Use this manual along with the advanced diagnostic tests to troubleshoot problems effectively. Before servicing a ThinkPad product, be sure to read all the information under Chapter 1 “Safety information” on page 1 and Chapter 2 “Important service information” on page 29.
Chapter 1. Safety information This chapter presents following safety information that you need to be familiar with before you service a ThinkPad Notebook. • “General safety” on page 1 • “Electrical safety” on page 2 • “Safety inspection guide” on page 3 •...
– Pumps – Blowers and fans – Motor generators – Similar units to listed above This practice ensures correct grounding of the units. • If an electrical accident occurs: ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
This guide addresses only those items. You should use good judgment to identify potential safety hazards due to attachment of non-ThinkPad features or options not covered by this inspection guide. If any unsafe conditions are present, you must determine how serious the apparent hazard could be and whether you can continue without first correcting the problem.
The safety notices in this section are provided in the following languages: • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
The laser compliance statements in this section are provided in the following languages: • English • Arabic • Brazilian Portuguese • French • German • Hebrew • Japanese • Korean • Spanish • Traditional Chinese ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Chapter 2. Important service information This chapter presents following important service information that applies to all machine types supported by this manual: • “Strategy for replacing FRUs” on page 29 – “Strategy for replacing a hard disk drive” on page 30 –...
(Example: 1829-CTO). The PRODUCT ID portion of the machine label is the 4-digit MT and 3-digit CMV model (Example: 1829-W15). • The PEW record is the 4-digit MT and 3-digit model, where model = “CTO” (Example: 1829-CTO). ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
• eSupport will show both the CTO and CMV machine type models (Example: 1829-CTO and 1829-W15 will be found on the eSupport site.) • The HMM will have the 4-digit MT and 3-digit CTO model only (Example: 1829-CTO). Again, CMVs are custom models and are not found in the HMM.
Page 40
Use the HMM as a back-up to PEW and eSupport to view the complete list of FRUs at the MT Model level. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
• “Power system checkout” on page 39 ® The descriptions in this chapter apply to any ThinkPad model that supports the PC-Doctor for DOS diagnostics program. Some descriptions might not apply to your particular computer. Before you go to the checkout guide, be sure to read the following important notes.
Checkout guide Use the following procedures as a guide in identifying and correcting problems with the ThinkPad Notebook. Note: The diagnostic tests are intended to test only ThinkPad products. The use of non-ThinkPad products, prototype cards, or modified options can lead to false indications of errors and invalid system responses.
39, and check the power sources. If an error code appears, go to “Symptom-to-FRU index” on page 48. 4. When the ThinkPad logo comes up, immediately press F12 to enter the Boot Menu. 5. Insert the PC-Doctor CD into the internal optical drive.
Page 44
• In the Keyboard test in Interactive Tests, the Fn key should be held down for at least 2 seconds; otherwise, it cannot be sensed. • Video Adapter test supports only the LCD display on the ThinkPad Notebook. If you have an external monitor attached to your computer, detach it before running PC-Doctor for DOS.
For additional information about this program, see the Help for the program. PC-Doctor for Windows In some models of ThinkPad Notebook, PC-Doctor for Windows enables you to troubleshoot and resolve problems related to the computer. Select one of the categories listed below to display symptoms and solutions: •...
Page 46
1. Diagnostics ➙ CPU/Coprocessor. 2. Diagnostics ➙ Systemboard. 3. If the ThinkPad X200 Ultrabase™ is attached to the ThinkPad computer, detach it. Place the computer on a horizontal surface, and run Diagnostics ➙ ThinkPad ➙ Devices ➙ HDD Active Protection Test.
You are here because the computer fails only when the ac adapter is used. • If the power problem occurs only when the ThinkPad X200 UltraBase is used, replace the UltraBase. • If the power-on indicator does not turn on, check the power cord of the ac adapter for correct continuity and installation.
3. Remove the battery pack (see “1010 Battery pack” on page 71). 4. Remove the backup battery (see “1060 Backup battery” on page 82). 5. Measure the voltage of the backup battery. See the following figure. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 49
Wire Voltage (V dc) +2.5 to +3.2 Black Ground • If the voltage is correct, replace the system board. • If the voltage is not correct, replace the backup battery. • If the backup battery discharges quickly after replacement, replace the system board. Chapter 3 General checkout...
