Job Setting To use as a Stapler: 20-Bin Staple Sorter Stack the sheets of paper neatly. Non-Sort Bin For ST-206 Insert the stack of paper between Sort Bins 1136O104AA the Non-Sort Bin and 1st Bin of the Staple Sorter. 20-Bin Staple Sorter Non-Sort Bin For ST-101...
Page 104 4. System Job Setting Instructions for Loading Originals for Stapling If you want to staple copy sets or stacks automatically in the Sort-and-Staple Mode or manually in the Manual Staple Mode, position the originals crosswise (face up). The originals should also be placed so that the stapling position (marked with ) is positioned as shown.
Page 105 4. System Job Setting...
Page 106: Typical Finishing Mode
4. System Job Setting Typical Finishing Mode Finishing Manual Examples Mode Stapling Example: Making two copies each. Original Set Copy Stack Non-Sort Impossible 1076O154 Example: Sorting copies into 2 copy sets and having them Example: stapled manually. Manual Stapling Copy Sets Original Set Sort Possible...
Page 107 4. System Job Setting Finishing Manual Examples Mode Stapling Example: Sorting and stapling copies into 2 copy sets. Stapled Copy Sets Original Set Sort-and- Staple Impossible 1140O077 Example: Sorting or separating copies into 2 sets/stacks, Sort Example: punching holes in them and then having each Example: stapled manually.
Page 108: Supplementary Copying Overview
5. Supplementary Copying Overview Making the Selecting Selecting Selecting Basic and the Erase the Margin the Book System Job Mode Mode Mode Settings Place the p. 100 p. 103 p. 107 original. p. 40 Set the image density. p. 49 Set the zoom Erase 1 ratio.
Page 109: Using Ohp Interleaving
5. Supplementary Copying Overview Selecting Selecting Selecting Starting the the Job the Cover Insertion Copy Cycle Program Mode Mode Memory p. 110 Using Page Press the Start Calling Up a Key to start the Program Insertion copy cycle. p. 126 pp.
Page 110: Supplementary Function Setting
6. Supplementary Function Setting Erase Mode The copier provides a margin of a set width Zoom Auto Size Memory Memory along the four edges, one edge, or at the Input Meter center to erase shadows or other unwanted Count Cover Erase 1 Inter- (Front)
Page 111 6. Supplementary Function Setting Erase 3 <Frame Erase> Copy Original (Fax Output) The copier erases a set width along the four edges. This feature is effective, for example, when making a copy from a document received by fax. The erase width is 10 mm. 1136P215AA 1136P215AA Erase 4 <Center Erase>...
Page 112 6. Supplementary Function Setting Selecting a Particular Erase Function Press the Erase Mode Key to Cover Erase 1 Inter- (Front) leaving select the desired erase function. Erase 2 Page Cover Insertion (Front Back) & Each time the Key is pressed, a Margin 1 Erase 3 Book...
Page 113: Erase
6. Supplementary Function Setting Loading the Originals in Erase Mode Erase Mode On Original Glass Using AF-3/AFR-7 Erase 1 Punch Hole Erase I 1136O120AA 1136O116AA Erase edge on the right. Erase edge on the left. Erase 2 Punch Hole Erase II 1136O121AA 1136O117AA Erase edge in the rear.
Page 114: File Margin
6. Supplementary Function Setting File Margin Mode The copier provides a file margin along the Zoom Auto Size Memory Memory trailing edge on the copy for your easy filing. Input Meter Count There are two different ways available for Cover Erase 1 Inter- (Front)
Page 115 6. Supplementary Function Setting Selecting a Particular Margin Function Press the File Margin Mode Key Margin 1 to select the desired margin function. Margin 2 Each time the Key is pressed, the newly selected indicator lights. 1136P336CA 1136P336CA Margin 1 Margin 2 None of Two LEDs Light Up.
Page 116 6. Supplementary Function Setting NOTE Having a margin width larger than necessary in Margin 1 <Shift-for-Margin> could result in part of the image missing on the copy. Try to keep a logical margin width. Loading the Originals in Margin Mode On Original Glass Using the AF-3/AFR-7 1136O127AA...
Page 117 6. Supplementary Function Setting...
Page 118: Book
6. Supplementary Function Setting Book Mode You may want to fit each page of an open Zoom Auto Size Memory Memory book onto a separate sheet. Input Meter Count The copier provides two different Book Cover Erase 1 Inter- (Front) leaving functions to choose from.
Page 119 6. Supplementary Function Setting Selecting a Particular Book Function Press the Book Mode Key to select Book the desired book function. Each time the Key is pressed, a new Book book function is selected, as indicated by a lit LED. This completes the setting of the Book Mode.
Page 120: Cover
6. Supplementary Function Setting Cover Mode Cover Mode lets you make a front cover or a Zoom Auto Size Memory Memory front and back cover for a copy set by Input Meter Count copying the first page or the first and last Cover Erase 1 Inter-...
