Summary of Contents for Tannoy Definition
- Page 1 O W N E R ʼ S M A N U A L...
- Page 2 If you suspect a problem with a Tannoy product then, in the first instance, discuss it with your Tannoy dealer. If you require further assistance then we ask that you deal directly with your local Tannoy distributor. If you cannot locate your distributor please contact Customer Services, Tannoy Ltd at the address given below.
- Page 3 Thank you for selecting Tannoy loudspeakers developed in the UK by our dedicated team of design engineers. They are the choice of discriminating music lovers the world over. Musical excellence is designed into our loudspeakers from the start. Careful selection of the very best components combined with strict quality control procedures in the production process ensures this level of excellence is maintained.
- Page 4 It is strongly recommended that you store all the packaging to allow protected transportation in future. An exclusive five way terminal panel has been designed for the Definition range to optimise performance further by take advantage of the driver earthing facility. Use a shielded or screened loudspeaker cable; connecting the screening termination to the earth or 'ground' (green) terminal on the loudspeaker and to the ground or earth connection on the amplifier.
- Page 5 Switch the amplifier on with the volume control set at its lowest setting. Select a favourite source and slowly turn up the volume to a low level. Check that bass and treble information is being reproduced from both speakers - if not, switch off the amplifier and recheck the connections. DEFINITION MANUAL...
- Page 6 Avoid potential damage to your amplifier - ensure that all connections are secure and the polarity is correct in all wiring. (Method illustrated on all terminal panel sketches) To get best results from your new Tannoy Definition loudspeakers it is worthwhile spending a little time finding the optimum set-up configuration.
- Page 7 (40.4 x 10.7 x 9.4”) (44.3 x 13.4 x 13”) High gloss black High gloss black High gloss black High gloss cherry High gloss cherry High gloss cherry High gloss dark walnut High gloss dark walnut High gloss dark walnut DEFINITION MANUAL...
- Page 8 DEFINITION MANUAL...
- Page 9 HIGH FREQUENCY POSITIVE(+) TERMINAL HIGH FREQUENCY NEGATIVE(-) TERMINAL LOW FREQUENCY POSITIVE(+) TERMINAL LOW FREQUENCY NEGATIVE(-) TERMINAL 'EARTH' OR 'GROUND' TERMINAL TO RIGHT SPEAKER POWER AMPLIFIER TO 'GROUND' OR 'EARTH' CONNECTION ON AMPLIFIER (OPTIONAL) LINKS IN PLACE DEFINITION MANUAL...
- Page 10 POWER AMPLIFIER TO 'GROUND' OR 'EARTH' CONNECTION ON AMPLIFIER (OPTIONAL) LINKS REMOVED TO RIGHT SPEAKER HIGH FREQUENCY POWER AMPLIFIER LOW FREQUENCY POWER AMPLIFIER TO RIGHT SPEAKER TO 'GROUND' OR 'EARTH' CONNECTION ON HIGH FREQUENCY AMPLIFIER (OPTIONAL) LINKS REMOVED 010_ DEFINITION MANUAL...
- Page 11 0.5 METRES OR MORE 1.5 TO 4.5 METRES 1 METRE OR MORE _011 DEFINITION MANUAL...
- Page 12 T: 00 1 (519) 745 1158 E: inquiries@tannoyna.com Tannoy Deutschland T: 00 49 (180) 1111 881 E: anfragen@tannoy.com Tannoy France T: 00 33 (0)1 7036 7473 E: ventes@tannoy.com Tannoy adopts a policy of continuous improvement and product specification is subject to change.
