Page 3: Table Of Contents
Crestron ST-TUNE Contents Integrated AM/FM/TV Tuner: ST-TUNE Description Functional Description Physical Description Leading Specifications Setup Network Wiring Preparation for Use Identity Code Firmware Upgrade Programming with SIMPL Windows Configure ST-TUNE Program ST-TUNE and STI-TUNE Symbols Basic Example Program Advanced Example Program... -
Page 5: Integrated Am/Fm/Tv Tuner: St-Tune
STI-TUNE. All of the features are identical with the exceptions of TV reception formats and FM and TV input connectors. The ST-TUNE receives National Television System Committee (NTSC) M/N format video and the STI- Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner Integrated AM/FM/TV Tuner: ST-TUNE... -
Page 6: Physical Description
All connections are made on the rear panel ports. There are four rubber feet on the base of the unit for stability and to prevent slippage. ST-TUNE Physical Views Integrated AM/FM/TV Tuner: ST-TUNE Crestron ST-TUNE Operations Guide - DOC. 5833A... - Page 7 N E T N E T A U D I O CRESTRON ELECTRONICS INC. ROCKLEIGH, N.J. 07647 USA CRESTRON ELECTRONICS INC. ROCKLEIGH, N.J. 07647 USA Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner V I D E O V I D E O...
- Page 8 This LED (green) illuminates when operating power is supplied to the ST-TUNE. Operating power is supplied by the external power pack (included) or the network wiring via the rear panel connectors. Integrated AM/FM/TV Tuner: ST-TUNE reception, refer to Appendix 1 that begins on page 25. weak...
- Page 9 AM in ST-TUNE, for all modes except AM and TV in international version STI-TUNE) and the MODE button cycles through the preset, manual, or search tuning modes. Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner Integrated AM/FM/TV Tuner: ST-TUNE...
-
Page 10: Leading Specifications
The five tables in this section provide summaries of the specifications for the ST-TUNE. Dimensions and weight are rounded to the nearest hundredth unit. Leading Specifications of the ST-TUNE Integrated AM/FM/TV Tuner: ST-TUNE Crestron ST-TUNE DETAILS 12VDC, external power pack or 9 Watts (24VDC @ 0.375A), network... - Page 11 Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner DETAILS US "F" Type Coaxial, female, 75 ohms International "IEC" Type Coaxial, 9.5mm male 87.5MHz to 107.9MHz 11 (dBf) 74dB / 70dB 0.05% 5dB / 65dB 100dB 55dB 45dB 1VRMS Integrated AM/FM/TV Tuner: ST-TUNE...
-
Page 12: Setup
CNHBLOCK modular ports. DO NOT use standard, modular 6-conductor telephone cables. Most telephone cables are wired in a crisscross fashion and are not compatible with Crestron equipment. Integrated AM/FM/TV Tuner: ST-TUNE receiver is connected. Crestron ST-TUNE Operations Guide - DOC. 5833A... -
Page 13: Preparation For Use
Where: R = Resistance (refer to next table). L = Length of run (or chain) in feet. LF = Load factor of entire run (or chain). RESISTANCE (R) WIRE GAUGE 24 (Double-CAT 5) Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner... -
Page 14: Identity Code
75 ohm coaxial connectors for the FM and TV inputs. The international version STI-TUNE requires “IEC” connectors, 9.5mm for FM and 11mm for TV. Hookup Diagram for ST-TUNE Integrated AM/FM/TV Tuner: ST-TUNE N E T N E T A U D I O V I D E O Operations Guide - DOC. -
Page 15: Firmware Upgrade
3. From the SIMPL Windows or VT Pro-e menu bar, select Tools | Viewport to open the Crestron Viewport. 4. Refer to diagram on the next page. From the Viewport menu, select Setup | Communications settings (alternatively, depress Alt+D) to open the Port Settings dialog box. Integrated AM/FM/TV Tuner: ST-TUNE... - Page 16 IP address. Port Settings Dialog Box Integrated AM/FM/TV Tuner: ST-TUNE 5. Refer to the dialog box shown below and verify the communications settings. Make sure that parity is set to None, data bits to Eight, and XModem is selected.
