1. PRODUCT DESCRIPTION

The Wavecom WMOD2B is a dual-band E-GSM 900/1800 modem.
1.1

Package content

The Wavecom WMOD2B modem package comprises:
- 1 Modem
- 2 holding bridles
- 1 Power supply cable + fuse
- 1 User manual (this document)
1.2

Product presentation

The Wavecom WMOD2B modem supports DATA and FAX transmission, Short Messages (Point to Point and Cell Broadcast)
and VOICE calls.
The connectors binded to the body guarantee output and input connections.
An extractible holder is used to insert the SIM card (Micro-SIM type). A LED indicates the operating mode.
Micro-Fit
TM
connector
Front cap
Wavecom WMOD2B Modem
Back cap
SUB HD
connector
Figure 1
Modem presentation
1
LED
Extractible
SIM holder
SMA
connector
