Door Panels
mm
k
741/4''
(188.6 cm)
!
Freezer
Door Panel
Refrigerator
Door Panel
W;_[ot':III I[e] ! i
Pinch Hazard
Installation of door panels with less than a 3/8"(0.95 cm) gap
between the door panel and the adjacent cabinet increases
the risk of potential pinching.
Model 42 48
Reveal %" %" %" %"
A 17%6" 171¾6" 20¼6" 20¾6"
(44.61 cm) (45.24 cm) (50.96 cm) (50.17 cm)
B 23%6" 231¾6'' 271/16 '' 27¾6"
(59.85 cm) (60.48 cm) (68.74 cm) (69.37 cm)
Grille Panel
Integrated Installation - Full Height Grille - Open Soffit
_ C }'l
65/8'' + I
Top Grille Panel
I
Model 42 48
Reveal %" %" %" %"
C 411/4" 413/4" 471/4 '' 473/4"
(104.76 cm) (106.05 cm) (120.02 cm) (121.29 cm)
Standard Installation - Flush Grille - Open or Closed Soffit
,.. ore) I n,,o I
+
I- E
Model 42 48
Reveal %" %" %" %"
D 41 ¼" 413/4" 471/4 '' 473/4"
(104.76 cm) (106.05 cm) (120.02 cm) (121.29 cm)
E 41 ¼" 413/4" 471/4 '' 473/4 ''
(104.76 cm) (106.05 cm) (120.02 cm) (121.29 cm)
IMPORTANT: The grille panel height, shown in the Standard
Installation Flush Grille graphic, allows for an air gap critical to
refrigerator performance.
INSTALLATIONINSTRUCTIONS
Be ge eros"
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
IMPORTANT:
• Do not remove the film covering until the refrigerator is in its
operating location.
• All four leveling legs must contact the floor to support and
stabilize the full weight of the refrigerator.
• Keep the cardboard shipping piece or plywood under the
refrigerator until it is installed in the operating location.
1. Remove and save the literature package and hardware kit
located inside the refrigerator. Remove and save the literature,
grille, and trim taped to the outside of the refrigerator.
NOTE: Do not remove tape and door bracing until the
refrigerator is in its final location.