Page 121 6. Supplementary Function Setting Cover (Front&Back) Copy Set Original Set <Copied Cover> Cover The first and last pages of the original set are copied onto a different type of paper. Cover 1136O130AA Original Set Copy Set with Cover (Front&Back) Separate Front <Non-copied Cover>...
Page 122: Input The Number Of Originals
6. Supplementary Function Setting Using the Cover Mode Cover (Front) Press the Cover Mode Key to select the desired cover function. Cover (Front Back) & The message "Copy an image on the Cover?" appears on the Message Display. 1136P343CA 1136P343CA Press the Select Key to select Copy an image on whether you want to copy...
Page 123 6. Supplementary Function Setting Steps for Copier with AFR-7 (Auto # of originals: Count) Auto Count 10-key Input 1136P398CA Press the Select Key as necessary to select the desired original count mode and then press the Enter Key. Auto Count: Go to step 5 and Auto Count: onward on this Auto Count:...
Page 124 6. Supplementary Function Setting Steps for Copier with AF-3 (10-Key Input the number Input) of originals : 1136P399CA Using the Multi-Copy Keys, enter the number of originals you have. 1136P185AA 1136P185AA Press the Enter Key. The initial screen reappears on Display the Message Display and this completes the setting.
Page 125 6. Supplementary Function Setting...
Page 126 6. Supplementary Function Setting Insertion Mode You may at times need to make a number of copies each from several different originals. Zoom Auto Size Memory Memory Input Page Insertion allows you to insert a blank Meter Count sheet of paper (colored paper) between the Cover Erase 1 Inter-...
Page 127 6. Supplementary Function Setting Specifying the Place for Insert In the Page Insertion mode, you must specify where to place an insert. Two ways are available to specify the insert places, either Auto Detection or 10-Key Input. Original Set Copy Set Auto Detection Put a sheet of paper of a size different Insert Setting...
Page 128 6. Supplementary Function Setting OHP Interleaving Copies <Copied Interleaves> Single Copy: Copied The copier copies on OHP Originals Interleaves transparencies and, between each pair (Copy of transparencies, inserts a copied Multi-Copy Paper) copy paper. Entry: 1 1136O136AA Copy Sets Multiple Copy <Only when the copier is equipped Original Set with an ST-206 or S-205>:...
Page 129 6. Supplementary Function Setting Copy Sets OHP Interleaving <Non-Copied Interleaves> Single Copy: Original Set The copier copies on OHP Non-Copied transparencies and, between each pair Interleaves of transparencies, inserts a non-copied copy paper, i.e., a blank sheet of paper. 1136O138AA Copy Sets Multiple Copy <Only when the copier is equipped...
Page 130 6. Supplementary Function Setting Using Page Insertion <Auto Detection> Press the Insertion Mode Key to select Page Insertion. Inter- leaving The Message Display then asks Page Insertion you if you want a copied insert. Press the Select Key as necessary to select whether you want a 1136P347CA 1136P347CA...
Page 131: Insertion
6. Supplementary Function Setting Load the original set containing Insert Setting insert setting paper onto the Paper AFR-7. Original Placement p. 43 Press the Start Key to let the copier start the original count 1136O141AA sequence. The AFR-7 starts feeding the originals loaded onto it to detect the place for inserts.
Page 132 6. Supplementary Function Setting Using Page Insertion <10-Key Input> Press the Insertion Mode Key to select Page Insertion. Inter- leaving The Message Display then asks Page Insertion you if you want a copied insert. Press the Select Key as necessary to select whether you want a copied insert ("YES") or not 1136P347CA...
Page 133 6. Supplementary Function Setting Using the Multi-Copy Keys, Insert before enter the page number of the Sheet Original original before which you want an insert. # 1. Example: 1136P387CA To place an insert between pages 2 and 3, press Key 3. Insert If you need to correct the number, press the Clear Key,...
Page 134 6. Supplementary Function Setting Using OHP Interleaving Press the Insertion Mode Key to select OHP Interleaving. Inter- leaving The Message Display then asks Page you if you want a copied Insertion interleaf. 1136P350CA 1136P350CA Copy an image on the OHP insert? 1136P442CA Press the Select Key as necessary to select whether you want a...
Page 135 6. Supplementary Function Setting If you want to run a multi-copy cycle using OHP Interleaving, enter the required number of copies using the Multi-Copy Key or Keys. NOTE A multi-copy cycle of OHP 1136P192AA Interleaving is not possible on a copier system equipped with an ST-101.
Page 136: Job Program Memory
