Summary of Contents for Staco Energy UniStar C
-
Page 1: User Manual
UniStar C Intelligent True On-Line UPS User Manual 1K/2K/3K Form No. 003-2308 Rev C... -
Page 2: Table Of Contents
Table of Contents Important Safety Introduction ..............3 An Important Notice ................3 Storage Instruction ................4 Product Introduction ................4 General Characteristics ............... 4 Special Features ................. 5 UPS Functiuonal Descriptions ............. 6 UPS Front Panel Display Descriptions ..........6 3.1.1 LED Panel (Standard) ................ - Page 3 Trouble Shooting ................39 Error Codes and their Descriptions ........... 39 Maintenance..................39 Bundled Software Installation Guide ..........40 Hardware Installation ................ 40 Software Installation ................40 Dry Contact card SC-Relay (Optional) ..........41 The Pin assignments of 10-Pin Terminal .......... 41 SNMP Card ..................
-
Page 4: Important Safety Introduction
Important Safety Instruction An Important Notice Do not open the case, as there are no serviceable parts inside. Your Warranty will be void. Do not try to repair the unit yourself; contact your local supplier or your warranty will be void. If liquids are split onto the UPS or foreign objects dropped into the unit, the warranty will be null and void. -
Page 5: 1.2 Storage Instruction
1.2 Storage Instruction For extended storage in moderate climate, the batteries should be charged for 12 hours every 3 months interval by connecting the UPS to the utility supply and switch on input breaker located at UPS rear panel. Repeat this procedure every 2 months if the storage ambient temperature is above 30 C. -
Page 6: Special Features
Special Features 1. High Frequency Transformer-less technology with rack/tower convertible enclosure allows the UPS to be installed in the most difficult of environments with space constraints. 2. This UPS is equipped with digital control logic for greater functionality and enhanced high level power protection. Digital signal processing (DSP) also provides the UPS with powerful communication capability, which enhances the flexibility for easy remote control and monitoring 3. -
Page 7: Ups Functiuonal Descriptions
UPS Functional Descriptions UPS Front Panel Display Descriptions 3.1.1 LCD panel LCD Display Green LED steadily lights up to indicate that the Utility input voltage is within the window (80Vac~144Vac, or 160Vac~288Vac); the LED flashes flickeringly to indicate that the Utility input voltage is within the acceptable window (60Vac~79Vac, or 120Vac~159Vac). -
Page 8: Symbols On The Lcd Display Panel
Special functions log in/out Go to next page Go to previous page or change the setting of the UPS. To confirm the change of UPS Setting ON-KEY ” and " ◎ Manual Bypass：Press" Up-KEY" key simultaneously for approx. 3 seconds to transfer from "Inverter to Bypass" (the bypass led continuously “blinks“... -
Page 9: Rear Panel Descriptions
Rear Panel Descriptions 120V 1KVA 2KVA 3KVA... - Page 10 230V 1KVA 2KVA 3KVA 1. USB Port 2. RS232 Port 3. Emergency Power Off (EPO) Dry Contact Signal inputs 4. Communication Card Options Slot 5. External Battery Connector 6. AC power connection socket 7. AC Outlets 8. Two programmable outlets 9.
-
Page 11: Operating Modes & Voltage System Configurations
Operating Modes & Voltage System Configurations Download and open the “UPS Setting Tool” Software to see the screen as below 3.3.1 System Configuration Settings 1. System Voltage Selection：Select Input Voltage 110V or 220V 2. Voltage Configurations：Select UPS Output Voltage 200V/208V/220V/230V/240V or 100V/110V/115V/120V/127V 3. - Page 12 5. Bypass Voltage Windows：Sensitivity: Select Sensitivity Low/Sensitivity High** Sensitivity Low Sensitivity High 120V System 90V～130V 97V～130V 230V System 180V～260V 194V～260V 6. Syn-Frequency Window：Select 3Hz/1Hz Inverter Freq synchronizing range 7. Com Port：Select the Com Port of PC 8. Click on “Write” to confirm the configuration settings. The UPS will beep twice to acknowledge setting is successful.
-
Page 13: Software Programmable Outlet Setting
3.3.2 Software programmable outlet setting The UPS is equipped with 2 programmable outlets for use to supply to less critical loads. These outlets can be disabled to shed the less critical loads during back-up modes or overload conditions to maintain quality power supply to the more critical loads connected to the UPS. - Page 14 1. Outlet Turn On After UPS On– select the time to automatically enable this outlet within the specified time when the UPS is powered on. If “0” sec is selected, the outlet will be enabled once the UPS is powered on. 2.
