Grizzly G9979 Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9979 43" WIDE-BELT SANDER, 3-PHASE
Product Dimensions:
Weight............................................................................................................................................................ 2420 lbs.
Length/Width/Height............................................................................................................................. 50 x 62 x 70 in.
Foot Print (Length/Width)....................................................................................................................... 60 x 20-1/2 in.
Shipping Dimensions:
Type.................................................................................................................................................... Wood Slat Crate
Content............................................................................................................................................................ Machine
Weight............................................................................................................................................................ 2490 lbs.
Length/Width/Height............................................................................................................................. 53 x 65 x 72 in.
Electrical:
Switch.................................................................................................................................. ON/OFF Emergency Stop
Switch Voltage...................................................................................................................................................... 200V
Minimum Circuit Size........................................................................................................................................ 60 amp
Plug Included............................................................................................................................................................ No
Conversion To 440V................................................................................................................................... P99799139
Phase Converter.................................................................................................................................................H3741
Motors:
Table Elevation
Type........................................................................................................................................... TEFC Induction
Horsepower..............................................................................................................................................1/4 HP
Voltage.................................................................................................................................................220/440V
Prewired......................................................................................................................................................220V
Phase.........................................................................................................................................................Three
Amps......................................................................................................................................................1.2/0.6A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings.......................................................................................................................... Sealed and Lubricated
Sanding
Type........................................................................................................................................... TEFC Induction
Horsepower...............................................................................................................................................25 HP
Voltage.................................................................................................................................................220/440V
Prewired......................................................................................................................................................220V
Phase.........................................................................................................................................................Three
Amps........................................................................................................................................................64/32A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ............................................................................................................................... V-Belt Drive
Bearings.......................................................................................................................... Sealed and Lubricated
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G9979
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MACHINE DATA
SHEET
PAGE 1 OF 3
