USER’S MANUAL Model No. WLEX31212.0 Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? If you have questions, or if parts are damaged or missing, DO NOT CONTACT THE STORE; please contact Customer Care.
If a decal is missing or illegible, see the front cover of this manual and request a free replacement decal. Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. WESLO is a registered trademark of ICON IP, Inc.
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your exercise bike before using your exercise bike. ICON assumes no responsibility for personal injury or property damage sustained by or through the use of this product.
BEFORE YOU BEGIN Thank you for selecting the new WESLO PURSUIT CT reading this manual, please see the front cover of this ® 2.2 exercise bike. Cycling is an effective exercise for manual. To help us assist you, note the product model increasing cardiovascular fitness, building endurance, number and serial number before contacting us.
• In addition to the included tool(s), assembly video, go to requires the following tool(s): http://productvideo.co/ one Phillips screwdriver assembly/kmart/weslo or use your mobile one adjustable wrench phone or smartphone to read the QR code at the one pair of pliers right.
Page 6
2. If there is a cardboard tube (not shown) on the front the Frame (1), remove and discard the attachment screw and the cardboard tube. Set a sturdy piece of packing material under the front of the Frame (1). Have a second person hold the Frame to prevent it from tipping while you complete this step.
Page 7
4. Have a second person hold the Handlebar (4) near the Upright (3). Insert the two Pulse Wires (19) into the Upright, and pull them out of the top of the Upright. Tip: Avoid pinching the Pulse Wires (19). Open the indicated clamp on the Upright (3), hold the Handlebar (4) inside the clamp, and close the clamp.
Page 8
6. Have a second person hold the Console (2) near the Upright (3). Connect the wires on the Console to the Extension Wire (38) and to the Pulse Wires (19). Insert the excess wire into the Upright (3) or into the Console (2).
Page 9
9. Identify the Right Pedal (16). Using an adjustable wrench, firmly tighten the Right Pedal (16) clockwise into the right arm of the Crank (35). Tighten the Left Pedal (not shown) counter- clockwise into the left arm of the Crank (not shown).
HOW TO USE THE EXERCISE BIKE HOW TO ADJUST THE SEAT POST HOW TO ADJUST THE PEDALING RESISTANCE For effective exercise, the seat should be at the proper To increase the height. As you pedal, there should be a slight bend in resistance of the your knees when the pedals are in the lowest position.
Page 11
FEATURES OF THE CONSOLE Scan—This mode shows the time, speed, distance, calories, odometer, and pulse displays, for a few The easy-to-use console features seven displays that seconds each, in a repeating cycle. Note: The pulse provide instant exercise feedback during your work- display will appear only while you are using the heart outs.
Page 12
HOW TO USE THE CONSOLE 4. Measure your heart rate, if desired. Make sure that there are batteries (not included) in the If there are Contacts console (see assembly step 5 on page 7). If there sheets of plastic is a sheet of plastic on the console, remove the plastic. on the metal contacts of the 1.
MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the exercise bike regu- Next, turn the resistance knob to the lowest setting. larly. Replace any worn parts immediately. Locate the Reed Switch (26). Turn the Crank (35) until the Magnet (36) is aligned with the Reed Switch. To clean the exercise bike, use a damp cloth and a Loosen, but do not remove, the M4 x 20mm Screw (56).
Page 14
HOW TO ADJUST THE DRIVE BELT If you can feel the pedals slip while you are pedaling, even when the resistance is set at the highest level, the drive belt may need to be adjusted. To adjust the drive belt, the pedals and the shields must be removed. Use an adjustable wrench to remove the pedals.
FCC INFORMATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
Page 17
SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch; never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) LIMITED WARRANTY IMPORTANT: You must register this product within 30 days of the purchase date to avoid added fees for service needed under warranty.
