Grizzly G0552 Machine Data Sheet

Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
Product Dimensions:
Weight.............................................................................................................................................................. 233 lbs.
Length/Width/Height............................................................................................................................. 33 x 20 x 45 in.
Foot Print (Length/Width)....................................................................................................................... 28 x 19-1/2 in.
Shipping Dimensions:
Type......................................................................................................................................................... Not Available
Content.................................................................................................................................................... Not Available
Weight.................................................................................................................................................................... N/A
Length/Width/Height........................................................................................................................... N/A x N/A x N/A
Electrical:
Switch........................................................................................................ Magnetic with Thermal Overload Protector
Switch Voltage...................................................................................................................................................... 220V
Cord Length.......................................................................................................................................................... 10 ft.
Cord Gauge....................................................................................................................................................14 gauge
Minimum Circuit Size........................................................................................................................................ 15 amp
Plug Included............................................................................................................................................................ No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................ Single
Amps.............................................................................................................................................................12A
Speed.................................................................................................................................................3450 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer .................................................................................................................... Power Twist V-Belt
Bearings....................................................................................................................... Shielded and Lubricated
Main Specifications:
Operation Info
Max. Cut Width.............................................................................................................................................7 in.
Max. Cut Height............................................................................................................................................8 in.
Min. Stock Length........................................................................................................................................9 in.
Min. Stock Width....................................................................................................................................... 1/4 in.
Max. Stock Thickness.................................................................................................................................. 8 in.
No. Of Cuts Per Inch....................................................................................................................................... 78
No. Of Cuts Per Minute............................................................................................................................. 14000
Cutterhead Speed.............................................................................................................................. 7000 RPM
Planing Feed Rate..................................................................................................................................15 FPM
Moulding Feed Rate............................................................................................................................... 15 FPM
Max. Cut Depth Planing Full Width......................................................................................................... 1/16 in.
Max. Cut Depth Planing 6 Inch Wide Board............................................................................................1/16 in.
Max. Profile Depth Moulding..................................................................................................................... 3/4 in.
Max. Profile Width Moulding.................................................................................................................. 6-3/4 in.
The information contained herein is deemed accurate as of 10/7/2008 and represents our most recent product specifications.
Model G0552
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
MODEL G0552 PLANER MOULDER
MACHINE DATA
SHEET
PAGE 1 OF 2
