Spec.'s for the AG-30 series:
Input
Impedance: 1 Meg
Sensitivity: 150MV to 6V
EQ: (Active)
Bass: +/- 12db @ 150HZ
Treble: +/- 12db @ 5kHZ
Shape
+5db @ 3kHZ
-5db @ 1500HZ
+5db @ 100HZ
Notch (Feedback Elimination)
Range: 100 to 350HZ
Attenuation: –18db
Output
Power: 30W RMS
Total Harmonic Distortion: .1%
Signal to Noise Ratio: 98db
AG-30 series dimensions:
20 pounds
Weight:
11"
Height:
Length: 16"
Depth: 10 ½"
Serial number:
Model number:
Date of purchase:
Purchased from:
Please fill out and keep for your records.
ULTRASOUND AMPLIFIERS
5110 PARK AVE
DES MOINES, IA 50321
PHONE: 515-282-1650
FAX: 515-282-1680
www.UltraSoundAmps.com
E-MAIL:
Info@UltraSoundAmps.com
CUSTOMER / TECHNICAL SUPPORT:
E-MAIL:
Support@UltraSoundAmps.com
TOLL FREE 1-888-993-5091
ULTRASOUND AMPLIFIERS
5110 PARK AVE.
DES MOINES, IA 50321
30 series Owners Guide
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ultrasound 30 Series
Summary of Contents for Ultrasound 30 Series
- Page 1 ULTRASOUND AMPLIFIERS Spec.’s for the AG-30 series: AG-30 series dimensions: 5110 PARK AVE. 20 pounds Input Weight: DES MOINES, IA 50321 11” Height: Impedance: 1 Meg Length: 16” Sensitivity: 150MV to 6V Depth: 10 ½” EQ: (Active) Bass: +/- 12db @ 150HZ...
- Page 2 HZ – (NOTCH FILTER): Provides such as the ULTRASOUND AG-50E. selectable frequency shift of the 18db cut NOTCH FILTER from 100Hz - 350Hz DIRECT OUT: This XLR jack provides a to eliminate resonant feedback.
