- Page 1 2010 North American L.A. Spas Entry-Level Owner’s Manual...
-
Page 3: Table Of Contents
TABLE OF CONTENTS LETTER OF INTRODUCTION ......2 WATER TREATMENT ........17 Sanitizers ............17 SPA RECORD KEEPING INFORMATION ..3 Bromine ............17 Chlorine ............17 IMPORTANT SAFETY INSTRUCTIONS ... 4 Super Chlorination ........... 17 HYPERTHERMIA INFORMATION ....6 Shock Treatments (Potassium Peroxymonosulfate) ......... -
Page 4: Letter Of Introduction
LETTER OF INTRODUCTION Dear Valued Customer: Congratulations. On behalf of the entire L.A. Spas family, thank you for your decision to purchase one of our products. Every effort has been made to ensure the accuracy of this owner’s manual, however, L.A. Spas reserves the right to modify and improve the product without notice. -
Page 5: Spa Record Keeping Information
SPA RECORD KEEPING INFORMATION Serial Number Location The serial number is located in the lower right corner of the equipment access panel on the front of the spa. PLEASE FILL IN THE INFORMATION BELOW Spa Information: Model _______________ Color _______________ Serial # ___________________ Owner Information: Name _____________________________________ Date of Purchase ___________ Address _______________________________________________________________... -
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS READ THE ENTIRE OWNER’S MANUAL & SAFETY INSTRUCTIONS BEFORE OPERATING THE SPA. When installing the spa, basic safety precautions should always be followed, including the following: WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised by an adult at all times. - Page 7 c. Before entering a spa, the user should check the water temperature with an accurate thermometer since tolerance of water temperature regulating devices can vary and not reflect the proper temperature. d. The use of alcohol, drugs, or medication before or during spa use is prohibited and may lead to unconsciousness with the possibility of drowning.
-
Page 8: Hyperthermia Information
HYPERTHERMIA INFORMATION Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above normal body temperature of 98.6°F (37°C). The symptoms of hyperthermia include: Dizziness Fainting Drowsiness Lethargy Increase in internal body temperature The effects of hyperthermia include: Unawareness of impending hazard Failure to perceive heat Failure to recognize the need to exit spa... -
Page 9: Safety Sign
This sign has been mounted permanently to the front of the spa. Replacement signs can be obtained from: L.A. Spas, Inc. 1311 N. Blue Gum Street Anaheim, CA 92806... -
Page 10: Spa Equipped Safety Devices
SPA EQUIPPED SAFETY DEVICES Your spa is equipped with the following safety features: Overheat Protection – A water temperature sensor circuit in the system will monitor the water temperature. If the temperature reaches 112°F (44°C), the pump and all accessories will shut off. The spa will resume normal operation when the water temperature drops to 109°F (42°C). -
Page 11: Important Safety Instructions For Canada
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA CSA SAFETY INFORMATION READ AND FOLLOW ALL INSTRUCTIONS When using this electrical equipment, basic safety precautions should always be followed, including the following: A colored terminal or a terminal marked G, GR, Ground, Grounding, or the grounding symbol is located inside the supply terminal box/compartment. - Page 12 AVERTISSEMENT: POUR EVITER L’EVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND ON S’Y TROUVE. WARNING: Pregnant or possibly pregnant women should consult a physician before using a spa or hot tub.
-
Page 13: Installation Instructions
INSTALLATION INSTRUCTIONS SAVE THESE INSTRUCTIONS Read all instructions in this manual prior to having your spa installed at the selected location, whether indoors or outdoors. IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID THE WARRANTY. SURFACE AND PAD REQUIREMENTS We recommend that your new spa be placed on a 4”... -
Page 14: Electrical Connection
It is the responsibility of the spa owner to ensure that a qualified electrician performs the electrical installation. This installation must be in accordance with the National Electrical Code; local and state electrical codes; and the manufacturer’s instructions. This equipment has been designed to operate on 240V/120V 60Hz alternating current. This spa must be connected to a dedicated branch circuit. -
Page 15: Initial Start-Up Instructions
INITIAL START-UP INSTRUCTIONS DO NOT TURN ON THE POWER TO THE SPA WHEN THE SPA IS EMPTY OR PARTIALLY FILLED. Ensure the circuit breaker to the spa is off. Rotate all the jets in the spa to a counterclockwise position (fully open position). Ensure the gate valve is fully open. -
Page 16: Operating Instructions
OPERATING INSTRUCTIONS CONTROL PANEL This easy to use control has been pre-programmed to be “plug and play”. Turn the power on, adjust the desired temperature and the system is ready to go. If there are situations that require additional filtering time, the filter settings can be customized to any special requirements. -
Page 17: Filtration
FILTRATION The spa is factory programmed to filter two times a day for 1 hour. In most cases, this is sufficient filtration. However, the cycle duration can be modified between 1 and 8 hours in increments of 1 hour. The first cycle begins 6 minutes after the initial start-up of the spa, and the second cycle is 12 hours later. -
Page 18: Water Balance
WATER BALANCE WATER CHEMISTRY Maintaining proper water chemistry is imperative to maintaining safe water and preventing possible damage to your spa and spa components. START-UP PROCEDURES 1. Fill spa to correct level (approximately 4” above the top of the filter cartridge). 2. -
Page 19: Water Treatment
WATER TREATMENT SANITIZERS The importance of maintaining an adequate levels of sanitizer in your spa cannot be overemphasized. Warm water presents a fertile environment for the growth of bacteria and viruses. This growth is prevented when adequate sanitizer levels are continuously maintained. WARNING –... -
Page 20: Shock Treatments (Potassium Peroxymonosulfate)
WATER TESTING It is recommended that you test your spa water regularly with an accurate test kit or test strip. These are available from your local authorized L.A. Spas dealer. Be sure to follow the chemical manufacturer’s instructions for chemical use. -
Page 21: Spa Care
You may wax the spa surface if you choose. This adds a protective coating on the finish. Use a spa wax only. Follow the instructions on label of wax product. Consult your L.A. Spas dealer. CARE OF SPA CABINET (THERMOGUARD CABINET) Your ThermoGuard cabinet requires little or no maintenance of any kind. -
Page 22: Draining The Spa
During freezing conditions, check your spa frequently to ensure proper operation. Be sure to check your spa after any power failure to ensure the spa is operational. For additional information on winterizing your spa, contact your local L.A. Spas dealer. WARRANTY SERVICE INFORMATION Your spa warranty gives you specific coverage. -
Page 23: Troubleshooting
TROUBLESHOOTING HEATING SYSTEM Symptom Problem Corrective Action Spa water cold / spa not 1. Temperature setting is not at 1. Increase temperature heating user select. Power reset caused default setting. 2. Spa in economy mode 2. Reset to standard mode. 3. - Page 24 ELECTRICAL SYSTEM Symptom Problem Corrective Action Spa will not turn on in any 1. No power 1. Check circuit breaker and/or mode GFCI 2. Control panel unresponsive 2. Turn power off spa then back 3. Control panel still not working 3.
- Page 25 ERROR CODES Error Code Description Corrective Action Overheat – The spa has shut down. One of DO NOT ENTER THE WATER. the sensors has detected that the spa water Remove the spa cover and allow water is 118°F (47.8°C). to cool. Once the heater has cooled, reset by pressing any key.
- Page 26 WIRING DIAGRAM FOR 120V SETUP WIRING DIAGRAM FOR 240V SETUP...
