  • Page 1 AT-9800 SERIES QUICK INSTALL GUIDE...
  • Page 2 AT-9800 Series Quick Install Guide Document Number C613-04038-01 REV D. Copyright © 2003 Allied Telesyn International, Corp. 19800 North Creek Parkway, Suite 200, Bothell, WA 98011, USA. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn.
  • Page 3: Models Covered By This Guide

    AT-9800 Series Hardware Reference Printed Acrobat PDF Website Models Covered By This Guide This Quick Install Guide includes information on the following models: ■ AT-9812T ■ AT-9812TF ■ AT-9816GB ■ AT-9816GF Quick Install Guide updates can be downloaded from www.alliedtelesyn.co.nz/support/at9800/.
  • Page 4: Selecting A Site

    AT-9800 Series Selecting a Site The switch can be installed in a standard 19-inch rack or on a level surface such as a desktop or bench. When installing the switch, choose a site that: ■ Allows adequate airflow around the switch and its vents ■...
  • Page 5 Quick Install Guide Install CAM (Optional) If you purchased a Content Addressable Memory (CAM) module, install it now by following the instructions in the CAM Quick Install Guide. The CAM Quick Install Guide can be found on the AT-9800 Series Documentation and Tools CD-ROM, or can be downloaded from www.alliedtelesyn.co.nz/support/at9800/.
  • Page 6 AT-9800 Series Only trained and qualified personnel should connect a DC power supply. Due to exposed terminals, DC powered switches should only be installed in Restricted Access Areas. DC supply cable specifications (one cable is required for each PSU): • Number of wires (cores): 3 •...
  • Page 7 Quick Install Guide AT-9812TF and AT-9816GF models can be used with AT-RPS8000 RPS systems, while AT-9812T and AT-9816GB models can be used with AT-RPS9000 systems. RPS systems can be purchased separately, contact your authorised Allied Telesyn distributor or reseller for more information.
  • Page 8: Configuring The Switch

    AT-9800 Series Make sure each cable connection is secure. The switch will now perform basic Layer 2 switching functions. Configuring the Switch Some configuration is necessary if you wish to enable the switch’s advanced switching capabilities. The switch can be configured via the Command Line Interface (CLI) or Graphical User Interface (GUI).
  • Page 9 Quick Install Guide Load help files To access help, enter: set help=help-filename where help-filename is the name of a help file stored in flash. To see a list of files stored in flash, enter: show file Help files have an HLP extension. To display a list of help topics, enter: help To display help on a specific topic, enter:...
  • Page 10: System Leds

    AT-9800 Series Log in At the log in prompt, enter the log in name and password. User Name: manager Password: friend The system status page appears and you can now use the GUI to configure the switch. To ensure configuration settings are saved correctly, use the GUI pages’ menus and buttons to navigate, not your browser’s buttons.
  • Page 11: Documentation And Tools Cd-Rom

    Quick Install Guide The AT-9800 Series Hardware Reference has further troubleshooting information, including information on Switch Port LEDs. Documentation and Tools CD-ROM The Documentation and Tools CD-ROM bundled with each switch contains the complete Documentation Set for AT-9800 Series switches and their expansion options, as well as tools for managing the Switch.
