Summary of Contents for Danfoss DHP-S Eco
- Page 1 User manual DHP-S VUIFM102...
- Page 2 If these instructions are not followed during installation and service, Danfoss A/Sliability according to the applicable warranty is not binding. Danfoss A/S retains the right to make changes to components and specifi- cations without prior notice. © 2010 Copyright Danfoss A/S.
-
Page 3: Table Of Contents
Contents Important information......................... 3 Safety precautions........................... 4 Protection..............................5 About your heat pump........................6 Product description..........................6 The principles of the heat pump......................6 Hot water tank (option).......................... 8 Room sensor (option)..........................8 Operating instructions......................... 9 Control panel............................. 9 Checking the coolant circuit pressure.................... 14 Checking the water level in the heating system................ -
Page 5: Important Information
Important information Note! If the installation is not used during the winter, the heating system must be drained of water, otherwise there is a risk of frost damage to the installation. The system can be considered maintenance free but certain checks are necessary. -
Page 6: Safety Precautions
Safety precautions 1.1.1 Installation and maintenance DANGER! Only authorized installers may install, operate and carry out maintenance and repair work on the heat pump. DANGER! Only authorized electricians may modify the electrical installation. DANGER! DANGER TO LIFE! Only authorized refrigeration technicians may work on the refrigerant circuit. -
Page 7: Protection
Protection 1.2.1 Corrosion Protection Due to the risk of corrosion, avoid using different types of sprays in the vicinity of the heat pump. This particularly applies to: • Solvents • Chlorinated cleaning agents • Paints • Adhesives User manual VUIFM102 – 5... -
Page 8: About Your Heat Pump
About your heat pump Product description The heat pump is a heating system for heating and hot water if an external water heater is installed (accessory). It has a compressor developed solely for heat pumps. The heat pump is equipped with control equipment which is presented in a graphical display. - Page 9 The heat pump is, therefore, a very environmentally friendly and eco- nomical way of heating a house. Figure 1. The principles of the heat pump The heat pump has four separate fluid circuits • Brine circuit (1) – is a fluid (brine) filled hose lowered into a lake, buried in the ground or lowered into bedrock.
-
Page 10: Hot Water Tank (Option)
• Heat transfer fluid circuit (8) – is the water that transports the heat/ energy to the heating system and the hot water tank. • Hot gas circuit – is a high temperature circuit for the hot water circuit’s final heater. If the heat pump is not connected to any water heaters, the hot gas circuit does not need to be connected. -
Page 11: Operating Instructions
Operating instructions Control panel 3.1.1 Function description The heat pump has an integrated control system which automatically cal- culates the heat demand in the house to ensure that the correct amount of heat is produced and emitted where necessary. There are many differ- ent values (parameters), which are required in order to do the calculation of the heat demand. - Page 12 display always shows the set ROOM value, the operating mode and the status of the heat pump. ROOM 20°C NO HEAT DEMAND OPERAT. AUTO Figure 2. Display, keypad and indicator. (20°C) Position Description The display text and symbols are only shown as examples. Certain symbols cannot be displayed at the same time.
- Page 13 For installation and service, the SERVICE menu is used, which is opened by pressing the left button for five seconds. The SERVICE menu has a number of sub menus, see Menu information. The INFORMATION and SERVICE menus are intended for two categories of user, customers and installers.
-
Page 14: Operating Modes
3.1.2 Display The display shows information about the heat pump’s operation, status and any alarms, in text form. Operating mode and status, indicated by symbols, are also shown in the lower part which shows the heat pump’s active processes. Note! To change the display language, press the following sequence of buttons: right arrow, arrow down to bottom menu, arrow right, scroll between languages using + or -. - Page 15 Operating Meaning mode AUX. HEATER The control system only permits the auxiliary heater to be in operation. HOT WATER In this mode the heat pump only produces hot water, no heat goes to the heating system. 3.1.2.2 Symbols Table 2. Symbols shown in the display.
