Fuse Chart - SMART fortwo coupe Operator's Manual

Fuses

Fuse chart

No. Accessory/Componant
1 Engine
2 Windshield wipers
3 Power window, left and right
4 Blower
5 Front fog lamps
6 Right parking and lamp, instrument lighting, terminal 58R
7 Parking and lamp, left
8 Engine
9 Engine
10 Engine
®
11 ESP
12 Switches strip, on board diagnosis socket, turn signal lamp, transmission
control unit
13
14 Charge air cooler, air conditioning compressor
15 Audio, subwoofer, interior lighting
16 Fuel pump
17 Rear window wiper (coupé only)
®
18 ESP , power steering, air bag, instrument panel
19 Motor control unit, on board diagnosis socket, transmission control unit 7.5 A
20 Air conditioning system, exterior mirror adjustment, washer pump, audio,
seat heating, gear selector lever control unit
284
>> Practical hints.
Amperage Color
25 A Neutral
25 A Neutral
20 A Yellow
25 A Neutral
10 A Red
7.5 A Brown
7.5 A Brown
25 A Neutral
7.5 A Brown
15 A Blue
25 A Neutral
10 A Red
15 A Blue
15 A Blue
15 A Blue
15 A Blue
10 A Red
Brown
10 A Red
