Staco Energy SC60021RM User Manual

Unistar iii series p 6kva rack/universal mount
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
UniStar III Series P
6kVA Rack/Universal Mount
SC60021RM
SC60022RM
Parallel Redundancy/Capacity
On-Line UPS
User's Manual
8/1/07
Models:

Table of Contents

1
........................................................................................ 2
.......................................................................................... 4
2
....................................................................................... 5
............................................................................................ 8
3
......................................................................................................... 11
4
............................................................................................ 30
5
................................................................................... 32
..................................................................................... 32
6
........................................................................................ 33
............................................................................................... 34
.................................................................................................... 35
7
8
................................................................................................... 39
........................................................................ 2
................................................................................ 5
........................................................ 6
.......................................................... 10
.......................................................................... 11
.................................................................. 12
.................................................................... 13
...................................................................... 18
........................................ 19
................................................................................ 30
.................................................... 32
.............................................................................. 33
.............................................................................. 33
............................................................................... 34
........................................... 35
.................................................. 37
1
.... 33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SC60021RM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Staco Energy SC60021RM

Summary of Contents for Staco Energy SC60021RM

  • Page 1: Table Of Contents

    Bundled Software Installation Guide ............ 32 5.1. Hardware Installation Models: ................... 32 5.2. Software Installation ..................32 SC60021RM Customer Options Slots ................33 SC60022RM 6.1. All the below interface cards are with built-in EPO function..33 6.2. R2E(2nd RS-232 ) card ................

  • Page 2: Important Safety Instruction

    1.1.17 This U PS sup ports electr onic eq uipment in offices, telecommunications, p rocess co ntrol, 1 Important Safety Instruction medical and security applications. Non-authorized technician is not allowed to install the UPS in the following areas. 1.1. An Important Notice a.

  • Page 3: Storage Instruction

    2 Product Introduction 1.2. Storage Instruction 2.1. General Characteristics For extended storage t hrough mo derate climate, t he b atteries should b e 2.1.1 True online architecture c ontinuously supplies in y our critical device with a stable, regulated, charged fo r 12 ho urs eve ry 3 mon ths by p lugging th e U PS po wer c ord in to the transient-free pure sine wave AC Power.

  • Page 4: Symbols On The Lcd Display Panel

    2.2. Symbols on the LCD Display Panel Next Page Item Symbol Description Special Function Log in /out Utility or Bypass Source 2.2.1.1.1 LINE Enter or Reconfirmed Battery Low Utility Input Normal LED Battery Abnormal 2.2.1.2 Bypass Input Normal LED UPS Overloading UPS under Redundancy Mode UPS Working in specified mode* UPS under ECO Mode...

  • Page 5: Panel Explanation

    2.3. Panel explanation 2.3.2 Rear Panel Explanation 2.3.1 Front Panel Function Explanations A Te rminal Resistor for Parallel function B RS 232 Port C External Battery Connector D Utility Input Breaker E CAN Bus Connection Port for Parallel System LCD Display F Maintenance Bypass Switch and Galvanic Tx.

  • Page 6: Communication Port Explanation

    2.4. Communication Port Explanation 3 Installation and Operation The Communication port on the UPS provides true RS232 type to communicate The packing condition and the external outlook of the unit should be inspected with UPS software to remote monitoring the power and UPS status. carefully before installation.

  • Page 7: Selecting Installation Position

    3.3. Installation of Casters Cover 3.3.1 3.2. Selecting Installation Position Tower installation step It is necessary to select a proper environment to install the unit, in order to 3.3.1.1 Power Module + Battery Module minimize the possibility of damage to the UPS and extend the life of the UPS. Step 1 Installation Foot Cover and Power Module Please follow the advice below: 1.
  • Page 8 3.3.1.2 Power Module+ Isolation Transformer Module+ Battery Module Step 2 Installation Ear Cover to Power, Isolation Transformer and Battery Step 1 Installation Power, Isolation Transformer and Battery 3.3.2 Rack installation step 3.3.2.1 Power Module+ Battery Module Step 1 Installation Ear Cover Step 3 Installation Rail to Rack B1 B2 S4 B1 B3 S4...
  • Page 9 Step 4 Installation Battery Module to Step 2 Installation Power Module to Rack 3.3.2.2 Power Module+ Isolation Transformer Module+ Battery Module Step 1 Installation Isolation Transformer Module to Rail...