6. Supplementary Function Setting Job Program Memory Frequently used copying jobs can be programmed and stored in memory and Zoom Auto Size Memory Memory Input recalled as necessary. Meter Count Up to five (*ten) different jobs can be Cover Erase 1 Inter- (Front) leaving...
Page 137: Job Memory
6. Supplementary Function Setting Storing a Job Program in Memory Make the necessary control panel settings for the job to be stored in memory. Input Press the Memory Input Key. The Job Memory LED and Zoom Memory LED on the Supplementary Panel start 1136P290CA 1136P290CA...
Page 138 6. Supplementary Function Setting To recall the Job Press the Job Memory Select Key on the control panel. Zoom A screen appears on the Memory Memory Message Display to allow you to call up a program from the memory. 1136P351CA 1136P351CA Press the Select Key as necessary Select Job # :...
Page 139: Chapter 4 Special Functions
Chapter 4 Special Functions This Chapter explains about the special functions that can be used for specific purposes. 1. Meter Count Function 128 2. Auxiliary Toner Replenishing Mode (Increasing the Image Density) 130 3. Drum Dehumidify Function 131 4. User’s Choice 132...
Page 140: Meter Count Function
1. Meter Count Function Zoom Auto Size Memory Memory Input Meter Count Cover Erase 1 Inter- (Front) leaving Auto Page Cover Erase 2 Insertion (Front Back) & Toner Margin 1 Erase 3 Book Exposure Zoom Paper Lighter Darker x0.5~x2.0 Book Margin 2 Erase 4 Reduce Full size Enlarge...
Page 141 1. Meter Count Function Using the Meter Count Function Press the Meter Count Key once. The Message Display shows the counts of the Total and Size Meter Count Counters. Press the Meter Count Key a second time. Then, the counts of the 2-Sided 1136P353CA 1136P353CA Total and 2-Sided Size Counters...
Page 142: Auxiliary Toner Replenishing Mode (Increasing The Image Density)
2. Auxiliary Toner Replenishing Mode (Increasing the Image Density) The copier tends to exhaust the supply of Zoom Auto Size toner rapidly when making a number of Memory Memory Input copies from an original with dark solid areas. Meter Count As a result, the image density of the copy Cover Erase 1...
Page 143: Drum Dehumidify Function
3. Drum Dehumidify Function During high humidity periods or when there Zoom Auto Size Memory Memory are sudden rapid changes in humidity Input (especially when you are using a heater in Meter Count winter), condensation could form on the Cover Erase 1 Inter- (Front)
Page 144: User's Choice
4. User’s Choice The copier has been set so that the 2in1 Security Language most frequently used settings are Book Mode Mode Select 2in1 Separation automatically selected in the Custom initial mode. Auto Exp. Copy Mode Energy Level Priority Saver Mode The User’s Choice allows you to Counter Manual Exp.
Page 145: Language Select
4. User’s Choice Description of Each User’s Choice Function Language Select Selects the language of the Message Display. Language Select: Language Select: Language Select: German English Italian Spanish Danish Swedish French Dutch Portug. Norweg 1136P438CA 1136P438CA The initial setting is German. Mixed Orig.
Page 146: Paper Priority
4. User’s Choice Paper Priority Specifies the paper port selected automatically when the copier is set into either the Auto Size Mode or Manual Mode. 1st Drawer 4th Drawer Paper Pr. 2nd Drawer Blank 3rd Drawer 1136P544CA The initial setting is "1" (1st Drawer). Exposure Priority Determines the priority exposure mode, either Auto or Manual, selected when the control panel settings are reset.
Page 147: Finishing Priority
4. User’s Choice Finishing Priority Determines the priority finishing mode when the copier is equipped with a Sorter or Staple Sorter. Sorter Priority: Non Sort Sort Group Staple 1136P409CA The initial setting is "Non Sort." Auto Expo. Level Determines the priority exposure level in the Auto Exposure Mode when the copier has been set so that the Auto Exposure Mode is selected in the initial mode.
Page 148: Counter Removal
4. User’s Choice Counter Removal Determines whether to initialize the copier ("Panel Reset") or not ("Panel Not Reset") when the Plug-In Counter is pulled out after a copy cycle has been run using the Plug-In Counter. Counter Removal: Panel Reset Panel Not Reset 1136P412CA The initial setting is "Panel Reset."...
Page 149: Auto Panel Reset
4. User’s Choice Auto Panel Reset Selects whether to activate ("YES") the auto panel reset function after a given time after a copy cycle has been completed or a Key on the control panel operated, or not ("NO"). The time it takes this auto panel reset function to be activated can also be set to 1, 2, 3, and 5 minutes.
Page 150: Custom 2