Chapter 4. Related service information This chapter presents following information: • “Restoring the factory contents by using Product Recovery discs” on page 43 • “Restoring the factory contents by using Recovery Disc Set” on page 43 • “Passwords” on page 45 •...
Page 52
11. After you have completed the Windows setup, you might want to restore the original startup sequence. Start the Setup Utility program and then press F9 to restore the default settings. Press F10 to save and exit the Setup Utility. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Note: After restoring a drive to the factory default settings, you might need to reinstall some device drivers. Passwords As many as three passwords may be needed for any ThinkPad Notebook: the power-on password (POP), the hard-disk password (HDP), and the supervisor password (SVP).
(B) If an SVP has been set and is known by the service technician: 1. Turn on the computer. 2. When the ThinkPad logo comes up, immediately press F1 to enter BIOS Setup Utility.For models supporting the Passphrase function, press F1 while the POP icon is appearing on the screen; then enter the POP.
Screen blank mode If the time set on the “Turn off monitor” timer in the operating system expires, the LCD backlight turns off. To put the computer into screen blank mode, do as follows: 1. Press Fn+F3. A panel for selecting a power plan (in Windows XP, power scheme) appears. 2.
If no numeric code is displayed, check the narrative descriptions of symptoms. If the symptom is not described there, go to “Intermittent problems” on page 55. Note: For a device not supported by diagnostic codes in the ThinkPad Notebooks, see the manual for that device.
Numeric error codes Table 2. Numeric error codes Symptom or error FRU or action, in sequence 0175 System board. Bad CRC1, stop POST task—The EEPROM checksum is not correct. 0176 1. Run BIOS Setup Utility, and save the current System Security—The system has been tampered with. setting by pressing F10.
Page 58
1. Charge the backup battery for more than 8 hours System timer error. by connecting the ac adapter. 2. Replace the backup battery and run BIOS Setup Utility to reset the time and date. 3. System board. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 59
Table 2. Numeric error codes (continued) FRU or action, in sequence Symptom or error 0270 1. Charge the backup battery for more than 8 hours Real-time clock error. by connecting the ac adapter. 2. Replace the backup battery and run BIOS Setup Utility to reset the time and date.
Page 60
2011: HDD1 (in HDD slot-1) 2012: Ultrabay with HDD adapter 2100 1. Reseat the hard disk drive. Initialization error on HDD0 (Main hard disk drive) 2. Main hard disk drive. 3. System board. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 2. Numeric error codes (continued) FRU or action, in sequence Symptom or error 2102 1. Reseat the hard disk drive. Initialization error on HDD1 (Ultrabay hard disk drive) 2. Ultrabay™ hard disk drive. 3. System board. 2110 1. Reseat the hard disk drive. Read error on HDD0 (Main hard disk drive) 2.
Only the cursor appears. Reinstall the operating system. Four cycles of four short beeps and a blank screen. System board (security chip) Five short beeps and a blank screen. System board ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Notes: • This policy applies to all ThinkPad Notebooks purchased on 1 January, 2008 or later. • Lenovo will not provide replacement if the LCD is within specification as we cannot guarantee that any replacement LCD will have zero pixel defects.
6. If the problem does not recur, reconnect the removed devices one at a time until you find the failing FRU. 7. If the problem remains, replace the following FRUs one at a time (do not replace a nondefective FRU): a. System board b. LCD assembly ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 66
The wireless WAN is on, and the radio status link is ready for use, or the data is being transmitted. Blinking green: Data is being transmitted (for some models). ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 67
Table 7. Status indicators (continued) Indicator Meaning Wireless PAN status Green: Wireless PAN (Bluetooth wireless or Wireless USB) is operational. This indicator is on when Wireless PAN is on and not in suspend mode, or the data is being transmitted. Blinking green: Data is being transmitted (for some models).
