- Page 1 LAN35H08HR-D & LAN35E08HR-D, LAN35H08HR-RJ & LAN35E08HR-RJ, IDAN-LAN35H08HR & IDAN-LAN35E08HR Gigabit Ethernet Unmanaged Switches User’s Manual BDM-610020116 Rev. B LAN35H08HR-D LAN35H08HR-RJ RTD Embedded Technologies, Inc. AS9100 and ISO 9001 Certified...
- Page 2 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com...
-
Page 3: Revision History
Failure to follow the instructions found in this manual may result in damage to the product described in this manual, or other components of the system. The procedure set forth in this manual shall only be performed by persons qualified to service electronic equipment. Contents and specifications within this manual are given without warranty, and are subject to change without notice. RTD Embedded Technologies, Inc. shall not be liable for errors or omissions in this manual, or for any loss, damage, or injury in connection with the use of this manual. -
Page 4: Table Of Contents
IDAN Versions ..................................21 5.3.1 IDAN-LAN35H08HR & IDAN-LAN35E08HR Steps for Installing ..................................24 Troubleshooting Additional Information PC/104 Specifications ................................26 PCI and PCI Express Specification ............................26 Limited Warranty | www.rtd.com LAN35H08HR-D & LAN35E08HR-D User’s Manual RTD Embedded Technologies, Inc. - Page 5 Table of Figures Figure 1: LAN35H08HR-D & LAN35E08HR-D Board Dimensions ........................10 Figure 2: LAN35H08HR-RJ & LAN35E08HR-RJ Board Dimensions ........................11 Figure 3: LAN35H08HR-D & LAN35E08HR-D Board Connections ........................12 Figure 4: LAN35H08HR-RJ & LAN35E08HR-RJ Board Connections ........................13 Figure 5: RJ-45 Jack Connector ..................................... 14 Figure 6: External LED Drive Circuit ..................................
-
Page 6: Introduction
Packetized serial traffic with PCI Express Split Completion protocol Data Link Layer Cyclic Redundancy Check (CRC) generator and checker Automatic Retry of bad packets In-band interrupts and messages Message Signaled Interrupt (MSI) support | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 7: Ordering Information
The Intelligent Data Acquisition Node (IDAN™) building block can be used in just about any combination with other IDAN building blocks to create a simple but rugged 104™ stack. This module can also be incorporated in a custom-built RTD HiDAN™ or HiDANplus High Reliability Intelligent Data Acquisition Node. -
Page 8: Contact Information
If you are having problems with you system, please try the steps in the Troubleshooting section of this manual. For help with this product, or any other product made by RTD, you can contact RTD Embedded Technologies technical support via the... -
Page 9: Specifications
Down and Up stacking plus 8 ports linked at 1Gbps PCIe/104 Bus Differential Output Voltage 95.2 116.9 Ω Differential TX Impedance Differential 0.175 Input Voltage 92.7 115.8 Ω Differential Impedance Electrical Idle Detect Threshold | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 10: Board Connection
LAN35x08HR-RJ Weight: Approximately 109 g (0.24 lbs.) • Dimensions: 90.17 mm L x 95.89 mm W (3.550 in L x 3.775 in W) CN6 on LAN35H08HR only Figure 1: LAN35H08HR-D & LAN35E08HR-D Board Dimensions | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 11: Figure 2: Lan35H08Hr-Rj & Lan35E08Hr-Rj Board Dimensions
CN6 on LAN35H08HR only Figure 2: LAN35H08HR-RJ & LAN35E08HR-RJ Board Dimensions | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 12: Connectors
CN8 (on bottom) Link Speed/ACT LED CN6: Power • LAN35E08HR – Expansion Down Link Switch Expansion Down Expansion Up Link LAN35H08HR only LAN35E08HR only Figure 3: LAN35H08HR-D & LAN35E08HR-D Board Connections | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 13: External I/O Connectors
Receive - MDI_C+ Not Used MDI_C- Not Used MDI_A+ Transmit + MDI_A- Transmit - MDI_D+ Not Used MDI_D- Not Used Shield Ground Shield Ground Table 4: Ethernet Signal Assignments | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 14: Rj45 Twisted Pair Ethernet, Port 1 - Port 8 (Lanx08Hr-Rj Only)