4. User’s Choice Custom 2-in-1 It is possible to store in memory various settings that are automatically called up when the 2-in-1 mode is selected. <Setting Procedure> Paper: Use the Paper Select Key or Auto Paper Mode Key to make your own setting.
Page 151: Custom 2-In-1 Separation
The initial settings are as follows - Paper: Auto, Zoom: 1.414, Margin: 0 (none), Erase: 0 (none). Administrator This mode is used only by the administrator of the EP2050 copier. The Administrator menu allows him/her to select an item from among User Help, Copy Track, and Copy Track Data.
Page 152: Appears
4. User’s Choice Making the User’s Choice Settings Open the System Panel and fit the User’s Choice Card onto the Supplementary Panel of the control panel. 1136O194AA Keep pressing the Panel Reset Key for about 3 seconds. The Message Display changes to the User’s Choice screen.
Page 153 4. User’s Choice To select "YES," press the Select 2in1 Security Language Book Mode Mode Select as necessary. Separation 2in1 Custom Auto Exp. Copy Mode Energy Level Priority Saver Mode Counter Manual Exp. Finishing Auto Panel Removal Adjust Priority Reset Drum Intelligent Mixed Orig.
Page 154 4. User’s Choice Press the Panel Reset Key. This terminates the User’s Choice and the initial screen reappears on the Message Display. Remove the User’s Choice Card. 1136P362CA 1136P362CA NOTE Store the User’s Choice Card in a safe place.
Page 155 Chapter 5 When an Indicator Lights Up (Replenishing Supplies, Clearing Misfeeds, and Correcting a Closure Failure) This Chapter explains about the details of the various warning indications given on the control panel, including those that entail inhibition of the initiation of a copy cycle. It also shows action to be taken for each case.
Page 156: Quick Reference For Warning Messages And Indicator Lights
1. Quick Reference for Warning Messages and Indicator Lights Auto Count Mixed Orng. Even Detect # of Origs. 2in1 2in1 Auto 2in1 Exposure Zoom Paper 2in1 Lighter Darker x0.5~x2.0 Reduce Full size Enlarge Auto Select Orig. Copy 1136P367DA When the copier encounters any of the following conditions, a corresponding warning indicator lights up or a warning message appears on the Message Display.
Page 157: Quick Reference For Warning Messages And Indicator Lights
1. Quick Reference for Warning Messages and Indicator Lights Indicator/Message Copier State Action The paper has run out. Add paper by following the Load paper : steps given in the "Add Paper Indicator" section. x1.000 1136P432CA 1136O432CA p. 148 A copier door is open or an Check the Monitor Display for Close section...
Page 158: Detailed Instructions For Messages/Indicator Lights
2. Detailed Instructions for Messages/Indicator Lights Add Toner Indicator When the Toner Bottle will soon run out of Add Toner toner, the Add Toner Indicator lights up. Once it Indicator has lit up, replace the Toner Bottle with a new <Copying one as soon as possible by following the possible>...
Page 159 Add Toner Indicator has lit up. Continuing to make copies without changing the Toner Bottle will result in increasingly lighter images. Use ONLY MT Toner 201B for the EP2050 copier. Using any other Toner could result in image trouble. Auxiliary Toner Replenishing Mode Use the Auxiliary Toner Replenishing Mode if the image is light immediately after replacing the Toner Bottle with a new one.
Page 160: Add Paper Indicator
2. Detailed Instructions for Messages/Indicator Lights Add Paper Indicator When the Drawer currently selected for use has run out of paper, the message shown on the left appears, the Add Paper Indicator lights up, and the Start Key turns orange. At this time, you Load paper : AUTO cannot start any new copy cycle.
Page 161 2. Detailed Instructions for Messages/Indicator Lights Load the paper stack into the Drawer so that its front side (the side facing up when the package was unwrapped) faces down and its trailing edge is pressed up against the Trailing Edge Stop on the left.
Page 162 2. Detailed Instructions for Messages/Indicator Lights Adding Paper (3rd/4th Drawer) Monitor Display Add Paper Indicator The indications on the left show that the 3rd Drawer of the Paper Feed Cabinet PF-202 has run out of paper. 1136P350AA 1136P13OAA 1136P130AA Slide out the 3rd Drawer. 1139O0460A Unwrap the package of copy Front Side...
Page 163 2. Detailed Instructions for Messages/Indicator Lights...
Page 164 2. Detailed Instructions for Messages/Indicator Lights Adding Paper (3rd Drawer) Monitor Display Add Paper Indicator The indications on the left show that the 3rd Drawer of Paper Feed Cabinet PF-102 has run out of paper. At this 1136P350AA time, the Paper Descent Button on the 1136P516EA 3rd Drawer blinks.
