User Manual of Cost-effective Network Camera
Version 1.0
Thank you for purchasing our product. If there is any question or request, please do
not feel hesitated to contact us.
This manual may contain several technical incorrect places or printing errors,
and the content is subject to change without notice. The updates will be added to the
new version of this manual. We will readily improve or update the products or
procedures described in the manual.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-2CD726F-PT series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION DS-2CD726F-PT series

Summary of Contents for HIKVISION DS-2CD726F-PT series

  • Page 1 User Manual of Cost-effective Network Camera Version 1.0 Thank you for purchasing our product. If there is any question or request, please do not feel hesitated to contact us. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.

  • Page 2: Safety Instruction

    7. If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 3 The average time varies because of differences between operating environment and using history, so regular checking is recommended for all the users. Please contact with your dealer for more details. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 4: Table Of Contents

    4.2.3 Patrol Scan ..................................30 4.2.4 Defense ..................................30 4.2.5 Privacy Protect ................................30 4.2.6 Alarm setting .................................31 4.2.7 Clear....................................31 4.28 Password ..................................31 APPENDIX 1 PIN DEFINITION ............................32 APPENDIX 2 PORT MAP ..............................33 APPENDIX 3 TECHNOLOGY SPECIFICATION ......................34 ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 5: Chapter 1 Introduction

    Chapter 1 Introduction Product Introduction DS-2CD726F-PT, DS-2CD727PF-PT series cameras are a kind of cost-effective network camera, which is widely applied in the minitype lieu, such as house and small and medium enterprises indoor surveillance. The features are as following:  Adopted High Performance TI DSP chip;...
  • Page 6 Hikvision Technical Manual Figure 1-2-1 Forward Looking Appearance Figure1-2-2 Rearview Interface Appearance ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 7 Remote Control. Once the direction button is pressed, the camera will gyrate towards the orientation you select. It will not stop until you press the “Menu” button. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 8: State Indicate Lamp Introduction

    × Red Flicker(2 /s) √ √ √ Orange Flicker(2/s) 1.3 Application Figure 1-3-1 Topological Graph of System 1.4 Default IP, User Name and Password Default IP: 192.0.0.64 User Name: Admin Password: 12345 ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 9: Chapter 2 Installation

    2.2 Installation Step Both DS-2CD726F-PT and DS-2CD727PF-PT adopt the following installation method, the example is DS-2CD727PF-PT. Step 1: Take out the metal fixed plate, and install it on the wall or ceiling with the bolt.
  • Page 10 You can press the small metal sheet popped out on the bottom of metal fixed plate, and make it leave the small socket. Hold down the pedestal and slowly push it forward to remove the camera. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 11: Alarm Output Connection

    Pressed-Line Terminal and Plug the line into the connection hole, then release the Pressed-Line Terminal. [Notice] Gently draw the line to make sure the line is firmly connected, which avoid the open circuit and out of control. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 12: Chapter 3 Parameter Configuration

    Type 1: Point to Point Connection Mode In the mode, IP camera directly links to the wireless network laptop. It’s shown as following figure: [Notice] The above-mentioned function is reserved at present. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 13: Cable Network

    In this mode, the IP camera accesses the LAN trough the switch or the hub. As the following figure show: Type 2: Trough the Router access WAN User can visit the IP camera on the Internet. Broad band router requests IP Masquerade., i.e., visual sever. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 14: Set Parameters Through Ie

    “preview” page. Double click the “Camera 01” channel or “Preview” button to view the menu as Figure 3-2-3. Right click the “Camera 01” channel, and the “Main Stream”, “Sub Stream” and “Open sound” ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 15 IP address, etc. for your demand as Fig. 3-2-4. Enter the menu by invoking the 95 pre-set. Select the function you want by clicking the direction key. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 16: Parameter Configuration Through Client Software

