Model No. WLEX19821
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, we will guarantee
complete satisfaction through
direct assistance from our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE. The
technicians on our customer hot
line will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.weslo.com
new products, prizes,
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit 510 Cs Bike and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weslo Pursuit 510 Cs Bike

Summary of Contents for Weslo Pursuit 510 Cs Bike

  • Page 1 CUSTOMER HOT LINE: 1-800-999-3756 Mon.–Fri., 6 a.m.–6 p.m. MST CAUTION Visit our website at Read all precautions and instruc- tions in this manual before using www.weslo.com this equipment. Keep this manual new products, prizes, for future reference. fitness tips, and much more!

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .

  • Page 3: Before You Begin

    BEFORE YOU BEGIN Congratulations for selecting the new WESLO ® Service Department toll-free at 1-800-999-3756, PURSUIT 510 CS exercise cycle. Cycling is one of Monday through Friday, 6 a.m. until 6 p.m. Mountain the most effective exercises for increasing cardiovas- Time (excluding holidays).

  • Page 4: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the exercise cycle in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included tools, assembly requires a Phillips screwdriver , two adjustable wrenches , and pliers...
  • Page 5 1. While another person lifts the front of the Frame (1) slightly, attach a Stabilizer (2) with two M10 x 65mm Carriage Bolts (30) and two M10 Nylon Locknuts (33). 2. Attach a Stabilizer (2) to the Seat Frame (5) with two M10 x 65mm Carriage Bolts (30) and two M10 Nylon Locknuts (33).
  • Page 6 5. Attach a Seat Handle (50) to the round tube on the Left Seat Bracket (52) with two M6 x 32mm Bolts (62) and two M6 Nylon Locknuts (63). Attach the other Seat Handle (50) to the Right Seat Frame (53) in the same way. 6.
  • Page 7 8. The Console (16) requires three AA batteries (not included); alkaline batteries are recommended. Insert Batteries three batteries into the Console as shown. Make sure that the batteries are oriented as shown by the markings inside the Console. Hold the Console (16) near the Handlebar (15). Insert Hole the console wire down through the indicated hole in the Handlebar.

  • Page 8: How To Operate The Exercise Cycle

    11. Identify the Left Pedal (24), which is marked with an “L.” Using an adjustable wrench, firmly tighten the Left Pedal counterclockwise into the left arm of the Crank (21). Tighten the Right Pedal (not shown) clock- wise into the right arm of the Crank. Important: Tighten both Pedals as firmly as possible.
  • Page 9 FEATURES OF THE CONSOLE 2. Select one of the modes: The easy-to-use console features five modes that pro- Scan mode— vide instant exercise feedback during your workouts. Mode Indicators When the power The modes are described below. is turned on, the scan mode will be selected automati- cally.

  • Page 10: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and properly tighten all parts of the exercise With the left side shield removed, locate the Reed cycle regularly. Replace any worn parts immediately. Switch (43). Turn the Crank (21) until the Magnet (38) is aligned with the Reed Switch. Loosen, but do not To clean the exercise cycle, use a damp cloth and a remove, the M4 x 16mm Screw (49).

  • Page 11: Conditioning Guidelines

    CONDITIONING GUIDELINES The following guidelines will help you to plan your ber in your training zone as you exercise. For maxi- exercise program. Remember that proper nutrition mum fat burning, adjust the intensity of your exercise and adequate rest are essential for successful results. until your heart rate is near the middle number in your training zone as you exercise.
  • Page 12 EXERCISE FREQUENCY workouts. After a few months of regular exercise, you may complete up to five workouts each week, if To maintain or improve your condition, plan three work- desired. Remember, the key to success is make exer- outs each week, with at least one day of rest between cise a regular and enjoyable part of your everyday life.
  • Page 13 NOTES...

  • Page 14: Part List

    EXPLODED DRAWING—Model No. WLEX19821 R0903A Key No. Qty. Description Key No. Qty. Description Frame C-Magnet Bracket Stabilizer Flywheel M8 x 21mm Bolt Magnet Stabilizer Endcap Flywheel Axle Seat Frame 6200Z Bearing M4 x 16mm Flat Head Screw M4 x 25mm Screw Handlebar Endcap M8 Split Washer Foam Grip...

  • Page 15: Exploded Drawing

    EXPLODED DRAWING—Model No. WLEX19821 R0903A...

  • Page 16: Ordering Replacement Parts

    • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on page 14) WESLO is a registered trademark of ICON Health & Fitness, Inc. LIMITED WARRANTY ICON Health &...