Page 165 2. Detailed Instructions for Messages/Indicator Lights Load the paper stack into the right-hand half of the Drawer, facing its front side down. Press the leading edge of the paper stack tightly up against the right edge of the Drawer. NOTE The paper should 1139O1532A be loaded no higher...
Page 166: Add Staples Indicator
2. Detailed Instructions for Messages/Indicator Lights Add Staples Indicator When the staples are running out, the message shown on the left appears and the Add Staples Indicator lights up. Replace the Staple Cartridge with a new one by following the procedure Replace the AUTO given below.
Page 167 2. Detailed Instructions for Messages/Indicator Lights NOTE Check that no portion of the staple sheet hangs out of the Cartridge. Break off any portion of the sheet that hangs out of the Cartridge. 1136O173CA Insert the new Staple Cartridge until a click is heard. 1139O1440A Close the staple Cover and slide the Staple Sorter back against the...
Page 168 2. Detailed Instructions for Messages/Indicator Lights Press the Manual Staple Key. Manual Staple The Staple Sorter test-staples the paper several times automatically. 1139O2732A 1139O2732A Remove the sheet of paper from the Top Bin and check that it has been stapled. If it has not been stapled, place another sheet of paper into the Top Bin and repeat steps 7, 8,...
Page 169 2. Detailed Instructions for Messages/Indicator Lights...
Page 170 2. Detailed Instructions for Messages/Indicator Lights Replacing the Staple Cartridge for ST-206 Holding the Lock Release Lever of the Staple Sorter, slide the Staple Sorter away from the copier. 1136O166AA 1136O166AA Open the Staple Cover. While pressing down the Staple Cartridge Release Lever, pull the Staple Cartridge out of its port.
Page 171 2. Detailed Instructions for Messages/Indicator Lights NOTE Check that no portion of the staple sheet hangs out of the Cartridge. Break off any portion of the sheet that hangs out of the Cartridge. 1136O173CA Insert the new Staple Cartridge until a click is heard. 1136O013AA Close the Staple Cover and slide the Staple Sorter back against the...
Page 172 2. Detailed Instructions for Messages/Indicator Lights Press the Manual Staple Key. Manual Staple The Staple Sorter test-staples the paper several times automatically. 1139O2732A 1139O2732A Remove the sheet of paper from the 1st Bin and check that staples have been driven into it. If no staples are evident, place another sheet of paper into the 1st Bin and repeat steps 7, 8, and...
Page 173 2. Detailed Instructions for Messages/Indicator Lights...
Page 174: Closure Failure Indicator
2. Detailed Instructions for Messages/Indicator Lights Closure Failure Indicator The message shown on the left appears and the Closure Failure Indicator lights up if a copier door is left open, or an option is not attached properly. At this time, the Monitor Display shows the Close section AUTO...
Page 175: Monitor Display
2. Detailed Instructions for Messages/Indicator Lights Monitor Display Check Locations Check that the Lower Right Door is closed. 1136P23OAA 1136P23OAA 1136O049AA Check that the Duplex Unit (AD-5) is locked into position. 1136P24OAA 1139O0630A 1136P24OAA Check that the Sorter (S-104/S-205) or Staple Sorter (ST-101/ST-206) is in position.
Page 176 2. Detailed Instructions for Messages/Indicator Lights Monitor Display Check Locations Check that the Lower Left Door is closed. 1136P448CA 1136O022AA 1136P448CA...
Page 177 2. Detailed Instructions for Messages/Indicator Lights...
Page 178: Misfeed Clearing Procedure
2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Paper Feed Cabinet PF-102 There is a misfed sheet of paper in the Paper Feed Cabinet (Transport Section). 1136P29OAA 1136P290AA Open the Lower Right Door and then pull out the sheet of paper from the Transport Section.
Page 179 2. Detailed Instructions for Messages/Indicator Lights Unload the paper from the Drawer. 1139O6022A Fan the paper thoroughly and reload it. 1139O1532A Slide the Drawer back in. 1139O1512A Swing down the Front Door and then swing it closed to reset the Misfeed Indicator and message on the control panel.
Page 180 2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Duplex Unit AD-5 There is a misfed sheet of paper either in the Duplex Unit or the Transport Sections or both. 1136P30OAA 1136P300AA Open the Middle Left Door and Lower Left Door. Pull out the sheet of paper from the Transport Section.
Page 181: Duplex Unit
2. Detailed Instructions for Messages/Indicator Lights Close the Lower Right Door. 1136O049AA Slide out the Duplex Unit and open the Misfeed Removal Guide Plate. 1139O0780A Pull out the sheet of paper from the Duplex Unit. Close the Misfeed Removal Guide Plate and slide the Duplex Unit back into the copier.
Page 182: Duplexing Document Feeder
