Summary of Contents for ZALMAN CNPS14X
- Page 1 User's Manual CNPS14X Intel Socket 2011 V3 / 2011 / 1366 / 1156 / 1155 / 1150 / 775 CPUs AMD Socket FM2 / FM1 / AM3+ / AM3 / AM2+ / AM2 CPU&APUs To ensure safe and easy installation, please read the following precautions.
-
Page 2: Specifications
6) Check the components list and condition of the product before installation. If any problem is found, contact the retailer to obtain a replacement. 7) Zalman Tech Co., Ltd. is not responsible for any damaged due to overclocking. 8) During transportation of the system, the cooler must be removed. - Page 3 3. Components Manual Cooler Backplate Manual Nuts Clip A Clip B (Optional Fan) Silver Bolts A(4mm) Silver Bolts B(3mm) Side Caps (Socket 2011 V3 / 2011) (Socket 1366/115X/775/AMD) Thermal Grease Loading Block Spanner Double-sided Tape (ZM-STG2M) WWW.ZALMAN.COM...
-
Page 4: Installation Requirements
Install the cooler’s fan bracket close to the rear fan of the case, so that the air passing through the cooler comes out through the rear fan of the case,as shown in the image. Case Exhaust Rear Fan MotherBoard Fan Bracket WWW.ZALMAN.COM... -
Page 5: Installation
Please note that the connection Intel Socket AMD Socket directions of the clip A are different Installation Installation according to sockets. Caution Make sure that the holes of the clip A are attached to the raised parts of the base cover. Align WWW.ZALMAN.COM... - Page 6 AMD Socket Intel Socket 775 Intel Socket 1156/1155/1150 Intel Socket 1366 Caution Caution [Intel Socket] [AMD Socket] Please note the insertion directions of Please note the insertion directions of the nut and side cap the nut and side cap WWW.ZALMAN.COM...
- Page 7 Tier of the Loading Block and attach it to Double-sided Tape’s Cover. the Backplate. Double-sided Tape Loading Block ② Attach Double-sided Tape to the Loading Block and remove the Double-sided Tape Cover. Double-sided Tape Caution Please make a note of the orientation of the Loading Block. WWW.ZALMAN.COM...
- Page 8 ① Take away the fixed Clip support from motherboard’s clip support holes, attach it the motherboard. to the back side of the motherboard. ② Align the Backplate with motherboard’s clip support holes, attach it to the back side of the motherboard WWW.ZALMAN.COM...
-
Page 9: Cooler Installation
When connecting, be careful not to use the wrong size bolt. The silver bolt A and B are very Silver Bolt A(4mm) Silver Bolt B(3mm) similar in appearance, thus (Socket 1366/115X/ (Socket 2011 V3 / 2011) causing confusion. 775/AMD) WWW.ZALMAN.COM... - Page 10 (You can install a maximum of two 140 mm fans.) Clip B Option Fan(ZM-F4) [One Optional Fan] [ Two Optional Fan] WWW.ZALMAN.COM...