CN7 and CN9 are the status LED signals that are buffered and able to sink 24 mA. Each signal is driven low when active and tri-stated when inactive, has a 374 Ohm current limiting resistor, and supports being pulled up to +5 volts. The drive circuit is shown below: | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 15: Cn1 (Top) & Cn2 (Bottom) Bus Connectors
10. Attach any necessary cables to the PC/104 stack. 11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 16: Figure 7: Example 104™Stack
Figure 7: Example 104™Stack | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 17: Functional Description
Figure 9: IDAN-LAN35H08HR Block Diagram The Figures below shows the functional block diagram of the LAN35E08HR and IDAN-LAN35E08HR. The various parts of the block diagram are discussed in the following sections. | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 18: Broadcom Gig-Ethernet Switch
Manager in Windows). Until this is enabled, the Intel controller will drop any Jumbo frames it receives. Note that to use Jumbo frames effectively, all devices connected to the network must have Jumbo frames enabled, AND must agree on the frame size (mismatched frame sizes will result in dropped packets). | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 19: Intel Wg82574It Gigabit Ethernet Controller
10/100/1000M. There are two 0.1 inch DIL connectors (CN7 & CN8) that can be wired to external LED circuitry. They carry a link/activity signal for each port. | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 20: Idan Connections
Weight: Approximately 0.21 Kg (0.46 lbs.) • Dimensions: 151.972 mm L x 129.978 mm W x 16.993 mm H (5.983 in L x 5.117 in W x 0.669 in H) Figure 12: IDAN Dimensions | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 21: Idan Versions
37-pin “D” connectors into eight Ethernet ports into RJ-45 connectors. It has two cables with 37-pin “D” connectors on one end and four 9-pin “D” on the other end and eight 9-pin “D” to RJ45 adapters. | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 22: Figure 13: Idan-Lan35H08Hr Or Idan-Lan38E08Hr Front View
Transmit - PORT 1-8 MDI_D+ Not Used PORT 1-4 MDI_D- Not Used PORT 1-9 Shield Ground Shield Ground PORT 1-5 Table 10: IDAN-LAN35H08HR and IDAN-LAN35E08HR Front Connector Pin Out | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 23: Figure 14: Idan-Lan35H08Hr Or Idan-Lan38E08Hr Rear View
Transmit - PORT 5-8 MDI_D+ Not Used PORT 5-4 MDI_D- Not Used PORT 5-9 Shield Ground Shield Ground PORT 5-5 Table 11: IDAN-LAN35H08HR and IDAN-LAN35E08HR Rear Connector Pin Out | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 24: Steps For Installing
11. Re-connect the power cord and apply power to the stack. 12. Boot the system and verify that all of the hardware is working properly. Figure 15: Example IDAN System | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 25: Troubleshooting
If problems persist, or you have questions about configuring this product, contact RTD Embedded Technologies via the following methods: Phone: +1-814-234-8087 E-Mail: techsupport@rtd.com Be sure to check the RTD web site (http://www.rtd.com) frequently for product updates, including newer versions of the board manual and application software. | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 26: Additional Information
PCI and PCI Express Specification A copy of the latest PCI and PCI Express specifications can be found on the webpage for the PCI Special Interest Group: www.pcisig.com | www.rtd.com LAN35H08HR & LAN35E08HR User’s Manual RTD Embedded Technologies, Inc. -
Page 27: Limited Warranty
During the one year warranty period, RTD Embedded Technologies will repair or replace, at its option, any defective products or parts at no additional charge, provided that the product is returned, shipping prepaid, to RTD Embedded Technologies. All replaced parts and products become the property of RTD Embedded Technologies. - Page 28 RTD Embedded Technologies, Inc. 103 Innovation Boulevard State College, PA 16803 USA Telephone: 814-234-8087 Fax: 814-234-5218 www.rtd.com sales@rtd.com techsupport@rtd.com Copyright 2017 by RTD Embedded Technologies, Inc. All rights reserved.