2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Duplexing Document Feeder AFR-7 There is a misfed original in the Duplexing Document Feeder AFR-7. 1136P31OAA 1136P310AA Swing open the Document Feed Unit Door and gently pull out the original. 1139O0790A Holding down the Document Turnover/Exit Unit Door Lock Release Key...
Page 183: Automatic Document Feeder
2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Automatic Document Feeder AF-3 There is a misfed original in the Automatic Document Feeder AF-3. 1136P31OAA 1136P310AA Holding down the Document Release Key, gently pull out the original. 1139O0830A Carefully pull out the original from the Exit Unit.
Page 184 2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Sorter S-104 or Staple Sorter ST-101 There is a misfed sheet of paper in the 10-Bin Sorter S-104 or the Staple Sorter ST-101 (Transport Section). 1136P32OAA 1136P320AA Take hold of the Lock Release Lever of S-104/ST-101 and slide the sorter away from the copier.
Page 185 2. Detailed Instructions for Messages/Indicator Lights Misfeed Clearing Procedure: Sorter S-205 or Staple Sorter ST-206 There is a misfed sheet of paper in the 20-Bin Sorter S-205 or the Staple Sorter ST-206 (Transport Section). 1136P32OAA 1136P320AA Hold the Lock Release Lever of the S-205/ST-206 and slide the sorter away from the copier.
Page 186: Call-Technical-Representative Indicator
2. Detailed Instructions for Messages/Indicator Lights Call-Technical-Representative Indicator Call your AUTO Technical Rep. : Code : C0610 1136P371CA 1136P371CA When a malfunction occurs in the copier, the Call-Technical-Representative Indicator lights up and the warning message as shown above appears on the Message Display showing the corresponding malfunction code.
Page 187: Chapter 6 Troubleshooting
Chapter 6 Troubleshooting This Chapter gives you instructions on how to troubleshoot copier malfunctions. 1. When this Type of Copy is Produced The Image is too Light 184 The Image is too Dark 184 The Copy is Blurry 184 The Copy has Lines 186 The Copy has dark specks or spots 186 The Edge of the Copy is dirty 186 The Image on the Copy is not aligned properly 186...
Page 188: When This Type Of Copy Is Produced
1. When this Type of Copy is Produced Symptom Possible Cause The Image is too light. The exposure level for the Auto Exposure Mode is set at one of the "Light" levels. The manual exposure level is set on the lighter side.
Page 189 1. When this Type of Copy is Produced Action Change the setting of the User’s Choice (Auto Expo. Level). p. 135 Cancel the Auto Exposure Mode and select the Manual Exposure Mode, to adjust the exposure level and obtain a darker image. p.
Page 190: The Copy Has Lines
1. When this Type of Copy is Produced Symptom Possible Cause The Copy has lines. The Corona Units are dirty. 1139O1670A The Copy has dark specks or spots. The Original Glass is dirty. The Original Pad or Document Feed Belt is dirty.
Page 191 1. When this Type of Copy is Produced Action Using the Corona Unit Cleaning Levers, clean the Corona Units. p. 210 Wipe the Original Glass clean with a soft dry cloth. p. 208 Wipe the Original Pad or Document Feed Belt clean with a soft cloth dampened with neutral detergent.
Page 192: The Copier Is Not Activated When The Power Switch Is Turned On
2. The Copier is not functioning as designed Symptom check for: None of the Control Panel Is only the Start Key lit up green. Indicators light up The Message Display shows The Display Contrast Control Knob is placed in the nothing.
Page 193 2. The Copier is not functioning as designed Action The copier is in the Energy Saver Mode. Press any key on the Control Panel to cancel the Energy Saver Mode. p. 33 Viewing the Message Display, turn the Display Contrast Control Knob as necessary. Referring to "Entering the Access Number,"...
Page 195: Chapter 7 Specifications
Chapter 7 Specifications This Chapter gives complete specifications of the copier system and options. 1. Copier 192 2. Paper Feed Cabinet 194 3. Duplexing Document Feeder 196 4. Automatic Document Feeder 197 5. 20 Bin Staple Sorter 198 6. 10 Bin Staple Sorter 199 7.
Page 196: Copier Specifications
1. Copier Specifications Name MINOLTA EP2050 Type Desk Top Copier Platen Type Stationary Photo conductor Copying System Electrostatic Dry Powdered Image Transfer to Plain Paper Developing System Micro-Toning System Fusing System Lamp-Heated Roller Types of Original Sheets, Books, and other three-dimensional objects...
Page 197 1. Copier Specifications Warming-up Time 2 min. 30 sec. or less at Ambient temperature of 20 C/68 F (30 sec. or less when the Energy saving Mode is used) First Copy Time A4C = 6.8 sec. (in Full size Mode using First Copier Drawer) Copying Speed First Copier Drawer (approx.
Page 198: Paper Feed Cabinet
