Page 1: Instruction Manual
MEAT-CUTTING BANDSAW MODEL G0560 INSTRUCTION MANUAL COPYRIGHT © DECEMBER, 2003 BY GRIZZLY INDUSTRIAL, INC. WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. #5906 PRINTED IN TAIWAN... - Page 2 WARNING Some dust created by power sanding, sawing, grind- ing, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...
-
Page 3: Table Of Contents
Cutting Bone ...27 Grinding Meat...27 SECTION 7: CLEANING/SANITIZING...28 Cleaning the Saw ...28 Proper Sanitation ...29 SECTION 8: MAINTENANCE ...30 SECTION 7: REFERENCE INFO ...31 G0560 Data Sheet ...32 G0560 Wiring Diagram...33 G0560 Parts Breakdown & Parts Lists ...34 Warranty & Returns ...38... -
Page 4: Section 1: Safety
G0560 Meat-Cutting Bandsaw VISITORS... - Page 5 14. MAINTAIN TOOLS WITH CARE. Keep tools sharp and clean for best and safest performance. Follow instructions for lubri- cating and changing accessories. G0560 Meat-Cutting Bandsaw 15. USE RECOMMENDED ACCESSORIES. 16. REDUCE THE RISK OF UNINTENTION- LENGTH 17. MANY WOODWORKING TOOLS CAN...
-
Page 6: Additional Safety Instructions For Meat Saws
DO NOT MANUALLY STOP OR SLOW BLADE after turning off the saw. Allow it to come to a complete stop before you leave it unattended. AND MAINTENANCE ARE TO BE DONE WITH THE POWER OFF and the plug pulled from the outlet. -
Page 7: Section 2: General Information
When used according to the guidelines stated in this manual, you can expect years of trouble-free, enjoyable operation. The Model G0560 is intended for home or pro- fessional butchers and is capable of cutting through meat and bones. The stainless steel table and easy disassembly of parts allow for proper cleaning and sanitation. -
Page 8: Section 3: Circuit Requirements
SECTION 3: CIRCUIT REQUIREMENTS Amperage Draw The Model G0560 features a 110/220V motor that is prewired at 110V. Amperage Draw 110V (prewired) ... 12 Amps 220V ... 6 Amps Circuit Breaker Use the following guidelines when choosing a cir- cuit breaker (circuit breakers rated any higher are... -
Page 9: Circuit Capacity
G0560 Meat-Cutting Bandsaw Rewiring To 220V The Model G0560 can be rewired to operate on a 220V power source. The motor must be rewired according to the wiring diagram on the motor label. The wiring configuration can also be found on the inside of the motor wire cover, as well as on page 33. -
Page 10: Section 4: Machine Features
SECTION 4: MACHINE FEATURES Figure 2. Main view of machine features. Adjustable Blade Guard Blade Guide Sliding Table Small Cutting Fence ON/OFF Switch Large Cutting Fence Meat Grinder/Sausage Stuffer G0560 Meat-Cutting Bandsaw... -
Page 11: Section 5: Set Up
After all the parts have been removed from the carton, you should have: Base Unit (Figure 3) BEFORE A. Model G0560 Bandsaw Base Unit...1 weight). B. Stand Hardware Bag —Knob Screw M6-1 x 12...17 —Special Hex Bolt M10-1.5 x 16...3 —Hex Bolt M8-1.25 x 20 ...4... - Page 12 In the event that any nonproprietary parts are missing (e.g. a nut or a washer), we would be glad to replace them, or, for the sake of expedi- ency, replacements can be obtained at your local hardware store. G0560 Meat-Cutting Bandsaw...