(power scheme) appears. Notes: 1. To use the Fn+F3 key combination, you must have the ThinkPad PM device driver installed on the computer. 2. If you have logged on with an administrator user ID, and you press Fn+F3, the panel for selecting a power plan (power scheme) appears.
Page 70
Fn+F12 Put the computer into hibernation mode. To return to normal operation, press the power button for less than four seconds. Note: To use Fn+F12 for hibernation, you must have the ThinkPad PM device driver installed on the computer. ®...
Page 71
Table 8. Fn key combinations (continued) Key combination Description Fn+Pause Has the same function as the Break key. Fn+cursor keys These key combinations work with Windows Media Player. Fn+down arrow key works for the Play or Pause button, Fn+up arrow key for the Stop button, Fn+right arrow key for the Next Track button, and Fn+left arrow key for the Previous Track button.
CRU. See your Lenovo Limited Warranty documentation for full details. Screw notices Loose screws can cause a reliability problem. In the ThinkPad Notebook, this problem is addressed with special nylon-coated screws that have the following characteristics: •...
If you replace the system board, you must restore the serial number of the system unit to its original value. Before replacing the system board, save the original serial number by doing the following: 1. Install the ThinkPad Hardware Maintenance Diskette Version 1.73 or later, and restart the computer. 2. From the main menu, select 1. Set System Identification.
When you replace the system board, you must set the UUID on the new system board as follows: 1. Install the ThinkPad Hardware Maintenance Diskette Version 1.73 or later, and restart the computer. 2. From the main menu, select 4. Assign UUID. A new UUID is created and written. If a valid UUID already exists, it is not overwritten.
Chapter 8. Removing and replacing a FRU This chapter presents directions and drawings for use in removing and replacing a FRU. Be sure to observe the following general rules: 1. Do not try to service any computer unless you have been trained and certified. An untrained person runs the risk of damaging parts.
Before servicing ThinkPad X200, X200s, X200si, X201, X201i, and X201s Removing the SIM card: Some models of the ThinkPad X200, X200s, X200si, X201, X201i, and X201s you are servicing might have the SIM card that the customer has been installed.
1010 Battery pack Important notice for replacing a battery pack: Lenovo ThinkVantage Toolbox (in Windows 7) and Lenovo System Toolbox (in Windows Vista and Windows XP) have an automatic battery diagnostic that determines if the battery pack is defective. A battery pack FRU should not be replaced unless this diagnostic shows that the battery is defective.
Page 80
Table 10. Removal steps of HDD cover, HDD, and HDD drive rubber rails or SSD and storage converter Step Screw (quantity) Color Torque Black 0.392 Nm Hard disk drive screw, M3 × 3 mm, wafer-head, nylon-coated (1) (4 kgfcm) ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 81
Table 10. Removal steps of HDD cover, HDD, and HDD drive rubber rails or SSD and storage converter (continued) When installing: Make sure that the HDD connector or SSD connector is attached firmly. HDD and HDD rubber rails: When installing: The rubber rails on the hard disk drive must be attached to the replacement drive.
When installing: When you install the SSD in the storage converter, do as follows. 1030 DIMM For access, remove this FRU in order: • “1010 Battery pack” on page 71 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 83
Note: Loosen the screws , but do not remove them. Note: For ThinkPad X200, X200s, and X200si, if only one DIMM is used on the computer you are servicing, the card must be installed in SLOT-0 ( ), but not in SLOT-1 (...
Page 84
Table 11. Removal steps of dimm (continued) For ThinkPad X201, X201i, and X201s: ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 11. Removal steps of dimm (continued) When installing: Insert the notched end of the DIMM into the socket. Press the DIMM firmly, and pivot it until it snaps into the place. Make sure that it is firmly fixed in the slot and does not move easily. 1040 Keyboard For access, remove this FRU in order: •...
Page 86
Table 12. Removal steps of keyboard Step Icon Screw (quantity) Color Torque M2 × 5 mm, wafer-head, nylon-coated (4) Black 0.181 Nm (1.85 kgfcm) ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 87
Table 12. Removal steps of keyboard (continued) Lift the keyboard a little in the direction shown by arrow , and then detach the connector When installing: 1. Attach the keyboard connector firmly. 2. Make sure that the keyboard edges are under the frame as shown in this figure. Then press the keys to latch the keyboard firmly in place.
