Summary of Contents for Crestron Adagio ATC-AMFMSR
- Page 1 Crestron Adagio ATC-AMFMSR ® AM/FM and SIRIUS Satellite Radio ® Tuner Card Operations & Installation Guide...
- Page 2 United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
-
Page 3: Table Of Contents
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card Contents AM/FM and SIRIUS Satellite Radio Tuner Card: Adagio ATC-AMFMSR 1 Introduction ..........................1 Features and Functions ....................1 Specifications ......................2 Physical Description ....................3 Industry Compliance ....................5 Setup ............................6 Installation ........................6 Regional Configuration .................... -
Page 5: Am/Fm And Sirius Satellite Radio Tuner Card: Adagio Atc-Amfmsr
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card AM/FM and SIRIUS Satellite Radio Tuner Card: Adagio ATC-AMFMSR Introduction Features and Functions • ® AM/FM/SR Tuner Card slides easily into place into the Adagio Audio Entertainment System (AES) to become an integral part of its control system •... -
Page 6: Specifications
AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR Specifications Specifications for the ATC-AMFMSR are listed in the following table. ATC-AMFMSR Specifications SPECIFICATION DETAILS Audio Maximum Output @ 1 kHz (AM/FM); (SIRIUS) FM Tuner Frequency Range 87.50 to 108 MHz (50 or 100 kHz steps) Intermediate Frequency 10.7 MHz... -
Page 7: Physical Description
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card Physical Description This section provides information on the connections, controls and indicators available on your ATC-AMFMSR. ATC-AMFMSR Physical View (Head On) ATC-AMFMSR Physical View (Angled) Conversion Connector Coax (RG6)/F Type (Antenna) to IEC Type Connector (Tuner) Conversion Connector Coax (RG6)/F Type (Antenna) to SMB Type Connector (Tuner) AM/FM/SR Tuner Card: ATC-AMFMSR •... - Page 8 AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR ATC-AMFMSR Overall Dimensions 6.69 in (16.98 cm) 4.91 in 6.19 in (12.46 cm) (15.72 cm) 1.39 in (3.51 cm) Connectors, Controls & Indicators CONNECTORS, DESCRIPTION CONTROLS & INDICATORS EXTERNAL AM (1) 8-wire RJ-45 female; Reserved for future ANTENNA IN remote AM antenna (not yet available).
-
Page 9: Industry Compliance
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card Industry Compliance As of the date of manufacture the ATC-AMFMSR has been tested and found to comply with specifications for CE marking and standards per EMC and Radiocommunications Compliance Labelling. NOTE: This device complies with part 15 of the FCC rules. Operation is subject to... -
Page 10: Setup
Installation CAUTION: The ATC-AMFMSR and the Adagio Entertainment System contain ® electrostatic discharge (ESD) sensitive devices. Crestron encourages you to wear a grounding strap to avoid damaging the card and/or the host system. When inserting a card into the Adagio Entertainment System you may need to move other source connections if designated connectors are occupied by other sources. -
Page 11: Regional Configuration
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card ATC-AMFMSR Installation Push the ATC-AMFMSR card into the slot until it stops at the rear connector, then push again until the ATC-AMFMSR card snaps into place. Secure the card in place by tightening the two slotted screws by hand. -
Page 12: Hardware Hookup
AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR Hardware Hookup Make the necessary connections as called out in the illustration that follows this paragraph. Hardware Connections for the ATC-AMFMSR EXTERNAL AM AM ANTENNA ANTENNA IN (SUPPLIED) EXTERNAL AM SIRIUS ANTENNA ANTENNA OUT... - Page 13 Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card tuner is a T-type and it should be stretched horizontally in space that is as clear as possible. Some reorientation may be necessary if signals in your area are weak. Best results can usually be achieved if the length of the antenna faces the metropolitan area from which the FM signals you wish to receive originate.
- Page 14 AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR North or Northeast. The exact direction is determined by your specific location in Area 2 relative to the X on the map; if you live in Texas, you will need a more North facing clear view of the sky whereas if you live in southern California, you will need a more Northeast facing clear view of the sky.
-
Page 15: Programming Software
Have a question or comment about Crestron software? Answers to frequently asked questions (FAQs) can be viewed in the Online Help section of the Crestron website. To post a question or view questions you have submitted to Crestron’s True Blue Support, log in at http://support.crestron.com. -
Page 16: Programming With Simpl Windows
The symbol can be viewed by double clicking on the icon or dragging it into Detail View. Each signal in the symbol is described in the SIMPL Windows help file (F1). Example Program An example program for the ATC-AMFMSR is available from the Crestron website (http://www.crestron.com/exampleprograms). 12 • AM/FM/SR Tuner Card: ATC-AMFMSR... -
Page 17: Uploading And Upgrading
AES, refer to the latest version of the Adagio AES Operations Guide (Doc. 6456) for details. Crestron recommends using the latest programming software and that each device contains the latest firmware to take advantage of the most recently released features. -
Page 18: Operation
AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR Operation This section provides a description of the available AM, FM and SR tuner control functions. In order to access functions of the AM/FM/SR Tuner card, it is necessary to become familiar with basic AES controls affecting tuner operation. -
Page 19: Problem Solving
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. ATC-AMFMSR Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION Tuner muted. -
Page 20: Further Inquiries
For assistance in your local time zone, refer to the Crestron website (http://www.crestron.com/) for a listing of Crestron worldwide offices. You can also log onto the online help section of the Crestron website to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 21: Appendix: Rbds/Rds Function Support
Crestron Adagio ATC-AMFMSR AM/FM/SR Tuner Card Appendix: RBDS/RDS Function Support Many radio stations transmit additional information such as traffic information, radio text, real time clock etc., with their regular FM programming. The FM tuner contains circuitry that retrieves this information. - Page 22 AM/FM/SR Tuner Card Crestron Adagio ATC-AMFMSR RBDS/RDS Program Types RBDS PROGRAM TYPE RDS PROGRAM TYPE CODE (US) (EUROPE) No program type or undefined No program type or undefined News News Information Current Affair Sports Information Talk Sports Rock Education Classic Rock...
-
Page 23: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 24 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 6463A 15 Volvo Drive Rockleigh, NJ 07647 (2014565) Tel: 888.CRESTRON 07.13 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