-
Page 13: Hardware Recognition Chart
Hardware Recognition Chart G0560 Meat-Cutting Bandsaw -11-... -
Page 14: Site Considerations
Floor Load The Model G0560 weighs 127 lbs. and has a base footprint of 16" x 18". Working Clearances Consider existing and anticipated needs, size of material to be processed, and space for auxiliary stands, work tables or other machinery when establishing a location for your bandsaw. -
Page 15: Stand
Switch Cutout V-belt Cutout Figure 7. Stand sides attached to stand top. G0560 Meat-Cutting Bandsaw Place the (4) feet brackets on the stand cor- ners where the rubber feet will be installed. Insert the (4) M6-1 x 20 hex bolts into the rubber feet and attach the feet to the stand corners as shown in Figure 8. -
Page 16: Switch & Cord
(hole below the switch). Tighten the plastic setscrew to secure the cord in place. Mount the switch and cord to the stand side as shown in Figure 12. G0560 Meat-Cutting Bandsaw... -
Page 17: Wiring
The washers should be placed on both sides of the motor mount. Figure 13. Motor mounted to motor mount. G0560 Meat-Cutting Bandsaw Wiring The diagram in Figure 14 shows the proper wiring of the motor and the power cord. The... -
Page 18: Bandsaw Unit
Make sure that the motor does not twist and double check the pulley alignment. Adjust the positioning as needed. Check for approximately ⁄ " deflection. If the belt is not tensioned correctly, repeat steps 1 and 3 until it is correct. G0560 Meat-Cutting Bandsaw... -
Page 19: Blade & Table Guards
Figure 18. Catch tab in place on stand cover. The stand covers fit inside the stand openings and attach by turning the catch tabs over the edges of the stand. G0560 Meat-Cutting Bandsaw Blade & Table Guards The blade and table guards prevent contami- nants from falling into the saw. -
Page 20: Table
To install the sliding table: Secure one end of each rail to the underside of the sliding table as shown in Figure 21. Note—Secure the rail ends to the closed side of the sliding table. Figure 21. Installing rails on table. G0560 Meat-Cutting Bandsaw... - Page 21 Slide the bandsaw blade through the slot in the sliding table and place the table on the rollers. Note—Be careful when placing the table on the saw. The other end of the rails are not secured to the table. Secure the force plate under the open edge of the table with the M6-1 x 12 knob screws as shown in Figure 22.
-
Page 22: Fence
Slide the long fence into the bracket on the left and the short fence into the bracket in front (Figure 27). Secure the fence assemblies in the brackets with knob screws. Figure 27. Fences installed on supports. G0560 Meat-Cutting Bandsaw... -
Page 23: Meat Grinder
Meat Grinder The Model G0560 comes with a meat grinder. Before assembling this for use, clean and sanitize its parts. See Section 5: Sanitation for details on sanitizing. Figure 28 shows the meat grinder components. The meat grinder should not be attached to the saw when not in use. -
Page 24: Section 6: Operations
Always wear safety glasses and hearing protection when operating this machine. The Model G0560 is operated by an ON/OFF paddle switch that is clearly labeled on the side of the stand. This switch is locked out when the key is removed to protect against accidental operation (Figure 31). -
Page 25: Blade Guides
Figure 34. Lower blade guide. G0560 Meat-Cutting Bandsaw The bandsaw blade must be adequately ten- sioned so that it will cut straight and not fall off the wheel during operation. -
Page 26: Blade Tracking
Put on a pair of leather gloves to protect your hands from the sharp edges of the blade. Carefully remove the blade as shown in Figure 37. Figure 37. Removing the bandsaw blade. G0560 Meat-Cutting Bandsaw... -
Page 27: Support Bearing
Strange or unnatural noises should be inves- tigated and corrected before operating the machine further. Run the Model G0560 for a short time to ensure that the moving parts are working properly with no excessive vibration. If any problem develops, correct it before attempting to use the machine. -