Table 13. Removal steps of palm rest ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 89
Table 13. Removal steps of palm rest (continued) Step Icon Screw (quantity) Color Torque M2 × 5 mm, wafer-head, nylon-coated (5) Black 0.181 Nm (1.85 kgfcm) Note: Step is only for models with the fingerprint reader. For models without the fingerprint reader, skip step Chapter 8 Removing and replacing a FRU...
For access, remove these FRUs in order: • “1010 Battery pack” on page 71 • “1040 Keyboard” on page 77 • “1050 Palm rest or palm rest with fingerprint reader” on page 80 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 14. Removal steps of backup battery When installing: Make sure that the battery connector is attached firmly. 1070 PCI Express Mini Card for wireless LAN/WiMAX For access, remove these FRUs in order: • “1010 Battery pack” on page 71 •...
Page 92
Note: Some models might have two antenna cables in step Step Screw (quantity) Color Torque Black 0.181 Nm M2 × 3 mm, wafer-head, nylon-coated (2) (1.85 kgfcm) ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 93
Table 15. Removal steps of PCI Express Mini Card for wireless LAN/WiMAX (continued) When installing: • In models with wireless LAN card that has two antenna connectors, plug the gray cable into the jack labeled MAIN or M on the card, and the black cable into the jack labeled AUX or A. If the computer you are servicing has three cables, put the white cable in the cable protection tube.
, unplug the jacks by using the removal tool antenna RF connector (P/N: 08K7159) or pick the connectors with your fingers and gently unplug them in direction of the arrow. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 16. Removal steps of PCI Express Mini Card for wireless WAN (continued) Step Screw (quantity) Color Torque M2 × 3 mm, wafer-head, nylon-coated (2) Black 0.181 Nm (1.85 kgfcm) When installing: Plug the red cable into the jack labeled MAIN on the card, and the blue cable into the jack labeled AUX. 1090 Intel Turbo Memory Minicard or Wireless USB PCI Express Half-Mini Card For access, remove these FRUs in order:...
In models with the Wireless USB PCI Express Half-Mini Card, plug the yellow cable into the jack on the card. 1100 Keyboard bezel For access, remove these FRUs in order: • “1010 Battery pack” on page 71 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Attention: When you service the keyboard bezel, avoid any kind of rough handling. When installing: Make sure that all the claws are attached firmly. 1110 Monaural speaker assembly (for X200, X200s, X201s, and X201si) For access, remove these FRUs in order: •...
Table 19. Removal steps of monaural speaker assembly (for X200, X200s, X201s, and X201si) When installing: Make sure that the speaker connector is attached firmly. 1120 I/O card assembly For access, remove these FRUs in order: • “1010 Battery pack” on page 71 •...
Page 99
Table 20. Removal steps of I/O card assembly Note: The cable is secured with a double-faced adhesive tape. Note: Step is only for ThinkPad X201. For the other models, skip the step Step Screw (quantity) Color Torque 0.181 Nm M2 × 3.5 mm, wafer-head, nylon-coated (1) Silver (1.85 kgfcm)
• “1090 Intel Turbo Memory Minicard or Wireless USB PCI Express Half-Mini Card” on page 87 • “1100 Keyboard bezel” on page 88 Table 21. Removal steps of LCD assembly ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 101
Table 21. Removal steps of LCD assembly (continued) Step Screw (quantity) Color Torque M2 × 5 mm, wafer-head, nylon-coated (2) Black 0.181 Nm (1.85 kgfcm) Torque Step Screw (quantity) Color M2 × 5 mm, wafer-head, nylon-coated (2) Black 0.181 Nm (1.85 kgfcm) Before step , strip off the tapes securing the antenna cables, and release the cables from the cable guides...
Page 102
Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. 2. Make sure that the LCD connector is attached firmly. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
• “1090 Intel Turbo Memory Minicard or Wireless USB PCI Express Half-Mini Card” on page 87 • “1100 Keyboard bezel” on page 88 • “1110 Monaural speaker assembly (for X200, X200s, X201s, and X201si)” on page 89 • “1120 I/O card assembly” on page 90 •...
