OWNER'S MANUAL
Network Video Server
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
LVS301
LVS311
P/NO : MFL62591920

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LVS301 and is the answer not in the manual?

Questions and answers

Summary of Contents for LG LVS301

  • Page 1 OWNER'S MANUAL Network Video Server Please read this manual carefully before operating your set and retain it for future reference. MODEL LVS301 LVS311 P/NO : MFL62591920...
  • Page 2 REGULATORY INFORMATION: FCC Part 15 CAUTION This equipment has been tested and found to comply with the lim- its for a Class A digital device, pursuant to Part 15 of the FCC Rules. RISK OF ELECTRIC SHOCK These limits are designed to provide reasonable protection against DO NOT OPEN harmful interference when the equipment is operated in a commer- cial environment.
  • Page 3 European representative : Warning: To reduce a risk of fire or electric shock, do not expose this LG Electronics Service Europe B.V. Veluwezoom 15, product to rain or moisture. 1327 AE Almere. The Netherlands Caution: This installation should be made by a qualified service per- (Tel : +31-(0)36-547-8888) son and should conform to all local codes.
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is 2. Keep these instructions. used, use caution when moving the cart/apparatus combination 3.
  • Page 5 Cautions for Safe Operation Handling of the unit Operating and storage location Be careful not to spill water or other liquids on the unit. Be cautions Avoid viewing a very bright object (such as light fittings) during an not to get combustible or metallic material inside the body. If used extended period.
  • Page 6: Table Of Contents

    Contents Introduction ................... 7 Accessing the LG IP device..............19 LG Smart Web Viewer Overview ...........21 Front Panel ....................8 Configuring the LG video server ...........22 Rear Panel ....................9 Reference ..................40 Connections ................. 11 Troubleshooting .................40 Precautions ...................11 Open source software notice ............43 Connection Overview ...............11...
  • Page 7: Introduction

    Introduction Features Chart The LG Video Server is designed to use on an Ethernet network and must be assigned an IP address to make it accessible. This table shows the differences between the models. This manual contains instructions on how to install and manage the Use LVS311 is used for the description, operations and details pro- Video Server in your networking environment.
  • Page 8: Front Panel

    Front Panel a b c d POWER NETWORK VIDEO SENSOR POWER Indicator: Lights when the LG Video Server is powered. NETWORK Indicator: Lights when a network cable is connected. VIDEO Indicator: Lights when the camera is connected. SENSOR Indicator: Lights when the alarm out is in progress. Introduction...
  • Page 9: Rear Panel

    Rear Panel b c e f h i VIDEO INPUT Connect the camera’s video output to this BNC connector. RS-485/RS-422 Terminals Connect RS-485/RS-422 compatible cameras. SENSOR IN Terminal Input terminal for sensor signal. RELAY OUT Terminals Output terminals for alarm (relay) signal. Introduction...
  • Page 10 RESET button Push the button more than 3 seconds, this would restore the factory default settings. RS-485/RS-422 Dip Switch The default position of the dip switch and function are as shown below. Position RS-485 RS-485 HALF TERMINATION ON RS-422 RS-485 FULL TERMINATION OFF VIDEO OUT Supplies analog video signal (composite) to the connected device.
  • Page 11: Connections

    Connections Precautions • Be sure to switch off the unit before installation and connection. • The installation should be made by qualified service personnel or system installers. • Do not expose the power and connection cables to moisture, which may cause damage to the unit. Connection Overview RS-485 / 422 RS-485 /...
  • Page 12: Connecting Camera

    Connecting Camera Connect the video output of your camera to the LG Video Server, using a standard 75 Ω video coaxial cable with BNC connector. There are two BNC connectors. Either connector can receive a camera’s signal. This signal is looped-through (directly connected) to the other connec- tor, so that you can send the camera’s signal to other equipment.
  • Page 13: Connecting Network

    You can control and monitor the system via network. With the remote control (monitoring), you can change the system configuration or monitor the image via network. After the installation, check the network settings for the remote control and monitoring work. Connect the LG Video Server to your network using a standard RJ-45 network cable as shown below. Broadband...
  • Page 14: Connecting Power Source

