- Page 1 2011 North American L.A. Spas IN-FIT Swim Spa Owner’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS LETTER OF INTRODUCTION ......2 WATER BALANCE ......... 20 Water Chemistry ..........20 SPA RECORD KEEPING INFORMATION ..3 Start-Up Procedures ........20 Water Quality ........... 20 IMPORTANT SAFETY INSTRUCTIONS ... 4 pH Control ............20 HYPERTHERMIA INFORMATION ....6 Total Alkalinity .......... -
Page 3: Letter Of Introduction
LETTER OF INTRODUCTION Dear Valued Customer: Congratulations. On behalf of the entire L.A. Spas family, thank you for your decision to purchase one of our products. Every effort has been made to ensure the accuracy of this owner’s manual, however, L.A. Spas reserves the right to modify and improve the product without notice. -
Page 4: Spa Record Keeping Information
SPA RECORD KEEPING INFORMATION Serial Number Location The serial number is located in the lower right corner of the equipment access panel on the front of the spa. PLEASE FILL IN THE INFORMATION BELOW Spa Information: Model _______________ Color _______________ Serial # ___________________ Owner Information: Name _____________________________________ Date of Purchase ___________ Address _______________________________________________________________... -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS READ THE ENTIRE OWNER’S MANUAL & SAFETY INSTRUCTIONS BEFORE OPERATING THE SPA. When installing the spa, basic safety precautions should always be followed, including the following: WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised by an adult at all times. -
Page 6: Save These Instructions
L.A. Spas authorized dealer. -
Page 7: Hyperthermia Information
HYPERTHERMIA INFORMATION Hyperthermia occurs when the internal temperature of the body reaches a level several degrees above normal body temperature of 98.6°F (37°C). The symptoms of hyperthermia include: Dizziness Fainting Drowsiness Lethargy Increase in internal body temperature The effects of hyperthermia include: Unawareness of impending hazard Failure to perceive heat Failure to recognize the need to exit spa... -
Page 8: Safety Sign
This sign has been mounted permanently to the front of the spa. Replacement signs can be obtained from: L.A. Spas, Inc. 1311 N. Blue Gum Street Anaheim, CA 92806... -
Page 9: Spa Equipped Safety Devices
SPA EQUIPPED SAFETY DEVICES Your spa is equipped with the following safety features: Overheat Protection – A water temperature sensor circuit in the system will monitor the water temperature. If the temperature reaches 112°F (44°C), the pump and all accessories will shut off. The spa will resume normal operation when the water temperature drops to 109°F (42°C). -
Page 10: Important Safety Instructions For Canada
IMPORTANT SAFETY INSTRUCTIONS FOR CANADA SAFETY INFORMATION READ AND FOLLOW ALL INSTRUCTIONS When using this electrical equipment, basic safety precautions should always be followed, including the following: A colored terminal or a terminal marked G, GR, Ground, Grounding, or the grounding symbol is located inside the supply terminal box/compartment. - Page 11 WARNING: Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid unconsciousness and possible drowning. AVERTISSEMENT: POUR EVITER L’EVANOUISSEMENT ET LA NOYADE EVENTUELLE, NE PRENDRE NI DROGUE NI ALCOOL AVANT D’UTILISER UNE CUVE DE RELAXATION NI QUAND ON S’Y TROUVE.