Page 104
Table 22. Removal steps of base cover assembly for ThinkPad X200, X201, and X201i (continued) Torque Step Screw (quantity) Color M2 × 3.5 mm, wafer-head, nylon-coated (1) Black 0.181 Nm (1.85 kgfcm) Note: Step is only for X201 and X201i.
Page 105
Table 22. Removal steps of base cover assembly for ThinkPad X200, X201, and X201i (continued) In step , remove the system board, the DC-in connector, and the fan assembly together from the base cover assembly. When installing: Check the position of the wireless switch , and firmly fit the system board into the base cover assembly.
Page 106
Table 23. Removal steps of base cover assembly for ThinkPad X200s, X200si, and X201s ThinPad X200s, X200si and X201s Remove the top shielding assembly at first. Torque Step Screw (quantity) Color M2 × 3 mm, wafer-head, nylon-coated (1) Black 0.181 Nm (1.85 kgfcm)
Page 107
Table 23. Removal steps of base cover assembly for ThinkPad X200s, X200si, and X201s (continued) Step Screw (quantity) Color Torque M2 × 3.5 mm, wafer-head, nylon-coated (4) Silver 0.181 Nm (1.85 kgfcm) M2 × 3 mm, large-head, nylon-coated (1) Silver 0.181 Nm...
1150 Systemboard, DC-in connector, fan, and ExpressCard slot assembly Notes: When you replace any of the following system boards, be sure that the new one has the same ROM size as the original one. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 109
The procedure is as follows: 1. Place the computer on a horizontal surface. 2. Run Diagnostics ➙ ThinkPad Devices ➙ HDD Active Protection Test. Attention: Do not apply physical shock to the computer while the test is running. For access, remove these FRUs in order: •...
Page 110
“1130 LCD assembly” on page 92 • “1140 Base cover assembly and stereo speaker assembly for X201 and X201i” on page 95 Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i Following components soldered on the system board are extremely sensitive.
Page 111
Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i (continued) ThinkPad X201 and X201i PCH (Platform Controller Hub) Accelerometer chip for the HDD Active Protection System Bottom Chapter 8...
Page 112
Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i (continued) Note: The DC-in connector and the fan assembly are attached to the underside of the system board. Note: Step is only for ThinkPad X200.
Page 113
Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i (continued) Step Screw (quantity) Color Torque 0.181 Nm M2 × 3.5 mm, flat-head, nylon-coated (1) Silver (1.85 kgfcm) When installing: •...
Page 114
Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i (continued) • Make sure that the fan connector is attached firmly. Note: The ExpressCard slot assembly is attached to the system board.
Page 115
Table 24. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200, X201, and X201i (continued) Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s ThinkPad X200s Following components soldered on the system board are extremely sensitive.
Page 116
Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s (continued) ThinkPad X201s PCH (Platform Controller Hub) Accelerometer chip for the HDD Active Protection System Bottom Note: Step in only for ThinkPad X201s.
Page 117
Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s (continued) Step Screw (quantity) Color Torque 0.181 Nm M2 × 3.5 mm, wafer-head, nylon-coated (1) Silver (1.85 kgfcm) Note: The DC-in connector and the fan assembly are attached to the underside of the system board.
Page 118
Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s (continued) Step Screw (quantity) Color Torque 0.181 Nm M2 × 3.5 mm, wafer-head, nylon-coated (1) Silver (1.85 kgfcm) When installing: • Before you attach the fan assembly to the computer, apply thermal grease, at an amount of 0.2 grams, on the part marked as in the following figure.
Page 119
Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s (continued) Note: The ExpressCard slot assembly is attached to the system board. For ThinkPad X200s: For ThinkPad X201s: Step Screw (quantity)
Table 25. Removal steps of system board, DC-in connector, fan, and ExpressCard slot assembly for ThinkPad X200s and X201s (continued) 2010 LCD front bezel For access, remove this FRU: • “1010 Battery pack” on page 71 Table 26. Removal steps of LCD front bezel for 12.1-in. WXGA LCD model 12.1-in.
