G E
LOBAL FF
Global Effects. This makes the effect
parameters of the chosen preset global for all
recalled presets.
T
UNING
Sets the tuning reference based on A-440.

MIDI Parameters

M C
IDI HANNEL
Sets the base MIDI Send and Receive
channel.
MIDI
FILTER
With this parameter you can cause the
VoiceWorks to ignore certain MIDI commands
and data.
P ignore program changes.
SX ignore system exclusive messages.
P+SX ignore program changes and system
exclusive messages.
S ID
YSEX
This parameter sets the MIDI sysex ID for the
VoiceWorks.
K Z
EYBOARD ONE
This parameter defines the note range of a
MIDI keyboard that the VoiceWorks will
recognize when creating harmonies.
For Example:
Above C4- would specify that the VoiceWorks
would respond only to MIDI notes
above C4 on the Keyboard.
V C
IB ONTROL
Vibrato Control. This control sets whether the
vibrato follows the onset and attack of the
model (Boost) or is instantaneous (Manual).
The Mod Wheel on most keyboards controls
the vibrato in both modes, boosting the preset
value in the Boost setting and starting from a
value of 0 in the Manual Setting for full manual
control.
N T
OTES RANS
Notes Mode Transpose. This transposes the
harmony voices in notes mode. The value
corresponds to octaves. This is useful when
used in conjunction with Keyboard Zone.
20
SETUP PARAMETERS
B R
END ANGE
Sets in semitones the range that MIDI pitch
bend information will alter the pitch of the
harmonies in Notes mode.
N 4C
OTES HAN
4 Channel Notes Mode.
Off: All harmony voices in Notes Mode will
respond to the base MIDI channel.
On: In Notes mode, Harmony Voice 1 responds
to the base MIDI channel; Harmony Voice
2 responds to the base MIDI channel +1
etc. All Harmony Voices will respond to
unique MIDI channels.
F 1-2-3
OOTSWITCH
For fully functional footpedal control, use the
Switch-3 three button foot pedal (other 3 but-
ton footswitches may work also). Each button
can be assigned to a special function. The
footswitch assignment options are listed below
and can be applied to each of the three but-
tons.
None Ignore this button.
SS+/- Increment/Hold:
Press and release: Increments
(changes on release).
Press and hold: After pressing for 2
seconds it will start to decrement.
In Song Mode this changes the Song
Step.
In Recall Mode this changes the
current Preset number.
SS+ Song Mode: Increment Song Step
Recall Mode: Increment current
preset.
SS- Song Mode: Decrement Song Step
Recall Mode: Decrement current
preset.
Byp Bypass
EffL Effect toggle mute - latched
EffM Effect toggle mute - momentary
(effects are on only when the pedal is
pressed)
HarL Harmony toggle mute
HarM Harmonies toggle mute - momentary
(harmonies are on only when the pedal
is pressed)
Hsus Harmony Hold.
