Crestron PT-AMFM Quick Start Manual

PT-AMFM
1 Introduction
The PT-AMFM is an AM/FM tuner for a Prodigy
Crestron ® radio technology delivers easy control and a crystal
clear signal in an easy to integrate package.
• Station, artist and song information (when available) is
displayed on any Prodigy ® touch screen
• Select favorite stations from any touch screen around the
house
• Station presets provide instant access to favorite programs
• Whole home audio distribution made easy - add the PT-AMFM
to a Prodigy system (existing AV receiver or a PAMP-4X100
Processor Amplifier) whenever budget allows
1
For Regulatory Compliance information, refer to the latest
version of Doc. 7178.
QUICKSTART DOC. 7177A (2030564)
Radio Tuner
2 Connection and Control
®
system. BAND SELECTION
Press AM or FM to
select radio band
DISP
Press DISP to display information
about the tuned station
AUDIO OUT
CONNECTS TO:
Unbalanced stereo line level audio outputs
connect to PAMP-4X100 or other amplifiers
www.crestron.com/prodigy
06.11
Specifications subject to
change without notice.
MENU
Press to display options
for selected tuner
LCD DISPLAY
Displays information on tuned
station and menu options
NET PWR
CONNECTS TO: CONNECTS TO:
Other Prodigy components AC power via included adapter
ANTENNA (FM and AM)
CONNECTS TO:
Included antennae.
FM
888.273.7876 201.767.3400
J and K
Notes on Antenna Orientation:
Press to tune or scroll
AM: Orient the AM loop antenna so
through menu options
that the flat surface of the loop
antenna faces the metropolitan area
NET LED originating the broadcast signals. This
is particularly necessary when signals
Indicates communication
are weak. If you are not aware of the
with Prodigy control
source or directions of the signals to
system
which you will listen, simply rotate the
loop antenna in clear space for
RESET BUTTON
maximum signal strength. The
Press to reset PT-AMFM
supplied antenna has a folding stand
that allows the antenna to stand on a
ENTER flat surface.
Press to confirm displayed
FM: The recommended FM antenna is
selection
an outdoor type available in electronics
stores. Use the included FM antenna if
an outdoor antenna cannot be used.
The included antenna may require
reorientation if the signal is weak. Best
results can occur if the length of the
antenna faces the metropolitan area
from which the desired FM signal
originates. The supplied antenna has a
fitting at its end that will enable you to
fasten it in place.
G
CONNECTS TO:
Ground Lug on PAMP-4X100
or AV Receiver
AM Connector End of AM Antenna
Connect to
Connect to
