Ultrasound AG-50DS2 Quick Manual

Back Panel Continued
AC Input: Connect the female end of the AC line
cord here. Connect the male plug to a suitable
source of line voltage. Refer to the voltage
information on the back of the amplifier for its
voltage and current requirements. This connector
also acts as the main fuse holder and includes a
compartment for a spare fuse.
Power: This rocker switch turns the AC power ON
and Off. When ON the unit is ready for play.
Protection
Short circuit and thermal overload
protection.
Spec.'s for the DS2 series:
Input
Impedance: 1 Meg
Sensitivity: 150MV to 6V
EQ: (Active)
Bass: +/- 12db @ 150HZ
Treble: +/- 12db @ 5kHZ
Shape
+5db @ 3kHZ
-5db @ 1500HZ
+5db @ 100HZ
Notch (Feedback Elimination)
Range: 100 to 350HZ
Attenuation: –18db
Line Out
IMP: 10K
Sig. Level: 300MV Nominal
Output
Power: 50W RMS
Total Harmonic Distortion: .1%
Signal to Noise Ratio: 98db
DS2 series dimensions:
AG-50DS2 AG-100DS2
23.7 pounds 37 ½ pounds
Weight:
13" 21 ½"
Height:
Length: 18" 18"
Depth: 10 ½" 10 ½"
Serial number:
Model number:
Date of purchase:
Purchased from:
Please fill out and keep for your records.
ULTRASOUND AMPLIFIERS
2150 Delavan Dr ste 11
WEST DES MOINES, IA 50265
PHONE: 515-282-1650
FAX: 515-282-1680
www.ultrasoundamps.com
E-MAIL: Info@ultrasoundamps.com
CUSTOMER / TECHNICAL SUPPORT:
E-MAIL:
Support@ultrasoundamps.com
TOLL FREE 1-888-993-5091
ULTRASOUND AMPLIFIERS
2150 DELEVAN DR STE 11
WEST
DES MOINES, IA 50265
It Sounds Just Like My Guitar,
Only Louder!!
DS2 series Owners Guide
