Fully automatic washing machine
User's manual
This manual is for
XQB60-68
Special number:
0030805945
Please read this manual
carefully before using.
Retain it for future reference.

Advertisement

loading

  Related Manuals for Haier XQB60-68

  Summary of Contents for Haier XQB60-68

  • Page 1 Fully automatic washing machine User's manual This manual is for XQB60-68 Special number: 0030805945 Please read this manual carefully before using. Retain it for future reference.
  • Page 2: Table Of Contents

    Contents Names of the parts Safety precautions Installation and adjustment Installation the water inlet hose Preparation before washing Put in the laundries Put in the detergent Use the operation knobs Close the top lid Finish washing Disposal after washing Trouble shooting *Answers to question Packing list Specification...
  • Page 3: Names Of The Parts

    Names of the parts Top lid Detergent box Lint filter(Installed by user) Control panel seat Filter cover Inner tub Front control board Control panel sheet Pulsator Cabinet Adjustable foot Meaning and description of the symbols Warning sign Forbidding sign Please check if the power receptacle has good earthing condition before using to guarantee your safety.
  • Page 4: Safety Precautions

    Safety precautions Please insert the power cord into special receptacle with rated vol- tage.Be sure to use single-phase three pins receptacle.The earthing terminal of the receptacle must be earthed reliably.If possible,please adopt electric leakage protector. Earth If the power cord is bad, to avoid risk it is required to replace it by the technicians ofour special shop or the after-sale service department.
  • Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the bottom plate After you open the package, please lean the washing machine gently down on soft items ( like the towel cloth, blanket, etc.
  • Page 7: How To Change The Direction Of The Drain Hose

    How to change the direction of the drain hose 1.Dismantle the back cover of the washing machine. 2.Put down the drain hose. Take off the drainhose frame. As indicated in Figure 1, put thedrain hose into the cabinet. Then stretch onehand into the cabinet to nip the claw of the drain hose bush- ing to remove the claw fromoriginal position.
  • Page 8: Install The Water Inlet Hose

    Install the water inlet hose Confirm the water faucet Water faucet, suitable It is required that the front end shall be longer than 10cm. The outlet end surface of the faucet shall be flat and smooth. If not please file it to avoid leakage.
  • Page 9 Connection between the water inlet hose and the washing machine 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately. 2.Put the nut of the water inlet hose on the valve jointer.
  • Page 10: Preparation Before Washing

    1Preparation before washing Pay attention to followings before washing the laundries Check if Clear the the laundries pocket. Take has special out the coins, requirement sand, hairpins on washing etc. a. Check if the laundries are applicable for washing with machine. b.
  • Page 11: Put In The Laundries

    2 Put in the laundries 3 Add the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color.
  • Page 12: Use The Operation Knobs

    4 Use the operation knobsand buttons a Description of the function of the knobs and buttons Mode and meaning of the indicators Flashing: indicate the running program On: indicate the program about to run, or indicate the selected mode Flashing rapidly: indicate abnormal condition Process Selection Quick-...
  • Page 13 b .Steps of using the operation buttons and description of the steps Power botton " " Push the "Power" button to switch on or off the power. When the power is on, push it again to switch off the power. Water Level Medium High...
  • Page 14 Attention Even there's no water in the tub, the spinning will start after a certain period. Do not use the "Twice wash" program for the woolen laundries. Wash the laundries that are prone to lose colors separately from other laundries. The pulsator will not rotate unless the water is filled to selected water level.
  • Page 15: The Washing Is Finished

    * Total time: including the normal water inlet time, drain time, excluding the power off time. The total washing time may be influenced by the water inlet pressure and water level. * Spin time: the time from intermittent running to finishing * When selecting "...
  • Page 16: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box and set it on the control panel seat.
  • Page 17: Trouble-Shooting Answers To Question

    Trouble-shooting Answers to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 18 Paching list Name User's manual Components of the water inlet hose The end connecting to the washing machine Jointer connecting the water inlet hose and the water faucet The end connecting to the water inlet hose jointer Bottom plate Tapping screws Lint filter Fully automatic washing machine...
  • Page 19 WASHING POWDER BOX 0030505636...