Page 121
Table 26. Removal steps of LCD front bezel for 12.1-in. WXGA LCD model (continued) In step , detach the claws. Then remove the LCD front bezel. When installing: Make sure that all the claws are attached firmly. Table 27. Removal steps of LCD front bezel for 12.1-in. WXGA+ LCD model 12.1-in.
“1010 Battery pack” on page 71 • “2010 LCD front bezel” on page 112 Table 28. Removal steps of inverter card or LED board For ThinkPad X200, X200s, and X200si: ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 123
Table 28. Removal steps of inverter card or LED board (continued) Torque Step Screw (quantity) Color M2 × 3.5 mm, wafer-head, nylon-coated (1) Silver 0.181 Nm (1.85 kgfcm) When installing: Make sure that the connector are attached firmly. Cabling: When replacing the inverter card or the LED board, route the connector cable as in this figure. Chapter 8 Removing and replacing a FRU...
2030 Bluetooth daughter card (BDC-2.1) For access, remove these FRUs in order: • “1010 Battery pack” on page 71 • “2010 LCD front bezel” on page 112 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 29. Removal steps of Bluetooth daughter card When installing: Make sure that the connector is attached firmly. 2040 Integrated camera For access, remove these FRUs in order: • “1010 Battery pack” on page 71 • “2010 LCD front bezel” on page 112 Chapter 8 Removing and replacing a FRU...
“2010 LCD front bezel” on page 112 • “2020 Inverter card or LED board” on page 114 • “2030 Bluetooth daughter card (BDC-2.1)” on page 116 • “2040 Integrated camera” on page 117 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 127
Table 31. Removal steps of LCD panel, LCD brackets, and LCD cable for 12.1-in. WXGA LCD model 12.1-in. WXGA LCD model: Step Screw (quantity) Color Torque Black 0.392 Nm M2.5 × 4 mm, wafer-head, nylon-coated (2) (4 kgfcm) 0.181 Nm M2 ×...
Page 128
Table 31. Removal steps of LCD panel, LCD brackets, and LCD cable for 12.1-in. WXGA LCD model (continued) In step , release the antenna cables from the cable guides, and then remove the LCD panel. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 129
Table 31. Removal steps of LCD panel, LCD brackets, and LCD cable for 12.1-in. WXGA LCD model (continued) Remove the LCD bracket Step Screw (quantity) Color Torque M2 × 2 mm, wafer-head, nylon-coated (4) Black 0.181 Nm (1.85 kgfcm) Turn the LCD panel over, and then remove the LCD cable from the LCD panel.
Page 130
Table 32. Removal steps of LCD panel, LCD brackets, and LCD cable for 12.1-in. WXGA+ LCD model 12.1-in. WXGA+ LCD model: Torque Step Screw (quantity) Color M2 x 2 mm, wafer-head, nylon-coated (1) Silver 0.181 Nm (1.85 kgfcm) ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 32. Removal steps of LCD panel, LCD brackets, and LCD cable for 12.1-in. WXGA+ LCD model (continued) Turn the LCD panel over, and then remove the LCD cable from the LCD panel. When installing: Make sure that the LCD cable connector is attached firmly. 2060 Hinges and hinge brackets For access, remove these FRUs in order: •...
Page 132
Table 34. Removal steps of hinges and hinge brackets for 12.1-in. WXGA+ LCD model 12.1-in. WXGA+ LCD model: In step , release the antenna cables from the cable guides. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 34. Removal steps of hinges and hinge brackets for 12.1-in. WXGA+ LCD model (continued) Remove the hinges and the hinge brackets Step Screw (quantity) Color Torque M2.5 x 4 mm, wafer-head, nylon-coated (2) Black 0.392 Nm (4 kgfcm) 2070 LCD rear cover and wireless antenna cables For access, remove these FRUs in order: •...
