- Page 1 LAN25255HR/LAN35255HR 4+1 Gigabit Ethernet Unmanaged Switch User’s Manual BDM-610020088 Rev. A RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
- Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
-
Page 3: Revision History
Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual. -
Page 4: Table Of Contents
Onboard LEDs and External LED Connectors ......................... 14 IDAN Connections Module Handling Precautions ..............................15 Physical Characteristics ................................15 IDAN-LAN25255HR and IDAN-LAN35255HR .......................... 16 IDAN Twisted Pair Ethernet PORT1, PORT2, PORT3, and PORT4..................17 Steps for Installing ..................................17 Troubleshooting Additional Information PC/104 Specifications ................................ - Page 5 Table 6: Status LEDs ......................................11 Table 7: CN14 External LED Drive ..................................11 Table 8: CN15 External LED Drive ..................................12 Table 9: LAN25255HR and LAN35255HR IDAN Pin Out ............................17 | www.rtd.com LAN25255HR User’s Manual RTD Embedded Technologies, Inc.
-
Page 6: Introduction
The Intelligent Data Acquisition Node (IDAN™) building block can be used in just about any combination with other IDAN building blocks to create a simple but rugged 104™ stack. This module can also be incorporated in a custom-built RTD HiDAN™ or HiDANplus High Reliability Intelligent Data Acquisition Node. -
Page 7: Contact Information
If you are having problems with you system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the... -
Page 8: Specifications
5V Current between buses BUS5 PCIe/104 Bus Differential Output Voltage DC Differential TX Impedance 95.2 116.9 Ω Differential Input Voltage 0.175 DC Differential RX Impedance 92.7 115.8 Ω Electrical Idle Detect Threshold | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 9: Board Connection
Physical Characteristics Weight: Approximately 55 g (0.12 lbs.) Dimensions: 90.17 mm L x 95.89 mm W (3.550 in L x 3.775 in W) Figure 2: Board Dimensions | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 10: Connectors And Jumpers
JP2 LED Power CN14 External LEDs CN15 External LEDs for CN5 & CN7 Ports for CN9 & CN11 Ports CN1 & CN2: PCIe/104 Connector Figure 3: LAN25255HR/LAN35255HR Board Connections 3.3.1 I/O C XTERNAL ONNECTORS AND UMPERS CN5/7/9/11: RJ-45 connectors for Ethernet access CN4/6/8/10: 2x5 0.1”... -
Page 11: Status Leds
If JP1 1-2 is shorted these pins will be ground 2, 4, 6, 8, 10, 12 Depends on JP2 setting If JP1 2-3 is shorted these pins will be 3.3 volts Table 7: CN14 External LED Drive | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 12: Bus Connectors
The PCIe connector is the connection to the system CPU. The position and pin assignments are compliant with the PCI/104-Express Specification. (See PC/104 Specifications on page 19) The LAN25255HR and LAN35255HR are “Universal” boards, and can connect to either a Type 1 or Type 2 PCIe/104 connector. CN3: PCI Connector The PCI connector is the connection to PCI peripheral modules. -
Page 13: Steps For Installing
10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 4: Example 104™Stack | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 14: Functional Description
Gigabit Ethernet switch. This switch contains 5 full-duplex 10/100/1000 BASE-TX Ethernet transceivers for network interfacing. One of these ports is used in conjunction with the WG82574IT for a host port. This allows the LAN25255HR to work as its own mini-server in a stacked system. -
Page 15: Idan Connections
Weight: Approximately 0.21 Kg (0.46 lbs.) Dimensions: 151.972 mm L x 129.978 mm W x 16.993 mm H (5.983 in L x 5.117 in W x 0.669 in H) Figure 5: IDAN Dimensions | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 16: Idan-Lan25255Hr And Idan-Lan35255Hr
IDAN-LAN25255HR and IDAN-LAN35255HR This utilityModule is also available in an IDAN configuration. The IDAN module is shown below. Figure 3: IDAN-LAN25255HR and IDAN-LAN35255HR Figure 4: IDAN-LAN25255HR and IDAN-LAN25255HR Front View 9 pin “D”: male Module Part#: Adam Tech DE09PD Mating Part#:... -
Page 17: Idan Twisted Pair Ethernet Port1, Port2, Port3, And Port4
MDI_A- Transmit - MDI_D- Not Used Table 9: LAN25255HR and LAN35255HR IDAN Pin Out Steps for Installing Always work at an ESD protected workstation, and wear a grounded wrist-strap. Turn off power to the IDAN system. Remove the module from its anti-static bag. -
Page 18: Troubleshooting
If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 19: Additional Information
A copy of the latest PC/104 specifications can be found on the webpage for the PC/104 Embedded Consortium: www.pc104.org PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com LAN25255HR/LAN35255HR User’s Manual RTD Embedded Technologies, Inc. -
Page 20: Limited Warranty
During the one year warranty period, RTD Embedded Technologies will repair or replace, at its option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to RTD Embedded Technologies. All replaced parts and products become the property of RTD Embedded Technologies. - Page 21 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2011 by RTD Embedded Technologies, Inc. All rights reserved.