- Page 17 8b. If the firmware version is prior to version 2.17, proceed to step 8 of “Appendix 3” that begins on page 28. 9. As shown below, select File Transfer | Load Network Device from the Viewport menu. Integrated AM/FM/TV Tuner: ST-TUNE...
-
Page 18: Programming With Simpl Windows
It provides a well-designed graphical environment with a number of workspaces (i.e., windows) in which a programmer can select, configure, program, test, and monitor a Crestron control system. Integrated AM/FM/TV Tuner: ST-TUNE 10. Refer to the diagram below. Select the NET ID of the ST-TUNE and then click OK. -
Page 19: Configure St-Tune Program
WHERE Desired control System Views system ST-TUNE or System Views, STI-TUNE Cresnet Units Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner DROP ADDITIONAL SETUP Refer to the documentation supplied with the control system for additional setup information. CHANGE NET ID (OPTIONAL) -... - Page 20 Depending upon how the symbol was created, symbol inputs may work at the logic levels or on transitions. Detail View of the ST-TUNE Symbol in SIMPL Windows’ Programming Manager Integrated AM/FM/TV Tuner: ST-TUNE Crestron ST-TUNE Operations Guide - DOC. 5833A...
- Page 21 Crestron ST-TUNE Integrated AM/FM/TV Tuner Detail View of the STI-TUNE Symbol in SIMPL Windows’ Programming Manager Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner: ST-TUNE...
- Page 22 Off-Air, STD, IRC, HRC AM-Station FM-Station Integrated AM/FM/TV Tuner: ST-TUNE INPUT(S) These signals perform the same functions as pressing the UP or DOWN buttons on the front panel. NOTE: The front panel buttons auto-increment after a preset period of time. These UP and DN signals engage only once on the rising edge.
- Page 23 5FFD, 7FFC, 9FFB, BFFA, DFF9. This signal is active only during the FM mode. NOTE: Best SRCH function recognition is achieved with a signal strength of 24573 (5FFD) or above for low-sensitivity or 40955 (9FFB) or above for high-sensitivity. Integrated AM/FM/TV Tuner FUNCTION(S) FUNCTION(S) Integrated AM/FM/TV Tuner: ST-TUNE...
-
Page 24: Basic Example Program
ST-TUNE symbols are common to all (AM, FM, WX and TV) functions but the diagram shows details the signals and logic for the AM function only. The logic specifically for the AM functions are OR symbol S-2.1 and analog Integrated AM/FM/TV Tuner: ST-TUNE Crestron ST-TUNE Operations Guide - DOC. 5833A... -
Page 25: Advanced Example Program
The setup screen allows MONO mode to be turned on or off, SAP to be turned on or off, the tuning sensitivity to be set, and the TV reception mode to be set. (The Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner Integrated AM/FM/TV Tuner: ST-TUNE... -
Page 26: Problem Solving
25 Fields” was used to program the preset names. Problem Solving Troubleshooting The table on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. Integrated AM/FM/TV Tuner: ST-TUNE Crestron ST-TUNE Operations Guide - DOC. 5833A... - Page 27 The location of the ST-TUNE is an important factor in the AM radio reception. The reception is also dependent on its placement and the construction of the building, locate the unit outside of any metal enclos Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner CORRECTIVE ACTION Verify VAC at wall outlet or power strip is available.