2. Paper Feed Cabinet Name Paper Feed Cabinet PF-102 Type Tandem-paper-loading, 2,500-sheet Cassette Installation Desk type Kinds of Paper Plain paper, Recycled paper: Weighing 60 g/m to 90 g/m Copy Paper Size A4L, Letter C Registration Front edge Paper Feeding System Automatic feeding from drawer Capacity 2,500 sheets (1,250 sheets 2)
Page 199 2. Paper Feed Cabinet Name Paper Feed Cabinet PF-2D Type Duplex Unit with a storage drawer Installation Desk type Basic Function 2-Sided Copying Mode Kinds of Paper Plain paper, Recycled paper: Weighing 60 g/m to 90 g/m Copy Paper Size A3L to A5L Multiple Copies 2-Sided Copies: 50 sheets...
Page 200: Duplexing Document Feeder
3. Duplexing Document Feeder Name Duplexing Document Feeder AFR-7 Type Take-up from bottom of stack and U-turn feeding to Glass, loop turnover, U-turn ejection Installation On top of copier, with two Hinges at the back Document Feeding Single Belt transport Document Stop Reference Left side Document Feeding Rear edge...
Page 201: Automatic Document Feeder
4. Automatic Document Feeder Name Automatic Document Feeder AF-3 Type Take-up from bottom of stack and U-turn feeding to Glass, U-turn ejection Installation On top of copier, with two Hinges at the back Document Feeding Single Belt transport System Document Stop Reference Left side Document Feeding Rear edge Registration...
Page 202: Bin Staple Sorter
5. 20 Bin Staple Sorter Name Staple Sorter ST-206 Type 20-Moving-Bin Sorter with Automatic Stapler Installation Freestanding Registration Front edge No. of Bins Non-Sort Bin 20 Sort Bins Modes Non-Sort Mode, Sort Mode, Group Mode, Sort Staple Mode, Manual Staple Mode, Hole Punch Mode Kinds of Paper Non-Sort Mode, Hole Punch Mode: Plain paper, Recycled paper...
Page 203 6. 10 Bin Staple Sorter Name Staple Sorter ST-101 Type 10-Moving-Bin Sorter with Automatic Stapler Installation Attached to copier Registration Front edge No. of Bins Sort Bins: 10 Modes Non-Sort Mode, Sort Mode, Group Mode, Sort Staple Mode, Manual Staple Mode Kinds of Paper Non-Sort Mode: Plain paper, Recycled paper, Special paper...
Page 204: Bin Sorter
7. 20 Bin Sorter Name 20 Bin Sorter S-205 Type 20-Moving-Bin Sorter Installation Freestanding Registration Front edge No. of Bins Non-Sort Bin 20 Sort Bins Modes Non-Sort Mode, Sort Mode, Group Mode Kinds of Paper Non-Sort Mode: Plain paper, Recycled paper (Weighing 60 g/m to 90 g/m Thick paper (Weighing 90 g/m...
Page 205 8. 10 Bin Sorter Name 10 Bin Sorter S-104 Type 10-Moving-Bin Sorter Installation Attached to copier Registration Front edge No. of Bins Sort Bins: 10 Modes Non-Sort Mode, Sort Mode, Group Mode Kinds of Paper Non-Sort Mode: Plain paper Recycled paper, Special paper (Thick paper, Transparencies, Translucent paper) Sort Mode, Group Mode: Plain paper, Recycled paper...
Page 206: Duplex Unit
9. Duplex Unit Name Duplex Unit AD-5 Type 1-sided copy storage and feeding unit for 2-sided copying Installation Fixed inside the copier Basic Function 2-sided copying Kinds of Paper Plain paper, Recycled paper: Weighing 60 g/m to 90 g/m Copy Paper Size A3L to A5L Capacity 50 sheets...
Page 207: Data Controller
DC24V (supplied from copier) Power Consumption 5W or less Dimensions Width : 180 mm Depth : 564 mm Height : 111 mm Weight Approx. 550 g Others A printer (option) recommended by Minolta can be hooked up, sourced from another power supply.
Page 208: Copier Outline Dimensions
11. Copier Outline Dimensions EP2050 1,105 1,550 1,455 1136O149AA 1136O148AA Scale: mm EP2050 with a Complete Lineup of Options 1,340 1,665 1,070 1,160 1136O154AA 1136O155AA Scale: mm...
Page 209: Chapter 8 Miscellaneous
Chapter 8 Miscellaneous This Chapter explains about care of the copier and the various possible combinations of functions. 1. Care of the Copier Daily Checks 206 Cleaning 208 2. Function Combination Matrix 212 3. Description of Copy Paper Size 216 4.
Page 210: Care Of The Copier
1. Care of the Copier To keep your copier in good shape at all times, make the following daily checks and cleaning. Daily Checks Power Cord, Communications Cable, Ground Cable Item Action Is the copier placed on its power cord or It could result in the copier or other other cables? electrical equipment malfunctioning.
Page 211 1. Care of the Copier Original Cover, Duplexing/Automatic Document Feeder Item Action Is the Original Pad or Document Transport Clean the Pad or Belt using the procedure Belt dirty? given in "Cleaning." p. 208 Is the Original Pad or Document Transport Call your Technical Representative.
Page 212: Cleaning
1. Care of the Copier Cleaning Housing Cover Wipe the surface of the Housing Cover clean with a soft cloth dampened with neutral home detergent. 1139O1820A Original Pad Raise the Original Cover. Wipe clean the surface of the Original Pad with a soft cloth dampened with neutral home detergent.