    Connecting Power Source Broadband Broadband Connect power, using one of the methods listed below: Service Service To use the power adapter Connect a DC 12 V / AC 24 V power source to the power input terminal as shown below. 1. Remove the insulation on the power cable as illustrated. 2. Attach the terminal tips. 3. Connect to the DC 12 V / AC 24 V UL Listed, Class 2 Power Supply only on the unit. To use the PoE (Power over Ethernet) device Connect the PoE cable to the LAN port on the unit. You must use the “IEEE802.3af” standard PoE device. PoE Device PoE Device PoE Device (IEEE802.3af )
  • Page 15: Connecting Rs-422/Rs-485 Device

    Connecting RS-422/RS-485 Device Use these ports to connect PTZ Device or an external device of RS-422/RS-485 format. RS-422 RS-422 RS-422 RS-422 RS-422 RS-422 device : Set the dip-switch to RS-422 mode and connect as shown below. Termination OFF Termination ON RS-422 RS-422 RS-422 RS-485 device: Set the dip-switch to RS-485 mode and connect as shown below. Termination OFF Termination ON RS-485 RS-485 RS-485 RS-485 RS-485 RS-485 RS-485 RS-485 (FULL) (HALF) RS-485 RS-485 RS-485 RS-485 (FULL) (HALF)
  • Page 16: Connecting Alarm Device

    Connecting Alarm Device Alarm terminals are used to connect the alarm (relay) devices such as sensors, door switches, etc. Sensor Input Connect the sensor device to the sensor input terminal. Sensor Device Relay Output Connect the alarm (relay) device to the relay output terminal. Alarm signal is outputted at an event occurrence. Alarm (Relay) Alarm (Relay) Device (NC)
  • Page 17: Connecting Microphone And Speaker Device

    Connecting Microphone and Speaker Device Optionally connect an active speaker and/or external microphone with a built-in amplifier. Note: Keep the microphone away from the speaker to avoid howling. Connections...
  • Page 18: Wall Mounting

    Wall Mounting The LG Video Server is supplied with a mounting bracket for wall mounting. The mounting bracket can be positioned for mounting the video server on a vertical surface. Follow the instructions below to attach the brackets to the video server: 1. Install the mounting bracket to the wall with four screws. 2. Assemble the LG Video Server and mounting bracket. (Connect the unit by following step a and b.) 3.
  • Page 19: Operation And Settings

    LG IP device. The LG Smart Station and the LG Smart Web Viewer program DirectX DirectX 9.0 or above are the network program of the LG Video Server and the LG IP cameras. Memory 2 GB or above RAM •...
  • Page 20 IP devices on your network. The IP Utility shows the MAC 3.1 Start your Web browser. address, IP address, Model name and so on. 3.2 Enter the IP address of the LG IP device in the address Note: bar of the browse.
  • Page 21: Lg Smart Web Viewer Overview

    LG Smart Web Viewer Overview Click to save the current image in JPEG format on your computer. 1. Click the [Snapshot] button and then the Snapshot window is displayed. 2. Click the [Save] button in the Snapshot window. 3. Enter the file name (JPEG format) and select the folder to save it. 4. Click the [Save] button to confirm it.
  • Page 22: Configuring The Lg Video Server

    Configuring the LG video server Provides all the necessary tools for setting up the device to your requirements. The The features and options of the LG video server are configured user will need administrator level to do through the Configuration menu.
  • Page 23: System Settings

