- Page 1 OperatiOn Manual Streetpro SerieS MODel Sp1e16a prOfeSSiOnal paveMent Saw (5Hp eleCtriC MOtOr) Revision #0 (04/14/10) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES. pn: 38257...
-
Page 2: Proposition 65 Warning
ALWAYS work in a well ventilated area, and work with approved safety equipment, such as dust masks that are specially designed to filter out microscopic particles. page 2 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 3: Silicosis/Respiratory Warnings
NIOSH/MSHA for the materials being used. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 3... -
Page 4: Table Of Contents
Maintenance ............. 21-22 Specifications/Dimensions ........13 Troubleshooting (Electric Motor) ......22 General Information ..........14 Troubleshooting (Saw) ........... 23 NOTICE Specifications are subject to change without notice. page 4 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) - Page 5 Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 5...
-
Page 6: Training Checklist
Starting a cut. Pavement cutting techniques. Stopping a cut. Restart after stopping blade within work surface — explanation Shutdown of machine. Lifting of machine. Machine transport and storage. page 6 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 7: Daily Pre-Operation Checklist
Daily pre-OperatiOn CHeCkliSt Daily pre-operation Checklist Hardware and damage check Condition of blade ON/OFF switch Condition of power cable Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 7... -
Page 8: Safety Information
CoulD result in DeaTH or SeriouS iNJury. CauTioN Indicates a hazardous situation which, if not avoided, CoulD result in MiNor or MoDeraTe iNJury. NOTICE Addresses practices not related to personal injury. page 8 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 9: General Safety
„ No one other than the operator is to be in the working area when the equipment is in operation. „ Do NoT use the equipment for any purpose other than its intended purposes or applications. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 9... - Page 10 „ alWayS store equipment properly when it is not being used. Equipment should be stored in a clean, dry location out of the reach of children and unauthorized personnel. page 10 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10)
-
Page 11: Blade Safety
„ Do NoT drop the diamond blade on ground or surface. „ Ensure that the blade is mounted for proper operating direction. „ Adhere to the blade manufacturer’s recommendations on handling, storage and safe usage of blades. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 11... -
Page 12: Safety Information
„ Contact your country's Department of Public Works or recyling agency in your area and arrange for proper disposal of any rubber components associated with this equipment. page 12 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 13: Specifications/Dimensions
Max Width 21.5 In. (55 cm) Rear Wheel Base 17.0 In. (40 cm) Front Wheel Base 10.0 In. (25.4 cm) Handle Bar Width 21.5 In. (55 cm) Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 13... -
Page 14: General Information
Refer to the electric motor Owner's Manual for specific instructions regarding motor operation and maintenance practices. The SP1E16A saw is powered by a 5.0 HP, 230 VAC single- page 14 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 15: Controls And Components
19.5 Amps 7. Belt Tension adjuster — Adjusts belt tension. 16. power Cable — Connect to a 230 VAC, power source @ 19.5 Amps. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 15... -
Page 16: Inspection/Setup
Table 3. extension Cord Sizes Motor Voltage 50' long 75' long 100' long single No. 10 No. 8 No. 6 Figure 3. Blade Guard phase page 16 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) - Page 17 V-belt alignment must be rechecked after adjusting V-belt: belt tension. 1. Remove the bolts that secure the V-belt cover (Figure 4) to the saw frame. V-BELT COVER Figure 4. V-Belt Cover Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 17...
-
Page 18: Blades
2. Stress relief Holes (gullets) — Check the steel core RPM. for cracks that may have propagated from the slots and/or gullets. Cracks indicate extreme fatigue failure and if sawing continues, catastrophic failure will occur. page 18 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 19: Blade Speed
WarNiNg Dropping or forcing the blade onto the cutting surface can severely damage the diamond blade and may cause serious damage to the saw and bodily harm. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 19... -
Page 20: Initial Startup
NeVer operate saw with V-belt cover removed. 3. Before the saw is placed into operation, run the motor for several minutes. Check for noises that would be associated with loose guards and/or covers. page 20 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 21: Operation
2. Disconnect the electric motor’s extension cord from jam nuts on the pointer until the pointer follows the its power source. same path as the blade. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 21... -
Page 22: Troubleshooting (Electric Motor)
Check power source. Electric motor RPM's too low. Low voltage? Check input voltage (230 VAC). Electric motor RPM's too high. High voltage? Check input voltage (230 VAC). page 22 — Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) -
Page 23: Troubleshooting (Saw)
Multiquip for information. Excessive force applied to blade while DO NOT force the blade in the cut. Apply a cutting? slow and steady pace when sawing. Sp1e16a paVeMeNT SaW • operaTioN MaNual — reV. #0 (04/14/10) — page 23... - Page 24 © COPYRIGHT 2010, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
