Removing the Memory Module(s)

WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. After working inside your computer, follow the instructions in "After
Working Inside Your Computer" on page 11. For additional safety best practices
information, see the Regulatory Compliance Homepage at
dell.com/regulatory_compliance.

Prerequisites

1 Remove the computer cover. See "Removing the Computer Cover" on page 15.
2 Remove the graphics card. See "Removing the Graphics Card" on page 26.

Procedure

WARNING: The memory module(s) may become hot during normal operation.
Allow the memory module(s) to cool before touching them.
1 Press out the securing clip at each end of the memory-module connector.
NOTE: If the memory module is difficult to remove, gently ease the memory
module back and forth to remove it from the connector.
2 Grasp the memory module and pull it upward.
1 memory-module connector
3 securing clips (2)
3
2
1
2 memory module