  • Page 10: Terminal Block Explanation

    3.4. Terminal Block Explanation 3.5. Operation Test and Installation Instruction 3.5.1 Start Up in Normal Mode 3.5.1.1 Open the terminal block cover on the rear panel (refer to 2.3.2) Before start the installation, please ma ke sure t he g rounding is connected properly.
  • Page 11 3.5.1.9 Your start-up operation of th e UPS is completely now. Make sure the 3.5.1.7 Then, the UP S is under sel f-test mode agai n, the LCD display will UPS is p lugged o nto th e w all r eceptacle for c harging a t lea st 8 hours illustrate f rom dr awing C t o d rawing D an d r emain ap prox.
  • Page 12 3.5.3 Check Measured Values & Figures detected by UPS 3.5.3.1 If y ou wou ld l ike t o ch eck t he me asured v alues & figures detected by the UPS , please u se scrol l up an d scroll down ke y pads.
  • Page 13 3.5.4 UPS Default Data and Special Function Execution 3.5.4.1 After UPS c ompletely starts up, press key pad to change the LCD display screen to drawing Q1. * It shows self-test is “On”. * It shows buzzer “On”. * It shows Bypass Voltage is adjusted to narrow one. * It shows bypass voltage is adjusted to wider one.
  • Page 14 * It shows the UPS is operated in “normal mode”. * It shows UPS Identification Number. * It shows the UPS is operated in “Eco mode”. * It shows the UPS is in the No. 1 of parallel systems. 3.5.4.3 Press scro ll up key pa d, you ma y exe cute s pecial functions.
  • Page 15 3.5.5.12 Turn Off the breaker of Utility Input. 3.5.5.13 Your Setting changes are complete. 3.5.5.3 Except Buzzer (a s dr awing Q 1 & Q2) a nd Se lf-test(as drawings R1 & R2), all the rest default settings may be changed by pr essing scroll up 3.5.6 UPS Is Off Due to Unknown Reason and Its Trouble Shooting ke y pad.

  • Page 16: Troubleshooting Guide

    Situation Check Items Solution 4 Troubleshooting Guide UPS Red Fault LED Check the error code 1. Check to see if the battery lights up shown on the LCD connection is properly done, 4.1. Trouble Shooting screen then re-charge the batteries for 8 hours to see whether the When the UPS malfunctions during operation, you may check the 1.Er05,...

  • Page 17: Bundled Software Installation Guide

    5 Bundled Software Installation Guide 6 Customer Options Slots 5.1. Hardware Installation 1. Connect the male connector of RS232 cable to the UPS communication 6.1. All the below interface cards are with built-in EPO function. port. The pin assignments of the EPO are: 2.

  • Page 18: Use(Usb) Card

    6.6. SNMP Cards 6.4. USE (USB) card 6.6.1 6.4.1 SNMP/WEB card CN1 for USB and CN3 for EPO. For installation, please refer 6.4.2 For co mmunication p rotocol, p lease see th to the user’s manual definition below: Comply with USB version 1.0,1.5Mbps attached with the card.

  • Page 19: Hot Swappable Battery Replacement

    Hot Swappable Battery Replacement 1. Unscrew the flank of the battery bank front panel as indicated in Step 1. 2. Remove the front panel as indicated in Step 2. 3. Remove the screw of the battery pack as shown in Step 3. 4.

  • Page 20: Specifications

    8 Specifications *Model – UPS Module 1 SC60021RM SC60022RM INPUT Voltage Range 160 -280Vac Frequency 45 ~ 65 Hz Phase/Wire Single, Line + Neutral + Ground Power Factor Up to 0.99 at 100% Linear Load Current THD <5% at 100% Linear Load...
  • Page 21 3.5” x 12.8” x 2.8” (2U) nonconforming may be returned to Staco for repair or replacement, at Staco’s discretion, without charge for material or labor. All returns must be shipped freight prepaid to Staco Energy products Co. Weight (l bs.) Staco will pay freight charges from factory to customer domestic (US and Canada) location.
  • Page 22 International: Staco Energy Products Co. (Staco), Dayton, Ohio, warrants this equipment, with all applicable terms and conditions stated above, to be free of defects in material and workmanship for a period of one year from the installation date, no more than eighteen (18) months from shipment date from a Staco warehouse.

This manual is also suitable for:

Sc60022rm
