Allied Telesis AT-AR236E Easy Start

Allied Telesis AT-AR236E Easy Start

Adsl ethernet & usb router
Hide thumbs Also See for AT-AR236E:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual
AT-AR236E
ADSL Ethernet & USB Router
Easy Start
Version 1.0
•
Product warranty does not apply to damage caused by lightning, power surges or wrong voltage usage.
•
This product is for use only in UL Listed computers.
Contents
Introduction ....................................................... 2
Minimum System Requirements ........................... 2
ADSL Router Package ......................................... 3
ADSL Router Overview ........................................ 3
Computer/Notebook................................. 6
Installing Your USB Device ...................... 10
Step 4: Connecting to the Internet ...................... 19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-AR236E and is the answer not in the manual?

Questions and answers

Related Manuals for Allied Telesis AT-AR236E

Summary of Contents for Allied Telesis AT-AR236E

  • Page 1: Table Of Contents

    AT-AR236E ADSL Ethernet & USB Router Easy Start Version 1.0 Contents Introduction ............2 Minimum System Requirements ......2 ADSL Router Package ......... 3 ADSL Router Overview ........3 Step 1: Connecting the ADSL Router to Your Computer/Notebook......... 6 Step 2: Configuring Your Ethernet Network Card / Installing Your USB Device ......

  • Page 2: Introduction

    Easy Start Introduction Thank you on your purchase of the Allied Telesyn AT-AR236E ADSL Ethernet & USB Router! The ADSL Router provides you with a high-speed broadband Internet connection using your existing phone line that at the same time allows you to make phone calls.

  • Page 3: Adsl Router Package

    Easy Start Easy Start Easy Start Easy Start Easy Start ADSL Router Package For any missing items, please contact your dealer immediately. 3. Easy Start USB cable 2. Installation CD 1. ADSL Ethernet & USB Router 7. CAT-5 UTP Straight Telephone cable (RJ-11) Power adapter (DC 9V) Ethernet Network cable (RJ-...

  • Page 4: Adsl Router Overview

    Easy Start Easy Start Easy Start Easy Start Easy Start ADSL Router Overview Front Indicators Lights up when the PPP connection is established. Lights up when power is supplied to the Router. Lights up when the ADSL connection is established. Flickers when the ADSL Router is trying to establish a connection with the ADSL Service Provider.

  • Page 5: Back Panel

    Easy Start Easy Start Easy Start Easy Start Easy Start Back Panel Telephone jack (RJ-11) to connect to your Telephone Wall Socket (ADSL line). USB port to connect to the USB port on your computer/notebook. ETHERNET 10/100 Base-T Ethernet jack (RJ-45) to connect to your Ethernet Network card or Ethernet Hub / Switch RESET To reset your ADSL Router to factory default settings.

  • Page 6: Step 1: Connecting The Adsl Router To Your Computer/Notebook

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 1: Connecting the ADSL Router to Your Computer/Notebook Power off your Computer/Notebook or/and any connected devices before connecting to the ADSL Router! To connect to your ADSL Router, you need to have either an Ethernet Port or a USB Port present on your Computer/Notebook.
  • Page 7 Easy Start Easy Start Easy Start Easy Start Easy Start See the following illustration. Computer/Notebook with USB Port Ethernet Ethernet Switch / Hub Computers/Notebooks with Ethernet Network Cards For details on the connection and types of Ethernet Network cable to use with the Ethernet Switch/Hub, please refer to the documentation that comes with your Ethernet Switch/Hub.
  • Page 8 Easy Start Easy Start Easy Start Easy Start Easy Start 1.1.2(a) Connecting to the Ethernet (This connection is not required if you are connecting to an Ethernet Switch/Hub for multiple- users connection). Back view of a computer Ethernet Port Back view of the ADSL Ethernet Router...
  • Page 9 Easy Start Easy Start Easy Start Easy Start Easy Start Step 1.2 Connecting to the ADSL Line To connect the ADSL Ethernet Modem to the ADSL line, carried out Step 1.2(a). To connect the ADSL Ethernet Modem to the ADSL line and a Telephone Set, carried out Step 1.2(b).
  • Page 10 Easy Start Easy Start Easy Start Easy Start Easy Start Step 1.3 Connecting to the Power Outlet Connect your ADSL Router to the Power Outlet via the Power adapter (that comes with your ADSL Router package). Back view of the ADSL Connect the other end of the Router Power Adapter to the Power...

  • Page 11: Step 2: Configuring Your Ethernet Network Card / Installing Your Usb Device

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 2: Configuring Your Ethernet Network Card / Installing Your USB Device If your computer/notebook is connected to the Ethernet Port of the ADSL Router, section 2.1. If your computer/notebook is connected to the USB Port proceed with of the ADSL Router, proceed with section...

  • Page 12: For Windows

    Easy Start Easy Start Easy Start Easy Start Easy Start 2.1.2 For Windows 2000 / Windows ® ® Windows® 2000: From your Windows desktop, right-click on the icon My Network Places select Properties. At the Network and Dial-up Connections window, right-click on the Local Area Connection icon and select Properties.

  • Page 13: Installing The Usb Device Driver

    Easy Start Easy Start Easy Start Easy Start Easy Start Installing the USB Device Driver Proceed with this section ONLY if your computer/notebook is connected to the USB Port of your ADSL Router! The following screen shots illustrated serve only as examples. For any dissimilarities, please follow closely the instructions prompted on your Computer/Notebook.
  • Page 14 Easy Start Easy Start Easy Start Easy Start Easy Start Select The updated driver (Recommended) DSL Router USB Remote NDIS Network Device and click Next. Click Next to proceed installation with indicated driver. Depending on your system configurations, you may be prompted for your Windows CD-ROM during installation.
  • Page 15 Easy Start Easy Start Easy Start Easy Start Easy Start 2.2.2 Installing the USB Device Driver - For Windows ® Power on your computer to start Windows. Place the Installation CD into your CD-ROM Drive. At the following prompt, select Specify the location of the driver (Advanced) option and click Next.
  • Page 16 Easy Start Easy Start Easy Start Easy Start Easy Start 2.2.3 Installing the USB Device Driver - For Windows 2000 ® Power on your computer to start Windows. Place the Installation CD into your CD-ROM Drive. At the following prompt, click Next. Select Search for a suitable driver for my device (recommended)
  • Page 17 Easy Start Easy Start Easy Start Easy Start Easy Start 2.2.4 Installing the USB Device Driver - For Windows ® Power on your computer to start Windows. Place the Installation CD into your CD-ROM Drive. At the following prompt, select Install from a list or specific location (Advanced) option and click Next.

  • Page 18: Step 3: Configuring Your Internet Browser

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 3: Configuring Your Internet Browser Microsoft® Internet Explorer™ (based on IE 5.5) From your Windows desktop, double-click on your Internet Explorer icon launch your Browser. From the Menu, click Tools and select Internet Options...

  • Page 19: Step 4: Connecting To The Internet

    Easy Start Easy Start Easy Start Easy Start Easy Start Step 4: Connecting to the Internet From your Internet Browser, key in http://192.168.1.1 at the address bar and hit <Enter>. You will be prompted for the username password to login to the Web Management. Enter admin for the username and password for the Password (factory defaults).
