Qos Traffic Shaping - Secure Computing SG300 User Manual

Select Packet Filtering from the Firewall menu, and click the Custom Firewall Rules
tab. Add the following Custom Firewall Rules:
iptables -t nat -D ContFilt -p tcp --dport 80 -j REDIRECT --to-port 81
iptables -t nat -A ContFilt -p tcp --dport 80 -j REDIRECT --to-port 3128
Click Update.
Select Advanced from the System menu, click the Configuration Files tab. Click the
Modify icon for squid.conf.
Add the following seven lines anywhere in the file:
httpd_accel_host virtual
httpd_accel_port 80
httpd_accel_with_proxy on
httpd_accel_uses_host_header on
cache_peer 127.0.0.1 parent 81 0 no-query default
acl authd proto HTTP
never_direct allow authd
Click Finish.

QoS Traffic Shaping

This advanced feature is provided for expert users to fine tune their network connections.
Traffic shaping allows you to give preference to certain types of network traffic to
maintain quality of service when a network connection is under heavy load.
QoS autoshaper
The Auto Traffic Shaper uses a set of inbuilt traffic shaping rules to attempt to ensure
low latency on interactive connections, while maintaining fast throughput on bulk
transfers.
Click Edit next to the network interface on which you wish to enable the autoshaper.
Network Setup
123