-
Page 15: Communication Port Explanation
Communication Port Explanation The UPS is equipped with EPO dry contacts input, true RS232 & USB Communication port as standard to provide communication with bundled UPS monitoring software for remote monitoring of UPS status via PC. There are 4 other optional interface cards available to meet various communication needs, i.e. -
Page 16: Usb Port Descriptions
The Pin Assignments of the true RS232 port are illustrated as follows： Pin 3: RS232 Rx Pin 2: RS232 Tx Pin 5: Ground 3.4.2 USB Port Descriptions The USB communication protocol definition as below: Complies with USB version 1.0, 1.5Mbps Complies with USB HID Version 1.0. -
Page 17: Installation And Operation
Installation and Operation Read the Safety Instruction guide (page 2 to 3) before installing the UPS Unpacking Inspect the UPS upon receipt. Staco has designed robust packaging for your product. However, accidents and damage may occur during shipment. Notify the forwarder and dealer if there is damage. The packaging is recyclable;... -
Page 18: Selecting Installation Position
Selecting Installation Position The UPS is heavy. Select a location sturdy enough to handle the UPS weight. To ensure proper operation and long operating life, always position the UPS according to the following requirement： 1. Keep minimum 20cm (8 inches) distance clearance from the rear panel of the UPS to avoid any obstructions. -
Page 19: Set Up
Set up Tower Configuration Setup Step 1 Power Module + Battery Module Step 1... - Page 20 Rack-Mount Configuration Setup Step 1 Step 2 Step 3...
- Page 21 Step 4 Step 5...
-
Page 22: Operation
Operation 4.4.1 Start Up In Normal Mode (1) Make sure the voltage of Utility matches with the input voltage window of the UPS. (2) Connect the UPS to the wall Receptacle of the Utility. After a short delay the UPS will automatically start. LED light up to indicate the Utility and the Bypass are normal. - Page 23 (3) The UPS is on Bypass Mode now and will proceed to self-test automatically. If there is no abnormal message then the pre-start-up of the UPS was successful and the charger begins to charge the batteries. ‟for approx. 3 seconds, until the unit (4) Press the UPS On Switch„...
-
Page 24: Start-Up In Battery Mode (Cold Start)
(6) The start-up sequence of the UPS is complete as illustrated as drawing E. Make sure the UPS is plugged onto the wall receptacle for at least 8 hours to ensure the batteries are fully charged. To turn off the UPS press and hold the Off switch until the alarm beeps twice, then release the switch. -
Page 25: Check Measured Values & Figures Detected By Ups
4.4.1.2 Check Measured Values & Figures detected by UPS (1) If you would like to check the measured values & messages, please use scroll up and scroll down key pads. When you use the scroll down key pad, the LCD display will change in sequence from Drawing E(Input Voltage) ... -
Page 26: Ups Default Data And Special Function Execution
4.4.1.3 UPS Default Data and Special Function Execution (1) After UPS is turned on successfully, use key pad to change the LCD Display screen to drawing P1. (2) Press key pad to scroll down the LCD screen, then check the UPS settings. -
Page 29: Ups Default Settings And Their Alternatives
(3) Press scroll up key pad, you may execute special functions. The functions include Buzzer ON (as drawing P1) or buzzer OFF (as drawing P2, Alarm silence for UPS warning) and self-test ON (as Drawing Q1) or OFF (as Drawing Q2. UPS will execute battery test for 10 seconds), if the self-test is successful, it show as Drawing W;... -
Page 30: Ups Is Off Due To Unknown Reason And Trouble Shooting
(10) Turn off the UPS and disconnect from the Utility. (11) Your Setting changes are complete. 4.4.1.5 UPS Is Off Due to Unknown Reason and Trouble Shooting (1) If there is a serious abnormal condition occurred, the UPS will lock itself as shown in the drawing Y and a abnormal message will show in the LCD screen. -
Page 31: Shut Off
4.4.1.6 Shut Off (1) Press key pad for about 5 seconds, the Inverter output will be turned off, the output load is supplied by Bypass loop and the LCD screen displays as drawing B. (2) Disconnect the UPS from the utility. (3) The UPS is turned off completely. -