    Date & Time Main Menu Sub Menu Basic RTP stream Network TCP/IP DDNS IP filtering User Basic Recording schedule Schedule Recording server Event schedule Event Event server Time zone Sensor & Relay Set the time difference from GMT in the area where the IP device is installed.
  • Page 24 Server time > Restore: Click the [Browse] button and select the file in which the configuration setting data is stored and > Server time: Displays the current date and time of the click the [Upload] button. Click the [Restore] button IP device. after successfully uploading the backup configura- • Save: Click this button to confirm the settings. tion. The System settings will be restored to the uploaded configuration and reboot the system.
  • Page 25 It is brighter when a large value is selected and it is darker when a small value is selected. > Standard: Displays the video standard of the camera. Language list > Hue: Edit the video Hue of the camera from 0 to 100. Select a language for the LG Smart Web Viewer configuration • Save: Click this button to confirm the settings. menu and information display. Operation and settings...
  • Page 26 • Default: Click this button to restore the IP device back to > Maximum frame rate: Set the frame rate of the original factory settings. image. Selectable values of the frame rates are as follows. Stream NTSC: 1 to 30 (fps) PAL: 1 to 25 (fps) > GOP size: It means “Group of Pictures”. The higher the GOP, the better is the video quality of the camera. Edit the value of GOP from 1 to 30.
  • Page 27 Audio Audio In > Enable: Enables the check box when you are going to send the audio from the microphone input con- nector. Note: The Clients connected to the IP device remains unaf- fected with additional changes made in the setting. > Audio type: Select the codec when you send the PTZ protocol list audio from the microphone input connector. >...
  • Page 28 0 to 3. > Focus speed: Enter the focus speed of the PTZ device to focus an object clearly near or far. Default value for the LG Multix protocol is 1 and ranges from 1 to 3. 1. Move the camera to the point you want by using the > Preset tour park time: Enter the parking time.
  • Page 29 Note: > To record the pattern 1. Click the [Start recording] button to start the pat- If you set the HOME position, check the [Set home tern recording. position] option. 2. Move the camera through the desired move- • Remove: Click to delete the preset position. ment.
  • Page 30: Network Settings

    Note: Note: If you control the PTZ or OSD, the preset tour will be The RTSP port number should not be same with the stopped. web port number. • Remove: Click this button to delete the selected preset in the [Preset tour list]. > TTL: This option indicates the Time-To-Live of multi- cast packets. The default setting is 7, and the allowed TTL range is from 1 to 255.
  • Page 31 TCP/IP Master / Slave > RTP unicast: When enabled the transmission of the data to the specified equipment happens on a net- work specifying a single address. > RTP multicast: When enabled it reduces the transmis- sion load on the camera by making the computer of the same segment network receive the same trans- mission data.
  • Page 32 IP address. DDNS This free service is very useful when combined with the LG DDNS Server. It allows the user to connect the IP device using the URL, rather than an IP Address. This also solves the problem of having a dynamic IP address.
  • Page 33: User Settings

    2. Set the IP options. Alias: Enter the alias. From: Enter the start IP address for the IP filtering. To: Enter the end IP address for the IP filtering. Note: If you want to deny or to allow a range of IP address- es, enter the start IP address to “From” and the end IP address to “To”. You can also add an IP address by entering the IP address to “From” and “To”. 3. Click the [Save] button. User list 4. Repeat the steps 1 to 3 to add additional IP address. • Remove: Click this button to delete the IP address. > Add the User 1.
  • Page 34: Schedule Settings

    Power user: Use of the limited functions of Maximum RTP stream connection the system (The Configuration menu is not > Maximum number of simultaneous stream connec- allowed. A power user can use the Live View, tion. PTZ control, OSD control and audio functions. Set this number to limit the number of simultaneous Normal user: Provides the lowest level of stream connections.
  • Page 35 To set the Recording Schedule automatically. 1. Click the [Add] button. Recording schedule setting DUPLICATED (C,S): Recording starts automatically window is displayed. from the preset time. When the sensor input is activated within a designated time, change the 2. Set the [Pre alarm] and/or [Post alarm] option. continuous recording mode to the sensor event Pre alarm: Specifies the maximum recording recording mode and recording starts automati-...
  • Page 36 2. To allocate a recording schedule choose the particu- lar one and click the [Allocate] button. These options can be set by using the LG Smart Station pro- gram. (Display only in this LG Smart Web Viewer program.) To deactivate the Recording Schedule Disk full notification of recording server.
  • Page 37: Event Settings

    Event settings Control relay: The relay is activated or deactivated. Event schedule • Stream: Selects the stream of the connected When an event (VA/Sensor Event) occurs, this unit records the camera. live images and routes as configured. • Default: Sets to default setting value. 3. Click the [Save] button to confirm the settings. Note: You should register the SMTP and FTP server on the Event server setting to set this function.
  • Page 38 > To add the FTP server > To add the SMTP server 1. Click the [Add] button. FTP server setting window 1. Click the [Add] button. SMTP server setting win- is displayed. dow is displayed. 2. Set the FTP server options. 2.
  • Page 39 > To edit the SMTP server 1. Choose the SMTP server in the SMTP server list. 2. Click the [Edit] button. You can check or edit the SMTP server options. > To delete the SMTP server 1. Choose the SMTP server in the SMTP server list. 2.
  • Page 40: Reference

