Pro-Form Performance 1450 User Manual page 9

5. Identify the Left Base Cover (81) and the Right
Base Cover (89). Slide the Left Base Cover onto
the Left Upright (79). Slide the Right Base Cover
onto the Right Upright (88). Do not press the
Base Covers into place yet.
Identify the Left Bottom Handrail Cover (84) and
the Right Bottom Handrail Cover (87). Slide the
Left Bottom Handrail Cover onto the Left Upright
(79). Slide the Right Bottom Handrail Cover onto
the Right Upright (88).
6. Attach the Left Handrail (83) to the Left
Upright (79) with two 5/16" x 2 1/2" Screws (10)
and two 5/16" Star Washers (11). Make sure
that the Upright Wire (78) is resting to the
side as shown and is not pinched. Firmly
tighten the screws.
Attach the Right Handrail (86) to the Right
Upright (88) with two 5/16" x 2 1/2" Screws (10)
and two 5/16" Star Washers (11); firmly tighten
the screws.
Remove the wire tie from the Upright Wire (78).
5
79
84
81
6
10
11
83
79
9
88
87
89
10
78
11
Wire
Tie
86
88