Page 134
Table 35. Removal steps of LCD rear cover and wireless antenna cables for 12.1-in. WXGA LCD model 12.1-in. WXGA LCD model: Torque Step Screw (quantity) Color M2 × 3.5 mm, wafer-head, nylon-coated (2) Silver 0.181 Nm (1.85 kgfcm) ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 135
Table 35. Removal steps of LCD rear cover and wireless antenna cables for 12.1-in. WXGA LCD model (continued) In step , release the antenna cables from the cable guides of the rear cover. Note: Wireless antennas are secured with double-faced adhesive tapes. Chapter 8 Removing and replacing a FRU...
Page 136
Attention: As you route the antenna cables, make sure that they are not subjected to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 137
Table 36. Removal steps of LCD rear cover and wireless antenna cables for 12.1-in. WXGA+ LCD model 12.1-in. WXGA+ LCD model: In step , release the antenna cables from the cable guides of the rear cover. Note: Wireless antennas are secured with double-faced adhesive tapes. Cable routing: Place the antenna assembly as shown in this figure.
Page 138
Attention: As you route the antenna cables, make sure that they are not subjected to any tension. Tension could cause the cables to be damaged by the cable guides, or a wire to be broken. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Chapter 9. Locations This chapter presents the location of ThinkPad X200, X200s, X200si, X201, X201i, and X201s features and hardware. Front view ThinkLight Integrated camera (for some models) Status indicators Note: For the description of each indicator, see Chapter 5 “Status indicators” on page 57.
Universal serial bus (USB) connector AC power connector Bluetooth antenna (for some models) Status indicators Note: For the description of each indicator, see Chapter 5 “Status indicators” on page 57. ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
LCD cover latch Built-in speaker 5-in-1 Media Card Reader or 3-in-1 Media Card Reader slot Hard disk drive (HDD) or solid state drive (SSD) Rear view (ThinkPad X200 UltraBase) AC power connector Universal serial bus (USB) connectors External monitor connector DisplayPort connector...
An N in the CRU ID column means that the part is not a CRU. A single asterisk (*) means that the part is a Self-service CRU; two asterisks (**) means that the part is an Optional-service CRU.ThinkPad computers contain the following types of CRUs:...
Page 149
Table 37. Parts list—Overall (continued) No. FRU FRU no. Notes: When you replace the system board listed below, be sure that the new one has the same ROM size as the original one. • To identify the system board originally installed in your computer, go to PEW at the following web site: http://www.lenovo.com/support/site.wss/document.do?lndocid=LOOK-WARNTY Select Warranty Lookup.
Page 150
System board with Intel Core 2 Duo mobile processor P8800 (2.4 GHz), non-AMT, non-TPM 45M2840 N • 7454-CTO • 7455-CTO • 7454-CTO • 7455-CTO • 7457-CTO • 7458-CTO • 7459-CTO • 2023-CTO • 2024-CTO ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 151
Table 37. Parts list—Overall (continued) No. FRU FRU no. 60Y3794 System board with Intel Core 2 Duo mobile processor T9400 (2.53 GHz), AMT, TPM • 7454-CTO • 7455-CTO • 7457-CTO • 7458-CTO • 7459-CTO • 2023-CTO • 2024-CTO System board with Intel Core 2 Duo mobile processor T9400 (2.53 GHz), AMT, non-TPM 60Y3797 •...
Page 152
System board with Intel Core 2 Duo mobile processor SU9400 (1.4 GHz), AMT, non-TPM • 7462-CTO • 7465-CTO, 3Lx • 7466-CTO, 46x • 7469-CTO • 7470-CTO • 2046-CTO • 2047-CTO ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Page 153
Table 37. Parts list—Overall (continued) No. FRU FRU no. 60Y3868 System board with Intel Core 2 Duo mobile processor SU9600 (1.6 GHz), AMT, TPM • 7462-CTO • 7465-CTO, 3Kx • 7466-CTO, 9Gx • 7469-CTO, 6Px • 7470-CTO • 2046-CTO • 2047-CTO System board with Intel Core 2 Duo mobile processor SU9600 (1.6 GHz), AMT, non-TPM 60Y3871 •...
