Inline Patch is covered by a 2 year warranty to be free from
defective workmanship and materials. In the event that the
Inline Patch needs repair, you must call us to get an au-
thorization, and then carefully pack and ship it to us. You
will pay for shipping to us and we will pay for return back to
you, UPS ground. No free repairs will be made if the defect
INLINE
PATCH
was caused by misuse, weather conditions, or other cause,
except for defective workmanship or materials.
THERE
ARE NO EXPRESSED OR IMPLIED WARRANTIES
Telephone Audio Interface
WHICH EXTEND BEYOND THE WARRANTY HERE
MADE.

User Guide

3/07
JK Audio
JK Audio, Inc.
1311 E 6th Street, Sandwich, IL 60548
USA
Voice: (815) 786-2929
Toll Free: 800-JK-Audio
Fax: 815-786-8502
Info@jkaudio.com
www.jkaudio.com
Copyright © 2007 JK Audio. All Rights Reserved.
