Haier XQB55-10 User Manual

Haier automatic washing machine user's manual
Hide thumbs

Advertisement

User's manual
Full Automatic Washing Machine
User's manual
This manual is for
XQB55-10
Please read this manual
carefully before using.
Retain it for future reference.
0030805169C

Advertisement

loading

  Related Manuals for Haier XQB55-10

  Summary of Contents for Haier XQB55-10

  • Page 1 User's manual Full Automatic Washing Machine User's manual This manual is for XQB55-10 Please read this manual carefully before using. Retain it for future reference. 0030805169C...
  • Page 2: Table Of Contents

    Contents Names of the parts...1 Safety precautions ...2 Installation and adjustment ...4 Install the water inlet hose...6 Preparation before washing ...8 Put in the laundries ...9 Usage of the detergent ...9 Use the operation buttons ...10 Close the top lid ...13 Finish washing ...13 Disposal after washing ...14 Trouble shooting Answer to question...15...
  • Page 3: Names Of The Parts

    Names of the par ts Top lid B Lint filter two Control panel Filter cover Inner tub Pulsator Control panel film Cabinet Meaning and description of the symbols Contents marked with that symbol are related to the safety Warning sign of the product and the personal safety of the users.
  • Page 4: Safety Precautions

    Safety precautions Please plug the plug on special receptacle with rated voltage. Be sure to use single- phase three pins receptacle. Ensure the earthing prong of the power receptacle is earthed reliably. Use leakage protector if possible. Do not damage the power cord, bend ,extend, twist, bind or alter it by force. Do not press or nip it with weight.
  • Page 5 Safety precautions Do not stretch hands into the working machine. It is dangerous even if the rotation is slow. Take special care of the children. Do not let the children climb the washing machine. Do not put any hot or heavy items (such as the kettle with hot water ) on the washing machine.
  • Page 6: Installation And Adjustment

    Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter Push the lint filter downward to location for lint filter. Adjust the installation position The largest allowed slope of the shank base of the machine is 2 .
  • Page 7: Usage Of The Drain Hose

    How to change the direction of the drain hose 1.Dismantle the back cover of the washing machine. 2.Put down the drain hose. Take off the drain hose frame. As indicated in Figure 1, put the drain hose into the cabinet. Then stretch one hand into the cabinet to nip the claw of the drain hose bush- ing to remove the claw from original...
  • Page 8: Install The Water Inlet Hose

    Install the water inlet hose Confirm the water tap Water tap,suitable It is required that the front end shall be longer than 10mm. The outlet end surface of the tap shall be flat and smooth. If not please file it to avoid leakage.
  • Page 9: Connection Between The Water Inlet Hose And The Washing Machine

    Connection between the water inlet hose and the washing machine 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens please contact our after-sale department immediately. 2.Put the nut of the water inlet hose on the valve jointer.
  • Page 10: Preparation Before Washing

    Preparation before washing Pay attention to followings before washing the laundries Confirm Clear the pocket. there's special Take out the requirement for coins , sand, the laundries. hairpins etc. a. Please check if the laundries are applicable for washing. b. Separate those not colorfast from other laundries. c.
  • Page 11: Put In The Laundries

    Put in the laundries Usage of the detergent Inlet box of the detergent How to use the whitener Fill water to decided level. Dilute the whitener with container. Pour it slowly into the washing tub. Avoid using whitener on laundries with color or pattern as they are prone to lose color.
  • Page 12: Use The Operation Buttons

    Use the operation buttons Description of the function of the buttons SURPLUS(MIN) To indicate -- during sensing. To indicate remaining min. During program running. To indicate remaining reserved time (hrs) during reservation period. To indicate fault symbols for abnormal conditions (see page 15) PROGRAM STATUS PROCEDURE STATUS STANDARD...
  • Page 13 Operating procedure and explanations for the buttons PROGRAM STATUS PROCEDURE STATUS STANDARD SOAK JEANS WASH GENTLE RINSE QUICK WASH SPIN WASH SPIN 1 Press the "POWER ON/OFF" button to switch on the power supply 2 Press the button of" select a suitable full-automatic program After switching on, the "Standard"...
  • Page 14 Attention Even there's no water in the tub, the spinning will start after a certain period. Do not use soak process for woolen laundries. Wash the laundries that are prone to lose colors separately from other laundries. The pulsator will not rotate unless the water is filled to selected water level.
  • Page 15: Close The Top Lid

    3 Press the "WATER LEVEL" button to select suitable water level After switching on the power, press the button "WATER LEVEL" to select a water level according to the load. Please refer to the button " Water level" on page 10. 4 Push the "...
  • Page 16: Disposal After Washing

    Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. When washing, lint filter must be used After using, please clean it in time.
  • Page 17: Trouble Shooting Answer To Question

    Trouble shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company.
  • Page 18: Packing List Specification

    Packing list Name User's manual Components of the water inlet hose Lint filter Bottom plate Tapping screws Full automatic washing machine Specification Water level/Water quantity (about) Water inlet pressure High/About 48 L Medium/About 37L Low/About 30L Very low/About 20L 0.03MPa-0.78MPa Quantity piece piece...

This manual is also suitable for:

Hwm58-020