Page 28: Cutting Meat
-26- Cutting Meat Your Model G0560 Meat-Cutting Bandsaw will cut through any fresh meat and almost all frozen meat. To cut meat with your bandsaw: Use the side fence to gauge the thickness of your desired cut. -
Page 29: Cutting Bone
G0560 Meat-Cutting Bandsaw Grinding Meat The meat grinder is great for grinding hamburger or sausage. The grinder automatically engages when it is mounted to the bandsaw unit. -
Page 30: Section 7: Cleaning/Sanitizing
(Figure 39). If used, disassemble the meat grinder (Figure 40). Figure 39. Pieces disassembled for cleaning. Figure 40. Meat grinder components Take off the upper wheel cover and open the cabinet door. disassembled for cleaning. G0560 Meat-Cutting Bandsaw... -
Page 31: Proper Sanitation
Prepare the sink. Wash and scrub all sink compartments with dish soap and hot water. Rinse these compartments thoroughly. G0560 Meat-Cutting Bandsaw Fill a sink with soapy water, submerge the item and scrub the entire surface thoroughly. Using hot water, rinse the newly cleaned item in the empty compartment, until all visi- ble suds have been removed. -
Page 32: Section 8: Maintenance
General Regular periodic maintenance on your Model G0560 Meat-Cutting Bandsaw ensures its opti- mum performance. Make a habit of inspecting your bandsaw each time you use it. Check for the following conditions and repair or replace when necessary. -
Page 33: Section 7: Reference Info
Grizzly Service Department. Trained ser- vice technicians will be glad to help you. If you have any comments regarding this manual, please write to Grizzly at the address below: Grizzly Industrial, Inc. Technical Documentation P.O. Box 2069... -
Page 34: Machine Data Sheet
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901 GRIZZLY MODEL G0560 MEAT-CUTTING BANDSAW Design Type ... Floor Model Overall Dimensions: Table ...22 Height ...56" Height From Floor to Table ...35 Width of Unit ...19"... -
Page 35: G0560 Wiring Diagram
G0560 Wiring Diagram G0560 Meat-Cutting Bandsaw -33-... -
Page 36: G0560 Parts Breakdown & Parts Lists
-34- G0560 Meat-Cutting Bandsaw... - Page 37 G0560 Main Saw Assembly REF PART # DESCRIPTION P0560001 Bandsaw Base PN03M Hex Nut M8-1.25 PW01M Flat Washer 8MM P0560004 Blade Cover P0560005 Lower Blade Wheel P0560006 Set Bearing PSS01M Set Screw M6-1 X 10 PB10M Hex Bolt M6-1 X 25...
- Page 38 P0560106 Upper Bracket P0560107 Motor 107-1 PLABEL-38 Gen Motor Label 107-2 P0560107-2 G0560 Motor Data Label 107-3 P0560107-3 Motor Fan Cover 107-4 P0560107-4 Motor Fan 107-5 P0560107-5 Capacitor Cover 107-6 P0560107-6 Start Capacitor 200M 125V 107-7 P0560107-7 Motor Wiring Box...
- Page 39 G0560 Sliding Table Assembly REF PART # DESCRIPTION 201 P0560201 Table (sliding) 202 P0560202 Rollers 203 P0560203 Stand Rod 204 P0560204 Guard Cover 205 P0560205 Roller Shaft 206 P0560206 Fixed Plate 207 P0560207 Right-support 208 P0560208 Pusher 209 P0560209 Roller Fixed Plate...
-
Page 40: Warranty & Returns
WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance. -
Page 41: Warranty Card
Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Industrial to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:__________________________________________________... - Page 42 FOLD ALONG DOTTED LINE FOLD ALONG DOTTED LINE Send a Grizzly Catalog to a friend: GRIZZLY INDUSTRIAL, INC. P.O. BOX 2069 BELLINGHAM, WA 98227-2069 Name_______________________________ Street_______________________________ City______________State______Zip______ TAPE ALONG EDGES--PLEASE DO NOT STAPLE Place Stamp Here...
- Page 44 Buy Direct and Save with Grizzly Visit Our Website Today And Discover Why • • • ® – Trusted, Proven and a Great Value! Grizzly ® Is The Industry Leader! SECURE ORDERING ORDERS SHIPPED WITHIN 24 HOURS E-MAIL RESPONSE WITHIN ONE HOUR...
