- Page 1 Crestron Adagio ATC-AMFMXMD ® AM/FM and XM Satellite Radio Tuner Card with Digital Output Operations & Installation Guide...
- Page 2 Customer Agreement available at xmradio.com. Only available in the 48 contiguous United States. ©2001-2008 XM Satellite Radio Inc. All rights reserved. All brand names, product names and trademarks are the property of their respective owners. ©2008 Crestron Electronics, Inc.
-
Page 3: Table Of Contents
Further Inquiries ......................12 Future Updates ......................12 Appendix: RBDS/RDS Function Support................13 Return and Warranty Policies ....................15 Merchandise Returns / Repair Service ..............15 CRESTRON Limited Warranty................. 15 Contents • i Operations & Installation Guide – DOC. 6605A... -
Page 5: Am/Fm And Xm Satellite Radio Tuner Card With Digital Output: Adagio ® Atc-Amfmxmd
ATC-AMFMXMD Introduction ® The ATC-AMFMXMD tuner card is designed for use with the Crestron CEN-TRACK Tuner Rack multi tuner. On a single card, the ATC-AMFMXMD provides one AM/FM tuner and one XM Satellite Radio tuner. Each tuner may be operated independently and simultaneously. -
Page 6: Specifications
® AM/FM/XM Tuner Card Crestron Adagio ATC-AMFMXMD Specifications Specifications for the ATC-AMFMXMD are listed in the following table. ATC-AMFMXMD Specifications SPECIFICATION DETAILS Audio Maximum Output @ 1 kHz (AM/FM); (XM) FM Tuner Frequency Response 87.50 to 108 MHz (50 or 100 kHz steps) Intermediate Frequency 10.7 MHz... -
Page 7: Physical Description
® Crestron Adagio ATC-AMFMXMD AM/FM/XM Tuner Card Physical Description This section provides information on the connections, controls and indicators available on your ATC-AMFMXMD. ATC-AMFMXMD Physical View (Head On) ATC-AMFMXMD Physical View (Angled) Conversion Connector Coax (RG6)/F Type (Antenna) to IEC Type Connector (Tuner) Conversion Connector Coax (RG6)/F Type (Tuner) to SMB Type Connector (Antenna) AM/FM/XM Tuner Card: ATC-AMFMXMD •... - Page 8 ® AM/FM/XM Tuner Card Crestron Adagio ATC-AMFMXMD ATC-AMFMXMD Overall Dimensions 6.69 in (16.98 cm) 4.91 in 6.19 in (12.46 cm) (15.72 cm) 1.39 in (3.51 cm) Connectors, Controls and Indicators CONNECTORS, DESCRIPTION CONTROLS, & INDICATORS EXT. ANT IN (1) 8-wire RJ-45 female;...
-
Page 9: Industry Compliance
® Crestron Adagio ATC-AMFMXMD AM/FM/XM Tuner Card Connectors, Controls and Indicators (Continued) CONNECTORS, DESCRIPTION CONTROLS, & INDICATORS EXT. ANT OUT (1) 2-pin detachable terminal block; AM antenna signal pass-through from remote antenna AM ANT (1) 2-pin spring-loaded terminals; AM shielded loop antenna included;... -
Page 10: Setup
CAUTION: The ATC-AMFMXMD and Adagio systems contain electrostatic discharge (ESD) sensitive devices. Crestron encourages you to wear a grounding strap to avoid damaging the card and/or the host system. When inserting a card into an Adagio system that features tuner card slots you may need to move other source connections if designated connectors are occupied by other sources. -
Page 11: Regional Configuration
Crestron CEN-TRACK Operations Guide (Doc. 6646) or the operations guide for your particular Adagio system that feature tuner card slots which can be obtained from the Crestron website (http://www.crestron.com/manuals). Hardware Hookup Make the necessary connections as called out in the following illustration. -
Page 12: Antenna Orientation
Certain areas provide satellite radio ground repeaters that retransmit satellite radio signals. Extension cables are available from your dealer or from Crestron. The following antennas are supplied with your AM/FM/XM tuner card:... -
Page 13: Uploading And Upgrading
For details on upgrading refer to the Crestron Toolbox™ help file. Check the Crestron website to find the latest firmware. (New users may be required to register to obtain access to certain areas of the site, including the FTP site.) Upgrade ATC-AMFMXMD firmware via Crestron Toolbox. -
Page 14: Operation
Crestron Adagio ATC-AMFMXMD Operation Please refer to the latest version of the Crestron CEN-TRACK Operations Guide (Doc. 6646) or the operations guide for your particular Adagio system for control of the AM/FM/XMD tuner card. 10 • AM/FM/XM Tuner Card: ATC-AMFMXMD... -
Page 15: Problem Solving
Crestron Adagio ATC-AMFMXMD AM/FM/XM Tuner Card Problem Solving Troubleshooting The following table provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. ATC-AMFMXMD Troubleshooting TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION Tuner muted. -
Page 16: Further Inquiries
Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876]. You can also log onto the online help section of the Crestron website (www.crestron.com/onlinehelp) to ask questions about Crestron products. First-time users will need to establish a user account to fully benefit from all available features. -
Page 17: Appendix: Rbds/Rds Function Support
® Crestron Adagio ATC-AMFMXMD AM/FM/XM Tuner Card Appendix: RBDS/RDS Function Support Many radio stations transmit additional information, such as traffic information, radio text, real time clock etc., with their regular FM programming. The FM tuner contains circuitry that retrieves this information. - Page 18 ® AM/FM/XM Tuner Card Crestron Adagio ATC-AMFMXMD RBDS/RDS Program Types RBDS PROGRAM TYPE RDS PROGRAM TYPE CODE (US) (EUROPE) No program type or undefined No program type or undefined News News Information Current Affair Sports Information Talk Sports Rock Education...
-
Page 19: Return And Warranty Policies
Purchasers should inquire of the dealer regarding the nature and extent of the dealer's warranty, if any. CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended or if it has been subjected to misuse, accidental damage, modification or improper installation procedures. - Page 20 Crestron Electronics, Inc. Operations & Installation Guide – DOC. 6605A 15 Volvo Drive Rockleigh, NJ 07647 (2019816) Tel: 888.CRESTRON 03.08 Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
