Grizzly G0566 Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0566 21" INDUSTRIAL BANDSAW, SINGLE-PHASE

Product Dimensions:

Weight.............................................................................................................................................................. 581 lbs.
Length/Width/Height................................................................................................................. 39-1/2 x 28-5/8 x 78 in.
Foot Print (Length/Width)................................................................................................................. 21-5/8 x 33-1/2 in.

Shipping Dimensions:

Type.................................................................................................................................................... Wood Slat Crate
Content............................................................................................................................................................ Machine
Weight.............................................................................................................................................................. 684 lbs.
Length/Width/Height............................................................................................................................. 40 x 31 x 87 in.

Electrical:

Switch.......................................................................................................Magnetic with Thermal Overload Protection
Switch Voltage...................................................................................................................................................... 220V
Cord Gauge....................................................................................................................................................14 gauge
Recommended Breaker Size............................................................................................................................ 20 amp
Plug.......................................................................................................................................................................... No

Motors:

Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................3 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................15A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer .........................................................................................................................................V-Belt
Bearings.................................................................................................. Shielded and Permanently Lubricated

Main Specifications:

Operation
Blade Speeds..................................................................................................................................... 4600 FPM
Table Tilt............................................................................................................................. Left 5, Right 45 deg.

Cutting Capacities

Height Capacity At Blade..................................................................................................................... 14-1/4 in.
Overall Height Capacity....................................................................................................................... 14-1/8 in.
Throat Capacity Left of Blade.....................................................................................................................20 in.

Blade Information

Standard Blade Length.............................................................................................................................165 in.
Blade Length Range...................................................................................................................... 164 - 165-1/2
Blade Width Range........................................................................................................................ 1/4 - 1-3/8 in.
Upper Blade Guides........................................................................................................................ Ball Bearing
Lower Blade Guides........................................................................................................................ Ball Bearing
The information contained herein is deemed accurate as of 3/20/2008 and represents our most recent product specifications.
Model G0566
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
