DSX SPECIFICATIONS

Input
Impedance: 1 Meg (HI-Z) - 10K (LO-Z)
Sensitivity: 150MV to 6V
EQ: (Active)
Bass: +/- 12db @ 150HZ
Treble: +/- 12db @ 5kHZ
Shape (On)
+5db @ 3kHZ
-5db @ 1500HZ
+5db @ 100HZ
Notch (Feedback Elimination)
Range: 100 to 350HZ
Attenuation: –18db
Line Out
Impedance: 10K
Sig. Level: 300MV Nominal
Output
Power: 50W RMS (25 Watts per side)
Total Harmonic Distortion: .1%
Signal to Noise Ratio: 98db
Speakers
Two 8" special design (coaxial)
DSX
Weight: 26 pounds
Height: 13"
Length: 18"
Depth: 10 ½"
Dimensions:
XTC
23 pounds
13"
18"
10 ½"

XTC SPECIFICATIONS

Impedance: 4 Ohms
Power Handling: 50 watts RMS
Speakers: Two 8" special design (coaxial)
Be sure to use a "Speaker Cable"
when connecting the XTC cabinet to an amplifier.
Using a shielded instrument cord can cause
unwanted noise or oscillation, which can harm the
amplifier and speakers.