Page 213 1. Care of the Copier Control Panel Turn the Power Switch OFF. Wipe the surface of the control panel clean with a soft, dry cloth. NOTE 1139O1850A NEVER use a glass cleaner or any other detergent to avoid damage to the control panel keys. Front Door Swing down the Front Door.
Page 214 1. Care of the Copier Corona Units Swing down the Front Door. Gently slide out the Corona Unit Cleaning Lever (Upper) as far as it goes. 1136O073AA Gently slide the Cleaning Lever back into the original position. 1136O074AA Gently slide out the Corona Unit Cleaning Lever (Lower) as far as it goes.
Page 215 1. Care of the Copier Document Transport Belt Raise the AF-3/AFR-7. Wipe the surface of the Document Transport Belt clean with a soft cloth dampened with neutral home detergent. 1139O1910A Hold the Document Transport Belt on both edges, and pull it to the left to expose a fresh surface.
Page 216: Function Combination Matrix
2. Function Combination Matrix Basic Functions Functions Set First Fin- Orig. Image Paper ish- Zoom Ratio Margin Copy Density Size Function Set Last Orig. Book Copy Finish- Non-Sort Auto Exposure Image Density Manual Exposure Auto Paper Paper Size Manual Auto Size Full Size (100%) Zoom Fixed Zoom...
Page 217 2. Function Combination Matrix System Functions Functions Set First Orig. Copy Finishing Function Set Last Orig. Book Copy Finish- Non-Sort Auto Exposure Image Density Manual Exposure Auto Paper Paper Size Manual Auto Size Full Size (100%) Zoom Fixed Zoom Ratio (Reduce, Enlarge) Variable Zoom (50-200%)
Page 218: Duplexing Document Feeder
2. Function Combination Matrix Conditions for Combined Functions : The functions can be combined. : The functions cannot be combined. (The function set first takes precedence.) : The functions cannot be combined. (The function set last takes precedence.) : The functions cannot be combined. (Either one of the functions must be canceled.) A to G: The settings can be made only when the copier is equipped with the following options.
Page 219 2. Function Combination Matrix Conditions for Combined Functions N : Book 1 or Book 2 can be combined with the Sort-and-Staple mode, but no stapling action takes place. (The copier performs only book copying and sorting of copies, but not stapling.) P : Hole Punch is possible only when the copier is equipped with a Staple Sorter ST-206 and the paper size is A3 lengthwise or A4 crosswise.
Page 220: Description Of Paper Size
3. Description of Paper Size Name Size (Metric) Size (Inch) 297 mm 420 mm 11-3/4" 16-1/2" 257 mm 364 mm 10" 14-1/4" 210 mm 297 mm 8-1/4" 11-3/4" 182 mm 257 mm 7-1/4" 10" 148 mm 210 mm 5-3/4" 8-1/4" 128 mm 182 mm 5"...
Page 221: Zoom Ratio Table
4. Zoom Ratio Table (Original Size to Copy Paper Size) Metric Areas Inch Areas Copy Paper Copy Paper Original Size Zoom Ratio Original Size Zoom Ratio Size Size 0.707 11" 14" 0.823 11" 17" 420 mm 0.500 Legal 0.772 11-3/4" 279.4 0.866 Foolscap...
Page 222: Index
5. Index Access No. 36 Add Paper 29, 148, 150, 152 Add Toner 29, 144, 146 Administrator (User’s Choice) 132, 139 Auto Copy Start Function 32 Auto Count mode (Original Count Mode) 82 Auto Dual Function 88 Auto Expo. Level (User’s Choice) 132, 135 Auto Exposure Mode 49 Auto Panel Reset (User’s Choice) 132, 137 Auto Paper Mode 62...
Page 223: Function Combination Matrix
5. Index Energy Saver (User’s Choice) 132, 136 Energy Saver Mode 33 Enlargement Ratios 52 Enter Key (OK Key) 27 Erase 1 (Punch Hole Erase I) 100 Erase 2 (Punch Hole Erase II) 100 Erase 3 (Frame Erase) 100 Erase 4 (Center Erase) 100 Exposure Priority (User’s Choice) 132, 134 Feeding Direction (copy paper path) x File Margin Mode 103...
Page 224 5. Index Language Select (User’s Choice) 132, 133 Length (Type of Originals and Copy Paper) xi Lengthwise (Type of Originals and Copy Paper) xi Maintenance Call Indicator 39, 145 Manual Exposure Mode 49 Manual Exposure Adjust (User’s Choice) 132, 135 Manual Mode (Manual Paper Select Mode) 60 Manual Staple Mode 90 Margin 1 (Shift for Margin) 103...
Page 225 5. Index Page Insertion 118 Panel Resetting 35 Paper Priority (User’s Choice) 132, 134 Paper Size 60 Power Switch 10, 30 Punch Hole Erase I (Erase 1) 100 Punch Hole Erase II (Erase 2) 100 Reduce for Margin (Margin 2) 103 Reduction Ratios 52 Remove Copies Indicator 29 Replacing the Toner Bottle 146...

Minolta EP2050 Operator's Manual

Chapter 1 Safety Notes

Chapter 2 First Things to Know

Chapter 3 Making Copies

Chapter 4 Special Functions

Chapter 5 When a Warning Message

Chapter 6 Troubleshooting

Chapter 7 Specifications

Chapter 8 Miscellaneous

Quick Links

Need help?

Questions and answers

Related Manuals for Minolta EP2050

Summary of Contents for Minolta EP2050

Table of Contents
