Summary of Contents for Tannoy Definition DC6i
- Page 1 USER MANUAL...
- Page 2 CONTENTS SAFETY INSTRUCTIONS PRODUCT IDENTIFICATION ACCESSORIES INSTALLATION GUIDELINES PRODUCT DIMENSIONS TECHNICAL SPECIFICATIONS FULL RANGE models SUBWOOFER models WARRANTY STATEMENT DECLARATION OF CONFORMITY...
- Page 3 A secondary support line should be attached from the safety loop on the rear of the product to a source point on the wall. Please consult the relevant construction codes in your region. 7. Tannoy will not be held accountable for any damage caused by incorrect installation.
- Page 4 IDENTIFICATION FULL RANGE MODELS SUBWOOFER MODELS Definition DC6i Definition sub 12i Definition DC8i Definition sub 15i Definition DC12i ACCESSORIES WALL BRACKET (only supplied with full range models)
- Page 5 GUIDELINES SURFACE MOUNTING THE LOUDSPEAKERS: 1. Lay the loudspeaker cable from the amplifier to the location where you intend to surface mount the loudspeaker. 2. Terminate the loudspeaker cable with 4mm connectors or spade connectors. Connect the loudspeaker to the approipriate amplifer channel.
- Page 6 DIMENSIONS DEFINITION DC6i 250.0 214.6 [9.84"] [8.45"] 334.0 [13.15"] DEFINITION DC8i 294.0 215.0 [8.46"] [11.57"] 394.0 [15.51"] DEFINITION DC12i 410.0 255.0 [16.14"] [10.04"] 550.0 [21.65"]...
- Page 7 DEFINITION SUB12i 370.0 355.0 [14.57"] [13.98"] 435.0 [17.13"] DEFINITION SUB15i 460.0 430.0 [18.11"] [16.93"] 525.0 [20.67"]...
-
Page 8: Specifications
SPECIFICATIONS FULL RANGE MODELS 85Hz - 35kHz 80Hz - 35kHz 67Hz - 25kHz 70Hz - 45kHz 62Hz - 45kHz 50Hz - 38kHz 90dB (1W = 2.83V for 8 ohms) 92dB (1W = 2.83V for 8 ohms) 97dB (1W = 2.83V for 8 ohms) 90 degrees conical 90 degrees conical 90 degrees conical... - Page 9 SPECIFICATIONS SUBWOOFER MODELS Subwoofer - Direct Radiating Subwoofer - Direct Radiating 48Hz 47Hz 38Hz 36Hz 94dB (1W = 2.83V for 8 ohms) 96dB (1W = 2.83V for 8 ohms) Average 400W 600W Programme 800W 1200W Peak (10ms) 1600W 2400W 400 - 800W @ 8 Ohms 600 - 1200W @ 8 Ohms Average 120dB...
- Page 10 If you suspect a problem with a Tannoy product then, in the first instance, discuss it with your Tannoy dealer. If you require further assistance then we ask that you deal directly with your local Tannoy distributor. If you cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given below.
- Page 11 DECLARATION The following apparatus is manufactured in the UK at Tannoy Ltd of Rosehall Industrial Estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the protection requirements of the European Electromagnetic Compatibility Standards and Directives relevant to Domestic Electrical Equipment. The apparatus is designed and constructed such that...
- Page 12 T: 00 1 (519) 745 1158 E: inquiries@tannoyna.com Tannoy Deutschland T: 00 49 (180) 1111 881 E: info@tannoy.com Tannoy France T: 00 33 (0)1 7036 7473 E: ventes@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