-
Page 16: Checking The Coolant Circuit Pressure
3.1.2.3 Operational information Table 3. Shows information about the heat pump. Message Meaning ROOM Shows the set ROOM value. Standard value: 20°C. If the accessory room sensor is installed it shows the actual temperature and the desired indoor temperature is shown within brackets. START Indicates that there is a need for heat production and that the heat pump will start. -
Page 17: Checking The Water Level In The Heating System
See the installation instructions when filling brine. Symbol explanation Used when filling Connected to brine circuit Figure 4. Filling the brine system Checking the water level in the heating system The line pressure of the installation must be checked once a month. Ensure that heating system has the necessary pressure, however, not above max- imum pressure of 6 bar. -
Page 18: In The Event Of Leakage
regularly, the water tank might be damaged. It is quite normal that the safety valve lets out small amounts of water when the water tank is being charged, especially if a lot of hot water was used previously. Both safety valves can be checked by turning the cap a quarter of a turn clockwise until the valve lets out some water through the overflow pipe. -
Page 19: Menu Information
Menu information INFORMATION menu Open the menu by pressing the left or right button. The menu also shows history and operating times. Menus in italics are only visible if the expansion card (accessory) is instal- led. Table 4. Used to change the heat pump's operating modes and to adjust the heat curve. - Page 20 Menu Sub menu Sub menu Sub menu CURVE TEMPERATURE OUTDOOR ROOM (if a room sensor is installed) SYSTEM SUPPLY (if buffer tank is activated) SUPPLY LINE RETURN LINE BUFFER TANK (must be activated) HOT WATER (must be activated) INTEGRAL BRINE IN BRINE OUT POOL (expansion card) COOLING...
- Page 21 4.1.1 Sub-menu OPERAT. Table 5. Used to select operating mode. Menu Meaning Factory selection setting The installation is fully switched off. This mode is (OFF) also used to acknowledge certain alarms. CANCEL = starting point, no changes made. To select OFF as operating mode, press the minus sign once to scroll down one step and press the right arrow once.
- Page 22 4.1.2 Sub-menu HEAT CURVE Table 6. Used to change settings for the heat curve. Menu Meaning Factory selection setting CURVE Calculated supply temperature at 0°C outdoor 40°C temperature. Shown as a graphic curve. The curve (for under will be limited by the set values of MIN and MAX. floor heating 30°C) (range:...
- Page 23 Menu Meaning Factory selection setting TANK TEMP Displayed if buffer tank is active. Charges the buf- AUTO fer tank to the set temperature. AUTO setting (range: charges the tank to the supply line setpoint value. 30°C / 55°C) OVER- Displayed if the buffer tank is active and TANK 0°C CHARGE TEMP is set to AUTO.
- Page 24 4.1.3 Sub menu HEAT CURVE 2 Only appears if shunt group sensor is connected and activated in menu SERVICE -> INSTALLATION -> SYSTEM -> SHUNT GROUP. Table 7. Used to change settings for heat curve 2. Menu Meaning Factory selection setting CURVE 2 Calculated shunt group temperature at 0°C out-...
- Page 25 Menu Meaning Factory set- selection ting SUPPLY Shows the actual supply temperature. The calcu- LINE lated supply temperature to the heating system group is within brackets. During hot water production in operating mode AUX. HEATER the value for HOT WATER STOP + 10° is shown within brackets.
- Page 26 4.1.5 Sub-menu OPERAT.TIME Table 9. Used to show the operating time for each component. Time given in hours. Menu Meaning Factory selection setting HEAT PUMP Compressor operating time for both heating and hot water production. AUX. HEATER Operating time of auxiliary heater. HOT WATER Operating time for hot water with compressor.
-
Page 27: Troubleshooting
Troubleshooting Alarm In event of alarm this is indicated in the display with the text ALARM and an alarm message, see following table. For alarms that are not reset auto- matically acknowledgement is required. Acknowledge the alarm by set- ting the heat pump to operating mode OFF. Message Meaning HIGH PRESSURE... -
Page 28: Terms And Abbreviations
Terms and abbreviations Table 11. Terms and abbreviations Term Explanation Evaporator In the evaporator, energy is retreived from the heat source and the refrigerant passing through the evaporator turns to gas. De-superheater In the de-superheater part of the total heating output is released (approx. - Page 29 Term Explanation Control computer The control computer controls the entire heating instal- lation. All settings are stored and the history of the instal- lation is registered here. The control computer’s settings can be changed via the display. Room If ROOM shows 20°C the heat curve is unaffected. If ROOM shows higher or lower, this indicates that the heat curve has been adjusted up or down to change the indoor tem- perature.
-
Page 30: References
References Piping installation Date ............Company ............Name ............Tel. No............Electrical Installation Date ............Company ............Name ............Tel. No............System adjustment Date ............Company ............Name ............28 – User manual VUIFM102... - Page 31 System adjustment Tel. No............User manual VUIFM102 – 29...
- Page 32 VUIFM102...