Page 32: 4.4.3 Battery Replacement
4.4.3 Battery Replacement Step 1 Step 2... - Page 33 Step 3 Step 4 1KVA 2K/3KVA...
-
Page 34: Ups Working Principle
UPS Working Principle 5.1. UPS System Block Diagram (fig 5.1) Figure 5.1 above illustrates the True On-Line Double Conversion architecture of the UPS system. The major modules consist of： 1) An AC to DC power converter (Rectifier) with PFC control circuit 2) A DC to AC power high frequency inverter 3) An Intelligent Battery Charger 4) A bank of stationary maintenance-free batteries... -
Page 35: When Utility Is Normal
LEDs Display Utility Conditions UPS Operating Modes indications Rectifier convert AC to DC, battery charging, Inverter convert DC to AC LEDs Utility Normal and supply to loads with clean & stable remain illuminated power. Rectifier and charger stop operating， Battery discharge via DC~DC boost Utility Abnormal LED off, circuit and supply to Inverter. -
Page 36: When Utility Is Abnormal/Absent
When Utility is Abnormal/Absent The working principle of the UPS under Utility abnormal condition is illustrated as follows： Fig 5.3 1. When Utility is abnormal, the UPS will direct the battery energy automatically to the Inverter without delay, and turn off the charger and AC/DC converter. The inverter converts the DC to AC to supply energy to the output connected load without interruption. -
Page 37: Overload Condition
Overload Condition The working principle of the UPS when overloading is illustrated as follows： (1) Generally, modern electronics & IT equipment generate an inrush current when switching on. The amount of inrush current varies from equipment to equipment, some can be as high as 6 times its rated capacity while others produce negligible inrush. -
Page 38: Inverter Failure
2. The UPS Bypass loop is also equipped with overload protection. Its overload capacity is illustrated by the graph & table below. Inverter Failure Output Load short circuit when being supplied from inverter If the output load is shorted while being supplied by the Inverter, the UPS will shutdown the Inverter automatically. -
Page 39: Inverter/Internal Over Temperature
Inverter/Internal Over temperature If the UPS experiences internal over-temperature while the Utility is normal, it will switch to bypass loop. The UPS will switch back to inverter mode when the over- temperature situation is eliminated. If over temperature occurs when Utility is abnormal, it will beep continuously and the Fault LED will light up. -
Page 40: Maintenance Guide
Maintenance Guide Trouble Shooting When the UPS becomes faulty or malfunctions during operation, you may check the fault lists below for possible solutions. Should the problem persist, please contact Staco for assistance. Error Codes and Their Descriptions Code Descriptions Er05 Battery weak or faulty Er06 Output short-circuited... -
Page 41: Bundled Software Installation Guide
Bundled Software Installation Guide Hardware Installation 1. Connect the male connector of RS232/USB* cable to the UPS communication port. 2. Connect the female connector of the RS232/USB* cable to a dedicated RS232 port of the Computer. 3. For optional interface cards, please refer to Chapter 8 for more details. *Note: Only RS232 cable is provided with the UPS. -
Page 42: Dry Contact Card Sc-Relay (Optional)
Dry Contact card SC-Relay (Optional) The pin assignments of 10-Pin Terminal： 1 UPS on Bypass mode (Bypass) 2 Utility Normal (Normal close contact) 3 Utility Normal (Normal open contact) 4 Inverter On 5 Battery Low 6 ... -
Page 43: Snmp Card
SNMP Card 8.2.1 SNMP/WEB card SC-SNMPI (Optional) For installation, please refer to the user‟s manual attached with the card. Installation Position：Option slot... -
Page 44: Specifications
Specifications Model 1KVA 2KVA 3KVA VA Rating Apparent Output Power 1000VA 2000VA 3000VA Active Output Power 700Watts 1400Watts 2100Watts Power Factor Topology Double conversion On-Line Type Rack/Tower 120V Models: UL, cUL, FCC Agency Approvals 230V Models: CE Input 120V 60/70/80 - 144Vac Voltage Window 230V 120/140/160 - 288Vac... -
Page 45: Battery System
Current Crest Factor ≦3% THD(Linear Load) Harmonic Distortion ≦7% THD(Non-Linear Load) Transient ＜＝60ms/5% Response(ms) Waveform Pure Sine wave To AC Mode (Full load) Efficiency To Battery Mode (Full load) Battery System Type 12V/7.2Ah 12V/7.2Ah 12V/9Ah Numbers of Batteries Backup Time(Full Load) >7min. - Page 46 (Battery Mode) ＜105％ continuous ＞106％～120％ for 30 seconds shuts down ＞121％～150％ for 10 seconds shuts down ＞150％ for immediately shuts down * Notification: continuous alarm. (Bypass Mode) ＜105％ continuous ＞106％～120％ for 250 seconds shuts down ＞121％～130％ for 125 seconds shuts down ＞131％～135％...
-
Page 47: Standards And Certification
＜50dBA Noise Level Relative Humidity 0 to 90% (Without condensation) Interface Interface Type -Standard 1 *USB port+ 1*RS-232 port SNMP (Optional) Power management from SNMP manager and Web browser Compatible platforms Windows 95/98/NT/2000/XP/Vista Novell NetWare, Linux, etc. Standards and Certification Safety IEC/EN 62040-1-1,IEC 60950-1 Performance...
