Wavecom SAM User Manual page 13

The recommended dual-band or quad-band antenna used with the SAM should have the
c.
following characteristics :
- Frequency range : Quad band GSM 850/900/1800/1900MHz
Impedance : 50Ω
-
- VSWR : Rx Max = 1.5 : 1, Tz Max = 1.5 : 1
- Typical radiated Gain : 0dBi
d. Temperature :
- Operating temperature : -20ºC to +55ºC
- Storage temperature : -25ºC to 70ºC
e. Conformity :
- Safety standard : EN60950
- Efficient use of radio spectrum : EN301 419 (Ver 4.1.1)
- EMC : EN 301 489-1, EN301 489-7
- Global Certification Forum- Certification Criteria : GCF-CC 3.13
EN301 511 (Ver 7.0.1)