-
Page 12: Installation Instructions
INSTALLATION INSTRUCTIONS Read all instructions in this manual prior to having your spa installed at the selected location, whether indoors or outdoors. IMPROPER INSTALLATION MAY RESULT IN EQUIPMENT DAMAGE AND VOID THE WARRANTY. SURFACE AND PAD REQUIREMENTS We recommend that your new spa be placed on a 6” (15 cm) thick reinforced concrete pad or level foundation capable of supporting the total filled weight of your specific spa model. -
Page 13: Electrical Connection
This spa must be connected to a dedicated branch circuit. The electrical supply for this spa must include a suitably rated switch or circuit breaker to open all ungrounded supply conductors to comply with Section 422-20 of the National Electric Code (NEC). A disconnect switch must be located where visible, not less than 5 feet (1.5 m) from the spa and not to exceed 50 (15 m) feet from the spa. -
Page 14: Initial Start-Up Instructions
INITIAL START-UP INSTRUCTIONS DO NOT TURN ON THE POWER TO THE SPA WHEN THE SPA IS EMPTY OR PARTIALLY FILLED. Ensure the circuit breaker to the spa is off. Rotate all the jets in the spa to a counterclockwise position (fully open position). Ensure the gate valve is open fully. -
Page 15: Operating Instructions
OPERATING INSTRUCTIONS CONTROL PANEL ML900 Main Control Panel ML400 Auxiliary Control Panel These easy to use controls have been pre-programmed to be “plug and play”. Turn the power on, adjust the desired temperature and the system is ready to go. If there are situations that require additional filtering time, the filter settings can be customized to any special requirements. -
Page 16: Economy Mode
Leveler key is associated with the leveler swim jet. Press the Leveler key once to turn on the leveler swim pump. Press the Leveler key again to turn off the pump. Spa Jets key: Spa Jets key is associated with the therapy jets. Press the Spa Jets key once to turn the spa pump on low speed. -
Page 17: Standard Mode
The Mode/Prog key is used to switch between program modes. The spa is factory equipped with three program modes: Standard, Economy, and Sleep modes. Press the Mode/Prog key to enter mode programming, press the Cool key to cycle through to desired mode. The control panel display flashes until confirmed. -
Page 18: Standby Mode
increments of 5 minutes. Press the Mode/Prog key to accept the minute setting and proceed to programming the filter 2 start time. Filter 2 Start Time: SET FILTER 2 After setting the end time of the first filter cycle, the control panel will display and a flashing “START TIME”... -
Page 19: Water Features And Water Feature Control Valve
WATER FEATURES AND WATER FEATURE CONTROL VAVLE Your spa may be equipped with water features. They are turned on/off by the water feature control valve. Turn the valve handle clockwise to turn the water features on, and counterclockwise to turn the water features off. - Page 20 Track Up/Down – Press the Track Up/Down to function the followings. • Radio mode: To select the next or previous preset station. Press and hold the Track Up/Down key to seek up or down to the next station. Scan mode stops as soon as a strong station is found. •...
-
Page 21: Water Balance
WATER BALANCE WATER CHEMISTRY Maintaining proper water chemistry is imperative to maintaining safe water and preventing possible damage to your spa and spa components. START-UP PROCEDURES 1. Fill spa to correct level (approximately 4” above the top of the filter cartridge). 2. -
Page 22: Water Treatment
WATER TREATMENT SANITIZERS The importance of maintaining an adequate levels of sanitizer in your spa cannot be overemphasized. Warm water presents a fertile environment for the growth of bacteria and viruses. This growth is prevented when adequate sanitizer levels are continuously maintained. WARNING –... -
Page 23: Shock Treatments (Potassium Peroxymonosulfate)
WATER TESTING It is recommended that you test your spa water regularly with an accurate test kit or test strip. These are available from your local authorized L.A. Spas dealer. Be sure to follow the chemical manufacturer’s instructions for chemical use. -
Page 24: Spa Care
Step 2: Adjust pH – ideal range is between 7.4-7.6. Test water, follow directions on manufacturer’s label, and add the required amount of spa chemicals with the jets on. Step 3: Adjust bromine/chlorine – ideal range is between 2-3 ppm chlorine and 3-5 ppm bromine (4-6 ppm for heavy spa usage). -
Page 25: Draining The Spa
Use a spa wax only. This adds a protective coating on the finish of your spa cover. Follow the instructions on the label of the wax product. Lastly, consult your L.A. Spas Authorized Dealer for further questions regarding your Therm-Rite spa cover. -
Page 26: Troubleshooting
TROUBLESHOOTING HEATING SYSTEM Symptom Problem Corrective Action Spa water cold / spa not 1. Temperature setting is not at 1. Increase temperature heating user select. Power reset caused default setting. 2. Spa in economy mode 2. Reset to standard mode. 3. - Page 27 ELECTRICAL SYSTEM Symptom Problem Corrective Action Spa will not turn on in any 1. No power 1. Check circuit breaker and/or mode GFCI 2. Control panel unresponsive 2. Turn power off spa then back 3. Control panel still not working 3.
- Page 28 DIAGNOSTIC MESSAGES Message Description Corrective Action Overheat – The spa has shut down. DO NOT ENTER THE WATER. One of the sensors has detected that Remove the spa cover and allow water the spa water is 118°F (47.8°C). to cool. Once the heater has cooled, HTR TEMP LMT reset by pressing any key.
- Page 29 DIAGNOSTIC MESSAGES (continued) Message Description Corrective Action PRIMING MODE Spa goes to priming mode during the See Initial Start-Up Instructions section initial start-up. (page 13). TAKES 4 MIN Temperature unknown. After the spa pump has been running for 1 minute, the temperature will be displayed.
-
Page 30: Wiring Diagram
WIRING DIAGRAM rev. 2011-5-26...