    Reference Troubleshooting This section provides useful information to help you to resolve any difficulty you might have with your LG IP device. Fault symptoms, pos- sible causes and remedial actions are provided here. IP Setting problems • ARP/Ping: Disconnect and reconnect the power to the network camera. The device should get the ip within 2 minutes. • Ping your camera: Open the command prompt on your computer, type ping with the IP address of the network device. The reply obtained by this command provides explanation for the cause of the problem.
  • Page 41 Accessing camera external to the local network • Firewall Protection: Check for the internet firewall with the system administrator, either he has to do port forwarding or modify the DMZ function on the router. • Default router needed: Check if you need configure the router settings. Sporadic network performance • Network Switches or hubs used may be of the lower configuration and the load on this may not meet the required conditions of our network camera.
  • Page 42 • If we obtain lower frame rate than set we need to check from the system administrator for sufficient bandwidth available or reduce the number of applications running on the client computer. • If the client PC’s are unable to access the multicast stream, check with the system administrator for the use of a valid multicast address or check if the router is supporting multicasting.
  • Page 43: Open Source Software Notice

    Linux kernel 2.6, bash, busybox, gdbm, libreadline, module-init-tools, mount, mtd-utils, net-tools, quftp, tar, util-linux LGPL LIBRARIES: Glibc, libelf, libesmtp, live.media LG Electronics offers to provide source code to you on CD-ROM for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling upon e-mail request to LG Electronics at: opensource@lge.com This offer is valid for a period of three (3) years from the date of the distribution of this product by LG Electronics.
  • Page 44 This product includes • dhcp client : Copyright © 2004-2008 by Internet Systems Consortium, Inc. (“ISC”) Copyright © 1995-2003 by Internet Software Consortium • expat library : Copyright © 2006 expat maintainers. • libcap • libjpeg : Independent JPEG Group Copyright © 1991 1998, Thomas G. Lane. • libmd5 : Copyright © 2002 Aladdin Enterprises. • libncurses : Copyright © 1998,2002 Free Software Foundation, Inc. • libpcre : Copyright © 1997-2009 University of Cambridge • UPnP SDK : Copyright © 2000-2003 Intel Corporation • libxml2 : Copyright © 1998-2003 Daniel Veillard. • lighttpd : Copyright © 2004, Jan Kneschke, incremental • ntpdate : Copyright © David L. Mills 1992-2006 • OpenSSL : > cryptographic software written by Eric Young (eay@cryptsoft.com).
  • Page 45 > Copyright 1992-1994 Jutta Degener, Carsten Bormann • Zlib : Copyright © 1995-2002 Jean-loup Gailly and Mark Adler. All rights reserved. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation files (the “Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distrib- ute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the follow- ing conditions: THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT.
  • Page 46: Specifications

    Specifications Item LVS301 LVS311 Resolution (Max) 704 x 480 (NTSC), 704 x 576 (PAL) Output RJ-45 (Network), CVBS (Monitor) Frame Rate(Max) 30 fps/25 fps (NTSC/PAL) Compression H.264 (Basic Profile) / MJPEG Dual Stream Audio Full Duplex(Line level input/output ) - Audio Input 1Ch, Audio Output 1Ch Audio Compression G.726, G.711 (A-law, u-law) Sensor/Relay 1 digital input, 1 relay output...
  • Page 47 Item LVS301 LVS311 Physical Layer 10/100 base TX Ethernet Protocol TCP/IP(IPv4), HTTP, HTTPS, RTP, RTSP, UDP, DHCP, FTP, SMTP, NTP, ARP, ICMP, DDNS(LG) IP support Dynamic, Static, Private IP Users Unicast 10 Streams / 50 user registration Operation Temp. / Humidity -10 ºC to 50 ºC / 0 %RH to 80 %RH Power Source PoE, AC 24 V (±20 %) (1 A or above), DC 12 V (±10 %) (2 A or above) Power Consumption About 7 W Dimension (W x H x D) 170.4 mm x 56.2 mm x130.2 mm...
  • Page 48 AB28...
