JVC TK-C553U Specification

Fixed color dome camera

Hide thumbs Also See for TK-C553U:

Download this manual See also: Service Manual, Instruction Manual

CCTV Camera

Variable Focal-Length Lens (f=2.6 to

6 mm)

1/4-inch 380,000 Pixel CCD

High Sensitivity — 4 Lux (with

cover), 1.5 Lux (without cover)

Digital 2X Zoom — Auto Pan, Tilt,

Scroll and Preset Sequence (Auto

Patrol) Mode

FIXED COLOR DOME CAMERA

TK-C553U

Cost-effective, Compact Programmable Color

Dome Camera with Digital Zoom

6 Preset Positions

One-push Auto White Balance

Programmable Backlight

Compensation

RS-422A and RS-485 Control Signals

Compact, Space-saving Design

(AC 24 V/DC 12 V)

Page 1 FIXED COLOR DOME CAMERA TK-C553U (AC 24 V/DC 12 V) Cost-effective, Compact Programmable Color Dome Camera with Digital Zoom CCTV Camera Variable Focal-Length Lens (f=2.6 to 6 Preset Positions 6 mm) One-push Auto White Balance 1/4-inch 380,000 Pixel CCD Programmable Backlight High Sensitivity —...
Page 2 With its fully programmable Auto Patrol function, JVC’s TK-C553U can pan and tilt to monitor up to six positions in a sequential or random pattern. A wide-aperture, wide-angle lens with zoom further boosts coverage. Images are captured by a JVC 1/4-inch CCD with 380,000 pixels, which delivers 470 TV lines for crisp pictures at light levels down to 1.5 Lux (without cover).
Page 3 The professional-quality large aperture lens screen and lets the user instantly know coverage of the area under surveillance — of the TK-C553U features a 2X digital zoom the location of the camera. horizontal: 90°, vertical: 130°, and Tilt: 30°. ratio and zoom can be smoothly and easily...
Page 4: Specifications
MASTER MONITOR Design and specifications subject to change without notice. DISTRIBUTED BY JVC PROFESSIONAL PRODUCTS COMPANY DIVISION OF JVC AMERICAS CORP. 1700 Valley Road, Wayne, N.J. 07470 TEL: (973) 315-5000, (800) 582-5825 FAX: (973) 315-5030 The Hachioji Plant of Victor Company of Japan, Ltd., has received ISO14001 Certification E-mail: proinfo@jvc.com...