Page 154
System board with Intel Core 2 Solo mobile processor SU3500 (1.4 GHz), non-AMT, non-TPM 45M2842 N • 7462-CTO • 7465-CTO • 7466-CTO • 7469-CTO • 7470-CTO • 2046-CTO • 2047-CTO ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
45N5784 — AC adapter (see “AC adapters” on page 264.) LCD FRUs In ThinkPad X200, X200s, X200si, X201, X201i, and X201s, there are following types of LCDs. • “12.1-in. WXGA TFT” on page 230 • “12.1-in. WXGA+ TFT” on page 258...
42T3671 U.S. English (International, with a Euro symbol) 42T3767 42T3701 Miscellaneous parts Table 41. Parts list—Miscellaneous parts Screw kit for X200, X200s, and X200si 44C9558 75Y4454 Screw kit for X201, X201i, and X201s Base cover miscellaneous parts kit 44C9556 • SD cover •...
3-pin (65W, 20 V) adapter (models CTO, xxA, xxB, xxC, xxG, xxH, xxK, xxM, xxT, xxV) Power cords A ThinkPad power cord for a specific country or region is usually available only in that country or region: Table 43. Parts list—2-pin power cords Country or region FRU no.
Table 44. Parts list—3-pin power cords FRU no. Country or region Australia, New Zealand 42T5050 42T5135 • models -CTO, xxM 42T5056 42T5141 Bangladesh, Sri Lanka, South Africa • models -CTO, xxG 42T5004 42T5089 Canada, U.S. • models -CTO, xxG, xxT 42T5065 42T5150 China (P.R.C.) (other than Hong Kong S.A.R.)
Table 49. Parts list—Windows Vista Home Premium (32-bit) DVDs Language Danish 58Y2802 English 58Y2815 English (modem-disabled) 58Y2814 58Y2817 English, Finnish, and Swedish (in Sweden) English, French, German, and Dutch (in Belgium and Luxemburg) 58Y2816 58Y2818 English, French, German, and Italian (in Switzerland) French 58Y2803 German...
Page 278
58Y2781 Japanese 58Y2782 Korean 58Y2783 Norwegian 58Y2784 Polish 58Y2785 Portuguese 58Y2786 Romanian 58Y2788 Russian 58Y2789 Russian (English-enabled) 58Y2787 Serbian-Latin 58Y2793 Simplified Chinese 58Y2771 Slovak 58Y2790 Slovenian 58Y2791 Spanish 58Y2792 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 50. Parts list—Windows Vista Business (32-bit) DVDs (continued) Language 58Y2772 Traditional Chinese Traditional Chinese (Hong Kong S.A.R.) 58Y2779 Turkish 58Y2794 • 3249-CTO • 3323-CTO • 3357-CTO • 3626-CTO • 3680-CTO • 3712-CTO • 4492-CTO • 5129-CTO • 5143-CTO • 5385-CTO •...
58Y2852 English, French, German, and Italian (in Switzerland) 58Y2854 French 58Y2836 German 58Y2838 58Y2837 Greek Hebrew 58Y2839 Hungarian 58Y2841 Italian 58Y2842 Norwegian 58Y2843 Polish 58Y2844 Romanian 58Y2845 Serbian-Latin 58Y2849 ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
Table 53. Parts list—Windows Vista Ultimate (32-bit) DVDs (continued) Language 58Y2832 Simplified Chinese Slovak 58Y2846 58Y2847 Slovenian Spanish 58Y2848 58Y2833 Traditional Chinese Traditional Chinese (Hong Kong S.A.R.) 58Y2840 Turkish 58Y2850 • 3249-CTO • 3323-CTO • 3357-CTO • 3626-CTO • 3680-CTO •...
Windows 7 Home Premium (32-bit) is preinstalled as the operating system in the following models: • 7454-CTO, 3Px, 3Tx, GCx • 7455-CTO, 49x, 4Nx, 8Rx, 8Yx, P4x, P5x • 7457-CTO, 58x ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
USB floppy diskette drive tool kit 27L3452 Test card for integrated Smart Card 42W7820 — ThinkPad Hardware Maintenance Diskette Version 1.73 or later Note: Download the file from the following Web site: http://www.lenovo.com/spm ThinkPad X200, X200s, X200si, X201, X201i, and X201s Hardware Maintenance Manual...