    “Program”→ “client software 4.01”, a message box of “Register Administrator” as Fig. 3-3-1 will appear by then for the first time running. Both the user name and password should be no less than 6 digits for ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 17 Fig.3-3-1 Register Administrator Enter the registered user name and password as Fig. 3-3-2. Click “Login” to enter the “Preview” menu as Fig. 3-3-2. Fig. 3-3-2 User Login ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 18 Click the “Configure” button in Fig. 3-3-4, and then right click the blank spaces in the middle. Click the “Create Root Node” button as Fig. 3-3-4, and the “Area Properties” message will pop up as fig 3-3-5. Fig. 3-3-4Create Root Node ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 19 Input the area name (you can create whatever name you like) and click “OK” as Fig. 3-3-5. Then right click the area name you have just created as Fig. 3-3-7. Fig. 3-3-6Area Name Adding Completed ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 20 Input your camera IP in “Server IP”, e.g. 192.0.0.64; “User Name”: admin, “Password”: 12345, and 8000 for the default “Port”, and then modify “Channel” to 1. Click the “OK” button as Fig. 3-3-8. Fig. 3-3-8Add Device Fig.3-3-9 Camera Adding Completed ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 21: Search And Amend Ip

    Run the software of SADP in the CD-ROM attached in the camera, and click the “enter” to enter the list which displays the online device’s information, such as IP address, port, subnet mask, device serial-number and so on. It’s shown as following: ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 22 Fig.3-4-1 Search IP Tool Input the Password (default password12345), and click “modify”, then you can modify the device’s IP address, port and subnet mask. The following fig. gives illustration: Fig.3-4-2 Modify Device Information ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 23: Ip Camera Access Wan

    [Notice] Please make sure that the ADSL Modem is powered on .The camera needs to be restarted to establish the network connection after the configuration of PPPoE parameters for the first time. And DS-2CD852F do not support this function. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 24: Wan Access

    “sever name” is consist with the sever name in “remote config”; and select “private DNS” in “register mode”; then input the IP address of DNS server in “DNS address”, click “Confirm”. Then you can preview the picture in the “preview” menu. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 25: Wireless Ip Camera Access

    User can select “Enable Security Function” according to the on-the-spot environment. You can select the “Security Type”, “Security Option”, “Key Mode Option” and “Key Content”. Please refer to the introduction of the wireless router to get the detailed configuration. As shown: ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 26 User should configure the parameters of the wireless network card through the cable network interface. The way of visiting is the same as the chapter 3.2. Enter the menu as “Fig. 3-2-2 preview page” shows, then click the “Config” option, enter the interface as following: ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 27 Net configuration in the picture is the wireless NIC IP address, please set it and pay attention that wireless IP address and IP camera wired IP address should be in different segment. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 28: Chapter 4 Menu Introduction

    “IRIS+”, User will enable the function. IF the current menu has submenu, you will enter the submenu through the above mentioned operation. You can also enable the function and enter the submenu using “IRIS+” in the client software or IE browser. Fig.4-4-1 shows all menu item. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 29: Main Menu Function Introduction

    [Notice] This function can be realized only through the remote control. If you select the video upload or the alarm upload “on”, even if enable the “Privacy Protect”, you can also see the popped out video when the camera receives the alarm signal. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 30: Alarm Setting

    “Alarm Action” has the “Auto Scan”, “Frame Scan”, “Random Scan” , “Patrol path” and so on optional item. 4.2.7 Clear Clear the information of preset, patrol scan and other settings. 4.28 Password [Notice] The function is reserved currently. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 31: Appendix 1 Pin Definition

    Hikvision Technical Manual APPENDIX 1 PIN DEFINITION (1)UTP between the network port of camera and HUB (Direct Cable) (2)UTP between the network port of camera and PC (Cross Cable): ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 32: Appendix 2 Port Map

    80 and 8000, and its IP address is 192.168.1.23. The other camera’s ports are 81 and 8001, and IP is 192.168.1.24. Afterwards, enable all or TCP protocols. Enable the port map after pressing the ‘Save’. ©2006 – 2010 by HIKVISION. All rights reserved.

  • Page 33: Appendix 3 Technology Specification

    1/4 inch SONY Super HAD CCD Effective Pixel 640(H)×480(V) Lens mount M12×0.5 Lens 3.6mm Min. Illumination 0.4Lux/F1.2 0.4Lux@F1.2(0 LUX with IR) Infrared Function Support Video Output Test Monitor OUT 1Vp-p Composite Output(75Ω/BNC) Compression standard Video Compression H.264 ©2006 – 2010 by HIKVISION. All rights reserved.
  • Page 34 Number of Preset Privacy Protection Only Display on the Monitor Menu Language Chinese and English, maximal 16 characters Mouse Control Support Mouse Drag while select HIKVISION protocol in Client Software Motion Detect Support Dual Stream Support SD Card Local Recording...

This manual is also suitable for:

Ds-2cd727pf-pt series