-
Page 28: Further Inquiries
What’s New page (Other Products section) or the Downloads page (UPGRADES Library) of Crestron’s website. New users are required to register in order to obtain access to the FTP site. Integrated AM/FM/TV Tuner: ST-TUNE In the US and Canada, call Crestron’s corporate headquarters at 1-888-CRESTRON [1-888-273-7876] or 1-201-767-3400. -
Page 29: Appendix 1: High-Gain Am Antenna
15 LOOPS AT APPROXIMATELY 5-INCHES DIAMETER APPROXIMATELY 36-INCHES 3. Bring the ends of the wire together. Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner reception. The antenna consists of a weak QUANTITY 240 inches * Eight (8) minimum One (1) **... - Page 30 Integrated AM/FM/TV Tuner Twist Wires Together Solder Connector Integrated AM/FM/TV Tuner: ST-TUNE 4. As shown below, twist the wires together at two (2) turns per inch until the length of the twisted wires is approximately 34-inches. APPROXIMATELY 34-INCHES WITH TWO TURNS PER INCH 5.
-
Page 31: Appendix 2: Sti-Tune Tv Receptions
559.25 567.25 575.25 583.25 591.25 599.25 607.25 615.25 623.25 631.25 639.25 647.25 655.25 663.25 671.25 679.25 687.25 Integrated AM/FM/TV Tuner: ST-TUNE Integrated AM/FM/TV Tuner Chan Prog Chan 695.25 703.25 711.25 719.25 727.25 735.25 743.25 751.25 759.25 767.25 775.25 783.25 791.25 799.25... -
Page 32: Appendix 3: Upgrade Firmware Version Prior To 2.17
NOTE: If performing a firmware upgrade via Ethernet, select TCP/IP as the connection type and provide the IP address. Integrated AM/FM/TV Tuner: ST-TUNE 1. Make sure that no programs accessing the COM port of the PC. 2. At the PC, start SIMPL Windows or VT Pro-e. - Page 33 Operations Guide - DOC. 5833A Integrated AM/FM/TV Tuner 6. Refer to diagram below. From the Viewport menu, select Diagnostics | Report Network Devices (alternatively, depress F4). 7. In the Viewport return display, observe the firmware version of the ST-TUNE. Integrated AM/FM/TV Tuner: ST-TUNE...
- Page 34 “Firmware Upgrade” that begins on page 11. Accessing the Port Settings Dialog Box Port Settings Dialog Box for ASCII Upload Integrated AM/FM/TV Tuner: ST-TUNE 8. Refer to diagram on the next page. From the Viewport menu, select Setup | Communications settings (alternatively, depress Alt+D) to open the Port Settings dialog box.
- Page 35 12. As shown below, browse to the firmware directory, select the downloaded loader (HEX) file and click Open. The transfer will complete in approximately 3-1/2 minutes. 13. Select Diagnostics | Report Network Devices in the Viewport (alternatively, depress F4) and observe Viewport return display show “BOOT”. Integrated AM/FM/TV Tuner: ST-TUNE...
- Page 36 Integrated AM/FM/TV Tuner Accessing the Port Settings Dialog Box Port Settings Dialog Box for Firmware Upload Integrated AM/FM/TV Tuner: ST-TUNE 14. Remove operating power from the ST-TUNE, wait several seconds and reconnect power. 15. Allow at least 30 seconds after power has been reconnected then select Diagnostics | Report Network Devices in the Viewport (alternatively, depress F4).
- Page 37 19. Refer to the diagram below. Select the NET ID of the ST-TUNE and then click OK. 20. As shown below, browse to the firmware directory, select the downloaded firmware (UPG) file and click Open. The transfer will complete automatically. Integrated AM/FM/TV Tuner: ST-TUNE...
- Page 38 Cresnet power supplied via the NET connector(s). To remove power from the unit, make sure both external power pack and NET connector(s) are removed. Integrated AM/FM/TV Tuner: ST-TUNE 21. Remove operating power from the ST-TUNE, wait several seconds and reconnect power.
-
Page 39: Return And Warranty Policies
3. Return freight charges following repair of items under warranty shall be paid by CRESTRON, shipping by standard ground carrier. In the event repairs are found to be non-warranty, return freight costs shall be paid by the purchaser. Integrated AM/FM/TV Tuner: ST-TUNE... - Page 40 Crestron Electronics, Inc. Operations Guide - DOC. 5833A 15 Volvo Drive Rockleigh, NJ 07647 06.01 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
